Care and precautions

1) Use a soft, dry cloth to clean the machine.

2) Use only

AA-size (LR6) alkaline batteries

3) Do not expose the machine or the tape cassette to high

temperatures, high humidity, or excessive dust.

4) If you do not intend to use the machine for an extended

period of time, remove the batteries.

5) Do not touch the tape cutter button while printing or

replacing the cutter unit.

6) Do not touch the cutter blade.

7) Do not block the tape exit slot.

8) Do not put labels in your mouth.

9) Do not stick labels onto skin.

10) If the machine “locks up” (i.e., it does not respond

when a key is pressed), press to turn o the

machine; then, while holding down and ,

press once to turn the machine on again.

FCC NOTICE

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protec-

tion against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communi-

cations. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on,

the user is encouraged to try to correct the interference by one

or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a circuit dierent

from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician

for help.

– Changes or modiﬁcations not expressly approved by Brother

Industries, Ltd. could void the user’s authority to operate the

equipment.

How to make a label

1) Insert the batteries.

2) Insert a tape cassette.

3) Turn on the P-Touch by pressing .

4) Type in and format the text.

Your text can be up to 55 characters long including spaces. See

“Advanced functions” for more details on formatting your text.

5) Print the label by pressing .

Before printing, be sure that the back cover is attached,

otherwise the label cannot be printed.

6) Cut oﬀ the label.

The tape cutter button is equipped with a safety mecha-

nism. Do not try to force the cutter button since it cannot

be operated if no cassette is installed and the back cover is

removed. If the cutter button is forcefully operated, correct

printing may no longer be possible.

7) Peel oﬀ the backing.

Changing the batteries

1) Remove the back cover by pressing in on the rough

area at the top end of the machine and pulling off the

back cover.

2) If batteries are already installed, remove them.

Before removing the batteries, pull out the tape cas-

sette if one is installed.

3) Insert

six new AA-size (LR6) alkaline batteries

in the

direction shown by the illustration on the bottom of the

battery compartment. The positive end of the three bat-

teries in the bottom row point downward, while the

positive end of the top three batteries point in the

opposite direction.

Back cover

With the P-Touch HOME&HOBBY, you can make labels quickly and easily. Simply switch on the P-Touch, type in your text, then

print out your label. You can choose from ﬁve dierent text sizes, nine character styles, and seven framing settings. The text can be

printed on either one or two lines and can include accented characters and special symbols. In addition, nine preset layout formats are

available for you to type in and print out labels quickly. Six tape color (white, silver, gold, blue, green and pink) and two tape widths

(3/8” (9 mm) and 1/2” (12 mm)) are available for creating personalized labels.

LA3085001

Printed in China

Please read this instruction leaﬂet before using the P-Touch. Keep

it in a handy place for future reference.

Use only tape cassettes bearing the logo with this machine.

TAPE

When inserting new batteries, always insert them pos-

itive end ﬁrst. When removing old batteries, always

remove them negative end ﬁrst.

Always replace all six batteries at the same time with

brand new ones.

4) Attach the back cover by inserting the two hooks on the

bottom end of the back cover into the slots on the bot-

tom end of the machine, then pushing down ﬁrmly on

the cover until it snaps into place.

Changing the tape cassette

1) Remove the back cover by pressing in on the rough

area at the top end of the machine and pulling off the

back cover.

2) If a tape cassette is already installed, pull it straight out

and remove the paper tab from the new tape cassette.

Make sure that the end of the tape in the new cassette

feeds under the tape guides.

The tape that is provided with the P-touch

Home&Hobby is a 13.3’ long (4m) starter tape. Tapes

available for purchase are 26.2’ (8m) long.

3) Insert the tape cassette, making sure that it clicks into place.

Check that the cassette ﬁts properly around the two

metal guides in the cassette compartment.

4) Attach the back cover by inserting the two hooks on the

bottom end of the back cover into the slots on the bot-

tom end of the machine, then pushing down ﬁrmly on

the cover until it snaps into place.

5) Feed the tape by holding down and pressing ,

then cut the tape by pressing in on the tape cutter button.

The amount of tape remaining is visible through the

window in the back of the P-Touch.

When the usable tape is ﬁnished, green ribbon appears.

Changing the cutter unit

When the cutter becomes blunt and ceases to cut the tape

cleanly, replace it.

1) Remove the back cover and the tape cassette.

2) Grasp the tab on the top of the cutter unit and pull out

the cutter, taking care not to touch the blade.

3) Grasp the tab on the new cutter unit and insert it as

shown below.

Cleaning the print head

If dust accumulates on the print head, blank horizontal

lines may appear through the printed label. If this hap-

pens, clean the print head as follows:

1) Turn o the P-Touch.

2) Remove the back cover and the tape cassette.

3) Use a dry cotton swab to gently wipe the print head

and rubber pinch roller with an up-and-down motion.

4) Re-insert the tape cassette, attach the back cover, turn

on the machine, hold down and press to feed

the tape, and then try printing.

5) If blank lines remain in the printed label, repeat steps 1

through 4, this time using a cotton swab dipped in iso-

propyl (rubbing) alcohol.

Accessories

Most retailers and distributors carry a full line of tape cas-

settes. If you wish to order accessories for your P-Touch

direct from Brother, please refer to the “Accessory Order

Form” included separately, or visit our web site

“http://www.brothermall.com”.

Tape guides

Metal guides

Tape cutter

button

CAUTION

• When changing the cutter unit, be sure not to

touch the cutter blade.

• Keep the cutter unit in a safe place that is out of

the reach of small children.

The following accessories are available:

Tape cassettes 1/2” (12 mm)

$9.99 (SRP)

3/8” (9 mm)

$8.99 (SRP)

Black on silver

Black on gold

Black on blue

Black on green

Black on pink

M-931

M-831

M-531

M-731

M-E31

M-921

M-821

M-521

M-721

M-E21

Black on white M-231

Replacement cutter

unit TC7 $9.95 (SRP)

Carrying case 6991 $17.99

Cutter unit

Tape exit slot

Tab

Thermal print head Rubber pinch

roller

Function keys

• On/Oﬀ ( )

To switch the P-Touch on or o, press .

The P-Touch conserves battery power by automatically

switching itself o if no key is pressed within ﬁve minutes.

When the batteries are low, “BATTERY” appears on the

display after printing. When the batteries are very low, the

P-Touch will automatically turn itself o when you try to

print text or feed the tape.

If the P-Touch is turned o and then on again, the current

text, text size and style, underline/frame setting, and Caps

setting remain unchanged.

• Caps ( )

To turn the Caps function on or o, press . When the

Caps indicator is on, you can add capital letters to your

text by simply pressing the character keys. When the Caps

indicator is o, pressing a character key enters lower case

letter in your text.

• Num ( )

To turn the Num function on or o, press . When the

Num indicator is on, you can add numbers to your text by

simply pressing the corresponding keys. When the Num

indicator is o, pressing a key adds a letter to the text.

• Space ( )

To add a space to your text, press .

• Return ( )

This key has 2 functions:

1) To end the ﬁrst line of text and start the second line,

simply press .

2) To accept or conﬁrm a setting, such as an accented

character or symbol.

Two-line text can only be printed with the

SIZE1 text size

and the

NORMAL

style. To change a message back to a

single line, use to delete the marker.

• Code ( / )

To access the functions or enter the characters printed in

yellow above the keys, press . See the following expla-

nations and “Advanced functions” for more details on

how this key is used.

The left and right Code keys can be used in the same way.

• Cursor movement ( , )

You can move the cursor ( _ ) to view or edit parts of the

text to the left or right of the 8 characters shown in the

LCD display. To move the cursor to the left, press ; to

move the cursor to the right, press . Move the cursor

several characters in a row by holding down the appropri-

ate key.

To position the cursor under the ﬁrst character of the text,

hold down and press ; to position the cursor

immediately after the last character, hold down and

press .

• Backspace ( )

To delete the character to the left of the cursor, press .

This key can also be used to cancel current function and

return to the text mode.

To erase the current text, hold down and press . The

text size, style, underline/frame setting, and Caps/Num

setting are not cleared.

• Text ( )

To view the entered text, hold down and press . All

of the entered text, starting from the beginning, scrolls

along the display, then the length of the text appears .

To change the units, press while the text is scrolling

across the display. Press or (or press ) until

the desired unit appears, and then press . The current

label length appears in the display for a short time.

• Feed ( )

To feed out about 1” (24 mm) of tape at a time, hold down

and press . The message “FEED” appears while

the tape is fed.

Do not press the tape cutter button while feeding, as this

will cause the tape to jam.

• Print ( )

To print out the entered text, press . The message

“PRINT” appears while printing.

Do not press the tape cutter button while printing, as this

will cause the tape to jam.

• Accented characters (

)

To enter an accented character, ﬁrst make sure the Caps

function is turned on or o as desired, then hold down

and press . After the message “A–U?” appears, press the

key of the desired letter (A, C, E, I, N, O or U).

In the displayed list of available accented characters, press

or to position the cursor under the desired

accented character, then press . Your text reappears on

the display with the selected character added.

To clear the list of available accented characters and return

to the current text, press (or hold down and press

) instead of pressing .

The following accented characters are available:

LCD display

Backspace key

On/Oﬀ key

Tape cutter button

Space key

Code key

Caps key

Num key

Print key

Code key

Accented characters Accented characters

Aàáäâãæ

ÀÁÄÂÃÆ N ñ Ñ

C ç Ç O óöôõ

ÓÖÔÕ

E èéëê ÈÉËÊ U ùúüû ÙÚÜÛ

I í ï î Í Ï Î

Advanced functions

Produktspecifikationer

Varumärke:	Brother
Kategori:	Skrivare
Modell:	P-Touch PT-65

Behöver du hjälp?

Om du behöver hjälp med Brother P-Touch PT-65 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Skrivare Brother Manualer

Brother HL-2240DR Bruksanvisning

21 Oktober 2024

Brother DCP-J152W Bruksanvisning

15 Oktober 2024

Brother HL-3150CDW Bruksanvisning

9 Oktober 2024

Brother P-touch PT-9800PCN Bruksanvisning

7 Oktober 2024

Brother PT-E110 Bruksanvisning

3 Oktober 2024

Brother DCP-115C Bruksanvisning

2 Oktober 2024

Brother HL-1650 Bruksanvisning

2 Oktober 2024

Brother MFC-J6555DW Bruksanvisning

29 September 2024

Brother MW-120 Bruksanvisning

29 September 2024

Brother HL-L2420DW Bruksanvisning

21 September 2024

Skrivare Manualer

Nyaste Skrivare Manualer

Lexmark CX421 Bruksanvisning

27 Oktober 2024

Samsung SCX-4729FD Bruksanvisning

26 Oktober 2024

HP Latex 800 Bruksanvisning

24 Oktober 2024

HP LaserJet M525fm Bruksanvisning

24 Oktober 2024

HP LaserJet M2727NF Bruksanvisning

24 Oktober 2024

HP Color LaserJet Pro M255dw Bruksanvisning

24 Oktober 2024

HP Deskjet 460WBT Bruksanvisning

24 Oktober 2024

HP 8017 All-in-One Bruksanvisning

24 Oktober 2024

HP Laser MFP 137fnw Bruksanvisning

24 Oktober 2024

HP DesignJet Studio Bruksanvisning

24 Oktober 2024
