BEFORE YOU BEGIN
Read these instructions completely and
carefully.
IMPORTANT Save these
instructions for local inspector’s use.
IMPORTANT Observe all
governing codes and ordinances.
Note to Installer Be sure to leave these
instructions with Consumer.
Note to Consumer Keep these
instructions for future reference.
Skill level Installation of this appliance
requires a qualified installer or electrician.
Proper installation is the responsibility
of the installer.
Product failure due to improper installation
is not covered under Warranty.
Product is for indoor use only.
Installation Instructions
27 & 30 Electric Built-In Wall Ovens
FOR YOUR SAFETY:
WARNING
Before beginning the installation, switch power off at the service panel and lock
the service disconnecting means to prevent power from being switched on accidentally. When the
service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
Be sure the oven is securely installed in a cabinet that is firmly attached to the house structure. Weight
on the oven door could cause the oven to tip and result in injury. Never allow anyone to climb, sit,
stand or hang on the oven door.
Make sure the wall coverings, counters and cabinets around the oven can withstand the heat (up to
200°F [93.3°C]) generated by the oven.
MATERIALS YOU MAY NEED
Junction Box
Wire Nuts
Strain Relief Clamp for 1/2” Conduit
36” (91 cm) of String
TOOLS YOU MAY NEED
1/8” Drill Bit and Electric or Hand Drill
T20 Screwdriver
Phillips Screwdriver
Wire Strippers
7/16” Nut Driver (combination ovens)
1/4” Nut Driver (30” combination ovens)
ATTENTION INSTALLER: All electric wall ovens must be hard-wired (direct-wired)
into an approved junction box. A plug and receptacle is NOT permitted on these products.
Questions? Call us at 1.800.432.2737 or visit GEAppliances.com.
In Canada, call 1.800.561.3344 or visit GEAppliances.ca.
1 REMOVE PACKAGING MATERIALS
Failure to remove packaging materials could result in damage to the appliance. Remove all
packing parts from oven, racks and heating elements. Remove protective film and labels on
the outer door and control panel. Also, remove plastic on trims and panel, all tape around the
oven and any shipping screws securing the oven to the base pad. Open oven door and remove
literature pack and oven racks. Remove the bottom trim from the top of the oven. It will be
installed at the end of the installation process. The trim is wrapped separately and taped to the top
of the unit. Remove pedestal rails from separate box and set aside (30” Double Wall Ovens Only).
Consider recycling options for your appliance packaging material.
2 PREPARE THE OPENING
NOTE: If the cabinet does not have a solid
bottom, two braces or runners must be
installed to support the weight of the oven.
For single ovens, the runners and braces
must support 220 lbs (99 kg). For double and
combination ovens, the runners and braces
must support 400 lbs. (181 kg).
NOTE: If marks, blemishes or the cutout
opening are visible above the installed oven,
it may be necessary to add wood shims
under the runners until the marks or opening
are covered.
NOTE: If the cabinet does not have a front
frame and the sides are less than ¾” (1.9 cm)
thick, shim both sides equally to establish the
cutout width.
DESIGN INFORMATION
SINGLE OVEN INSTALLATIONS
The single oven may be installed in a cabinet alone or above a warming drawer. The single oven
may also be installed side by side, below a countertop, or below specified cooktops. See the label
on top of the oven for approved models.
DOUBLE AND COMBINATION OVEN INSTALLATIONS
A double or combination oven may be installed in a cabinet alone or above a warming drawer.
See the label on top of the oven for approved models.
IMPORTANT: Always refer to individual installation instructions packed with each product for
specific requirements.
Suitable
Bracing
to Support
Runners
2" x 4" (5 cm x 10 cm)
or Equivalent Runners Level
with Bottom of Cutout
and Flush with Sides of Cutout
C
L
2 B CUTOUT FOR SINGLE OVENS UNDER COUNTER
NOTE: These ovens are only approved to be installed under the specific models as labeled on
the unit.
NOTE: One cooktop may be centered over either
oven in the side-by-side installation.
Cutout observe
all dimensions and
requirements.
2” (5.1 cm) Min.
30.5” (77.5 cm) 30” models
27” (68.58 cm) 27” models
Center Line Center Line
Side-by-Side Installations
Install two ovens in separate cutouts.
Cooktop
Cutout observe
all dimensions and
requirements.
Continue to Section 4.
Dimension Dimension Description 27” Single Oven 30” Single Oven
ACabinet Width 25” (63.5 cm) min.
251»4” (64.1 cm) max.
281»2” (72.4 cm) min.
285»8” (72.7 cm) max.
BCutout Height 275»8” (70.2 cm) min.
281»8” (71.4 cm) max.
271»4” (69.2 cm) min.
275»16” (69.4 cm) max.
CClearance from cutout - top* 1” (2.5 cm) 1” (2.5 cm)
(11»4(3.2 cm) for
PT9050
ZET1S and ZET1P)
DClearance from cutout - bottom* 1” (2.5 cm) 11»4(3.2 cm)
EClearance from cutout - side edges* 1” (2.5 cm) 11»16(1.75 cm)
FJunction Box Location 83»4” (22.2 cm) max.
right side only
91
»2(24.1 cm) max.
right side only
* Refers to minimum clearance required for wall oven installation and does not reflect actual product dimensions.
IMPORTANT: Maintain
a minimum distance
of 31-1/4” from the
top surface of the
countertop to the
wall oven platform to
ensure that the cooktop
and wall oven do not
interfere with each other
(see picture).
31-1/4” min.
(79.4 cm)
SIDE VIEW
Cooktop
Wall Oven
2-1/2” min. (6.4cm)
2 A CUTOUT FOR SINGLE OVENS IN WALL CABINET
NOTE: If the cabinet does not have a front frame and the sides are less than ¾(1.9 cm) thick,
shim both sides equally to establish the cutout width.
These ovens
are not
approved for
installations that
stack one single
wall oven above
another single
wall oven.
Cutout
observe all
dimensions and
requirements.
Cutout
observe all
dimensions and
requirements.
2” (5.1 cm) Min.
30.5” (77.5 cm)
30” models
27” (68.58 cm)
27” models
Center Line Center Line
Side-by-Side Installations
Install two ovens in separate cutouts.
B
F
GC
A
Cutout Location
from Floor
32-1/2” (82.6 cm)
H
P
R
D
E
Junction
Box
Location
(junction
box may
be located
in adjacent
cabinet)
Cutout Depth
23-1/2”
(59.7 cm) Min.
Opening
Between Inside
Walls Must be
at Least 28-1/2”
(72.4 cm) Wide
NOTE: Allow
1/4” (0.64 cm)
clearances from
side edges of
oven door.
Dimension Dimension Description 27” Single Oven 30” Single Oven
ACabinet Width 27” (68.6 cm) 30” (76.2 cm)
BCutout Width 25” (63.5 cm) min.
251»4(64.1 cm) max.
281»2(72.4 cm) min.
285
»8(72.7 cm) max.
CCutout Height 27
5»8” (70.2 cm) min.
281»8(71.4 cm) max.
271
»4(69.2 cm) min.
275
»16(69.4 cm) max.
D
Clearance from cutout - side edges*
1” (2.5 cm) 11»16 (1.75 cm)
EClearance to Adjacent Corners,
Drawers, Walls, etc., When Door
Is Open
23” (50.8 cm) min. 23” (53.3 cm) min.
FClearance from cutout - top* 1” (2.5 cm) min. 1” (2.5 cm) min.
(1 1»4(3.2 cm) for PT9050,
ZET1S and ZET1P)
GClearance from cutout - bottom* 1” (2.5 cm) min. 1
1»4” (3.2 cm)
HJunction Box Location 83»4” (22.2 cm) max.
right side only
91
»2(24.1 cm) max.
right side only
PJunction Box location 5-1/4(13.34 cm) max. 5-1/4(13.34 cm) max.
RJunction Box location 2-1/2(6.35 cm) max. 2-1/2(6.35 cm) max.
* Refers to minimum clearance required for wall oven installation and does not reflect actual product dimensions.
2 C CUTOUT FOR DOUBLE OVENS (2 THERMAL OVENS)
NOTE: If the cabinet does not have a front frame and the sides are less than ¾(1.9 cm) thick,
shim both sides equally to establish the cutout width.
2 D CUTOUT FOR COMBINATION OVENS
(WITH UPPER MICROWAVE OVEN)
NOTE: If the cabinet does not have a front frame and the sides are less than ¾(1.9 cm) thick,
shim both sides equally to establish the cutout width.
Dim. Description 27” Double Oven 30” Double Oven with
Pedestal 30” Double Oven without
Pedestal
ACabinet Width 27” (68.6 cm) 30” (76.2 cm) 30” (76.2 cm)
BCutout Width 25” (63.5 cm) min.
251
»4” (64.1 cm) max. 281»2(72.4 cm) min.
285»8(72.7 cm) max. 281»2(72.4 cm) min.
285»8(72.7 cm) max.
CCutout Height
4911»16(126.2 cm) min.
501»8(127.3 cm) max. 5113
»16(131.6 cm) min.
5115
»16(131.9 cm) max. 50 ¼” (127.64cm)
DClearance from cutout - side
edges* 1” (2.5 cm) 11
»16(1.75 cm) 11
»16(1.75 cm)
E
Clearance to Adjacent Corners,
Drawers, Walls, etc., When Door
Is Open
23” (50.8 cm) min. 23” (53.3 cm) min. 23” (53.3 cm) min.
FClearance from cutout - top* 1” (2.5 cm) min. 1” (2.5 cm) min.
(11
»4” (3.2 cm) for PT9550,
ZET2S and ZET2P)
1” (2.5 cm) min.
(11
»4” (3.2 cm) for PT9550,
ZET2S and ZET2P)
GClearance from cutout -
bottom* 1” (2.5 cm) min. 11
»4” (3.2 cm) 11
»4” (3.2 cm)
HJunction Box Location 8
3»4” (22.2 cm) max.
right side only 91
»2” (24.1 cm) max. right
side only 91
»2” (24.1 cm) max. right
side only
KCutout Location from Floor 13
1
»4” (33.7 cm) min. 12” (30.5 cm) min. 12” (30.5 cm) min.
PJunction Box location 5-1/4” (13.34 cm) max. 5-1/4” (13.34 cm) max. 5-1/4” (13.34 cm) max.
RJunction Box location 2-1/2” (6.35 cm) max. 2-1/2” (6.35 cm) max. 2-1/2” (6.35 cm) max.
Dim. Description
27” Oven
with Microwave
30” Oven
with Microwave
ACabinet Width 27” (68.6 cm) 30” (76.2 cm)
BCutout Width 25” (63.5 cm) min.
251»4” (64.1 cm) max.
281»2(72.4 cm) min.
285»8(72.7 cm) max.
CCutout Height 41
1»8(104.5 cm) min.
411
»4(104.8 cm) max.
423
»16(107.2 cm) min.
421
»4(107.3 cm) max.
DClearance from cutout -
side edges* 1” (2.5 cm) 11»16(1.75 cm)
E
Clearance to Adjacent Corners,
Drawers, Walls, etc., When Door
Is Open
23” (58.4 cm) min. 23” (58.4 cm)
FClearance from cutout - top* 1” (2.5 cm) min. 1” (2.5 cm) min.
GClearance from cutout -
bottom* 1” (2.5 cm) min. 1 1»4(3.2 cm)
HJunction Box Location 83
»4(22.2 cm) max.
right side only
91
»2(24.1 cm) max.
right side only
PJunction Box location 5-1/4” (13.34 cm) max. 5-1/4” (13.34 cm) max.
RJunction Box location 2-1/2” (6.35 cm) max. 2-1/2” (6.35 cm) max.
Continue to Section 3.
Continue to Section 2E.
PD
B
C
K
F
G
A
H
R
E
Junction Box
Location
(junction
box may
be located
in adjacent
cabinet)
Cutout Depth
23-1/2”
(59.7 cm) Min.
31-2000964 Rev. 2 03-24 GEA
* Refers to minimum clearance required for wall oven installation and does not reflect actual product dimensions.
* Refers to minimum clearance required for wall oven installation and does not reflect actual product dimensions.
H
R
P
NOTE: Allow
1/4” (0.64 cm)
clearances from
side edges of
oven door.
NOTE: Allow
1/4” (0.64 cm)
clearances from
side edges of
oven door.
