BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT — Save these
instructions for local inspector’s use.
• IMPORTANT — Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with consumer.
• Note to consumer – Keep these
instructions for future reference.
• Skill level – Installation of this appliance
requires a qualified installer or electrician.
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is
not covered under warranty.
FOR YOUR SAFETY:
If you did not receive an anti-tip bracket with your purchase,
visit ).cafeappliances.com (In Canada, cafeappliances.ca
Installation Instructions
Electric Slide-In Ranges
MATERIALS YOU MAY NEED TOOLS YOU WILL NEED
(UL Listed 40 AMP)
4-Wire Cord 4’ long OR
3-Wire Cord 4’ long
Squeeze Connector
(For Conduit
Installations Only)
1 REMOVE PACKAGING MATERIALS: Failure to remove packaging
materials could result in damage to the appliance. Remove all packing parts from oven,
racks, heating elements and drawer. Also, remove protective film and labels on the outer
door, cooktop and control panel.
Drill with 1/8” Bit
Safety Glasses
Adjustable Wrench
Level
Tin Snips
Tape Measure
Pliers
1/4” Nut Driver
Questions? Visit cafeappliances.com. In Canada, visit cafeappliances.ca.
2 PREPARE THE OPENING (FOR INDOOR USE ONLY)
See illustrations for all rough-in and spacing dimensions. The range may be placed with 0”
clearance (flush) at the back wall and side walls of the cabinet.
NOTE: Use a 4’ power cord to prevent interference with
the storage drawer. Power cords 4
1»2’ to 6’ long may
have to be dressed to allow for proper drawer closing.
MINIMUM DIMENSIONS BETWEEN COOKTOP,
WALLS AND ABOVE THE COOKTOP:
A. Make sure the wall covering, countertop, flooring
and cabinets around the range can withstand the
heat (up to 200°F) generated by the range. 0” to
cabinets below cooktop and at the range back.
B. Allow 30” minimum clearance between surface units
and bottom of unprotected wood or metal cabinet, or
allow a 24” minimum when bottom of wood or metal
cabinet is protected by no less than 1/4” thick flame
retardant millboard covered with not less than No.
28 MSG sheet metal, (.015”), .015” thick stainless
steel, .024” aluminum or .020” copper.
C. This appliance has been approved for 0” spacing
to adjacent surfaces above the cooktop. However,
a 6” minimum spacing to surfaces less than 15” above the cooktop and adjacent cabinet is
recommended to reduce exposure to steam, grease splatter and heat.
To reduce the risk of burns or fire when reaching over hot surface elements, cabinet storage space
above the cooktop should be avoided. If cabinet storage space is to be provided above the cooktop,
the risk can be reduced by installing a range hood that projects at least 5” beyond the front of the
cabinets. Cabinets installed above the cooktop must be no deeper than 16”.
Anti-Tip Bracket
Kit Included
WARNING Before
beginning the installation, switch power
off at service panel and lock the service
disconnecting means to prevent power
from being switched on accidentally.
When the service disconnecting means
cannot be locked, securely fasten a
prominent warning device, such as a
tag, to the service panel.
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
• Engage the range to the anti-tip bracket by sliding the
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING
A
C
B
A
C
Both
Sides
30”
Install the
outlet box
on either
side of the C
L
36
1»4” ± 1»4”
11»8”
471»2”
26 7
»8”
w/o handle
291»2”
with handle
30”
3”
3” 3”
9” 8”
4”
71»2”21»4”
21»4”
Recommended
acceptable
electrical outlet
area. Orient the
electrical receptacle
so the length is
parallel to the floor.
3 ELECTRICAL REQUIREMENTS
WARNING This appliance must be properly grounded.
WARNING
All new constructions, mobile homes, recreational vehicles and installations
where local codes do not allow grounding through neutral, require a 4-conductor UL-listed range cord.
WARNING To prevent fire or shock, do not use an extension cord with this appliance.
WARNING
To prevent shock, remove house fuse or open circuit breaker before
beginning installation.
We recommend you have the electrical wiring and hookup of your range connected by a qualified
electrician. After installation, have the electrician show you how to disconnect power from the range.
You must use a single-phase, 120/208 VAC or 120/240 VAC, 60 hertz electrical system. If you
connect to aluminum wiring, properly installed connectors approved for use with aluminum wiring
must be used.
Effective January 1, 1996, the National Electrical Code requires that new construction (not existing)
utilize a 4-conductor connection to an electric range. When installing an electric range in new
construction, mobile home, recreational vehicle, or an area where local codes prohibit grounding
through the neutral conductor, refer to the section on four-conductor branch circuit connections.
Check with your local utilities for electrical codes which apply in your area. Failure to wire your oven
according to governing codes could result in a hazardous condition. If there are no local codes,
your oven must be wired and fused to meet the National Electrical Code, NFPA No. 70 – latest
edition, available from the National Fire Protection Association.
This appliance must be supplied with the proper voltage and frequency, and connected to an
individual, properly grounded, 40 amp (minimum) branch circuit protected by a circuit breaker or
time-delay fuse.
Use only a 3-conductor or a 4-conductor UL-listed range cord. These cords may be provided with
ring terminals on wire and a strain relief device.
A range cord rated at 40 amps with 125/250 minimum volt range is required. A 50 amp range cord
is not recommended but if used, it should be marked for use with nominal 1
3»8” diameter connection
openings. Care should be taken to center the cable and strain relief within the knockout hole to
keep the edge from damaging the cable.
The rating plate is located on the oven frame or on the side of the drawer frame.
NOTE: Use of automatic, wireless or wired external switches that shut off power to the appliances,
are not recommended for this product.
Rating plate
SINGLE OVEN
4
POWER CORD AND CONDUIT INSTALLATION
A Remove wire cover (on the back of range) by removing screws using a 1/4” nut driver. You
can access the terminal block by either removing a terminal block cover (on some models) or
the wire cover. Do not discard these screws.
B For power cord and 1” conduit only, remove
the knockout ring (13»8”) located on bracket
directly below the terminal block. To remove
the knockout, use a pair of pliers to bend the
knockout ring away from the bracket and
twist until ring is removed.
D For 3/4” conduit installations only, purchase a squeeze connector matching the diameter
of your conduit and assemble it in the hole. Insert the conduit through the squeeze connector
and tighten. Allow enough slack to easily attach the wires to the terminal block. NOTE: Do
not install the conduit without a squeeze connector. The squeeze connector MUST be
installed before reinstalling the rear terminal block.
Knockout
ring in
bracket
Knockout ring
removed
Terminal block
(appearance
may vary)
C For power cord installations only (see
the next step if using conduit), assemble
the strain relief in the hole. Insert the
power cord through the strain relief and
tighten. Allow enough slack to easily
attach the cord terminals to the terminal
block. If tabs are present at the end of
the winged strain relief, they can be
removed for better fit.
NOTE: Do not install the power cord
without a strain relief. The strain relief
bracket MUST be installed before
reinstalling the rear range wiring cover.
Power cord
Strain relief
Terminal
block
Bracket
Squeeze
connector Terminal block
Conduit Bracket
Proceed to step 6 or 7.
Rear of Range
Terminal
Block Cover Screws to
remove terminal
block cover
6 3-WIRE INSTALLATION (GROUND IS THROUGH THE
NEUTRAL WIRE)
WARNING Shock Hazard
The neutral wire and ground strap must be
connected as shown below for the range to be
properly grounded. Do not remove the ground strap.
Failure follow this instruction may result in potential
shock hazard.
WARNING Fire hazard
Terminal block screws must be securely tightened.
Failure to do so may result in potential fire hazard.
FOR POWER CORD INSTALLATION
A. Remove the 3 lower screws from the terminal
block. Do not loosen the upper screws.
B. Do not cut or remove the ground strap.
C. Insert the 3 screws through each power cord
terminal ring and back into the terminal block. Be
certain the white wire is in the center. Securely
tighten each screw (35 to 50 in-lbs.)
FOR CONDUIT INSTALLATION
A. Loosen the 3 lower screws on the terminal block. Do
not loosen the upper screws.
B. Do not cut or remove the ground strap.
C. Insert the bare wire tip (insulation stripped 5/8”) into the
bottom terminal block openings. Be certain the white
wire is in the center. On certain models, the wire must
be inserted through an opening in the ground strap.
Securely tighten each screw onto each wire (35 to 50
in-lbs.).
D. Reinstall terminal block cover.
NOTE: Aluminum building wire may be used but it must
be rated for the correct amperage and voltage.
PROCEED TO STEP 8.
5 REAR TRIM INSTALLATION
For all installations, install the required rear trim to back of range with 4 screws provided.
7 4-WIRE INSTALLATION (SEPARATE GROUND WIRE)
WARNING The neutral wire of
the supply circuit must be connected to the
neutral terminal located in the lower center
of the terminal block. The power leads must
be connected to the lower left and the lower
right terminals of the terminal block. The
grounding lead must be connected to the
frame of the range with the ground plate and
the green ground screw.
FOR POWER CORD INSTALLATION
A. Remove the 3 lower screws from the
terminal block. Do not loosen the upper
screws.
B. Remove the ground screw and ground plate
and retain them.
C. Cut the ground strap below the terminal
block and discard the lower section.
D. Insert the ground screw through the ground
plate (removed earlier) and back into the
range frame. Tighten securely, but do not
over-tighten (15 to 20 in-lbs.)
E. Insert the 3 terminal screws through each
power cord terminal ring and back into the
terminal block. Be certain the white wire is
in the center. Securely tighten each screw
(35 to 50 in-lbs.
F. Reinstall terminal block cover.
FOR CONDUIT INSTALLATION
A. Remove the 3 lower screws from the terminal
block. Do not loosen the upper screws.
B. Remove the ground screw and ground plate
and retain them.
C. Cut the ground strap below the terminal block
and discard the lower section.
D. Insert the bare ground bare wire tip (insulation
stripped 5/8”) between the range frame and the
ground plate (removed earlier) and secure it in
place with the ground screw. Tighten securely,
but do not over-tighten (15 to 20 in-lbs).
E. Insert the wire tips (insulation stripped 5/8”) into
the bottom terminal block openings. Be certain
the white wire is in the center. On certain
models, the wire must be inserted through an
opening in the ground strap. Securely tighten
each screw onto each wire (35 to 50 in-lbs.)
F. Reinstall terminal block cover.
NOTE: Aluminum building wire may be used but it must be rated for the correct amperage and voltage.
Ground
strap
Terminal block
(appearance
may vary)
Neutral
terminal
Power cord
Ground
plate
Power Cord
Red or
Black
Red or
Black
White
Terminal
block
Red or
Black
Red or
Black
Neutral
terminal
Ground plate
(grounding to
range)
Ground
screw
After–Power Cord
Green
or Bare
White
Before–Power Cord and Conduit
Terminal
block
Neutral
terminal
Ground
strap
Ground strap
or
After–Conduit
Terminal
block Ground plate
(grounding to
range)
Wire
tips
Ground
screw
Red or
Black
Red or
Black
White
Green
or Bare
Wire
tips
Terminal
block
Conduit
Conduit
Red or
Black Red or
Black
White
Screws
Rear Trim
Back of
Range

Produktspecifikationer

Varumärke: Café
Kategori: Ugn
Modell: CHS900P2MS1

Behöver du hjälp?

Om du behöver hjälp med Café CHS900P2MS1 ställ en fråga nedan och andra användare kommer att svara dig


Ugn Café Manualer

Café

Café CES700P4MW2 Bruksanvisning

17 Oktober 2024
Café

Café CGS750P4MW2 Bruksanvisning

17 Oktober 2024
Café

Café C2Y486P2TS1 Bruksanvisning

17 Oktober 2024
Café

Café CES750P4MW2 Bruksanvisning

17 Oktober 2024
Café

Café CHP90302TSS Bruksanvisning

17 Oktober 2024
Café

Café CGY366P4TW2 Bruksanvisning

17 Oktober 2024
Café

Café CES700P2MS1 Bruksanvisning

17 Oktober 2024
Café

Café CGS700P3MD1 Bruksanvisning

17 Oktober 2024
Café

Café CEP90301TBB Bruksanvisning

13 Oktober 2024
Café

Café CTD90DP2NS1 Bruksanvisning

26 September 2024

Ugn Manualer

Nyaste Ugn Manualer

Taurus

Taurus HM778WHD Bruksanvisning

27 Oktober 2024
Lacanche

Lacanche CITEAUX Bruksanvisning

27 Oktober 2024
JennAir

JennAir JDS1450FS Bruksanvisning

27 Oktober 2024
Orima

Orima ORP-76-IN Bruksanvisning

27 Oktober 2024
Breville

Breville the Handy Hot Plate BHP150 Bruksanvisning

27 Oktober 2024
JennAir

JennAir JGRP436HL Bruksanvisning

27 Oktober 2024
Neff

Neff C17MS22G1 Bruksanvisning

27 Oktober 2024
Pit Boss

Pit Boss BK24 Bruksanvisning

27 Oktober 2024
Guzzanti

Guzzanti GZ-8206 Bruksanvisning

27 Oktober 2024
Avanti

Avanti DE2402SC Bruksanvisning

27 Oktober 2024
