Thank you for choosing a Caliber product. In doing so you’ve demonstrated a
desire to own the finest in Car Audio Technology. Caliber strives to provide you
with the finest products possible, and is always looking for ways to please our
customers even more.
Properly installed, your Caliber amplifier will provide years of high quality sonic
reproduction. Before installing the amplifier in your vehicle, please read this enti-
re manual carefully, in order to protect your vehicle, and get the maximum per-
formance of your mobile sound system.
Caliber Warranty
Due to the complexity of our products, we strongly recommend that this ampli-
fier is installed by your authorized Caliber dealer. If properly installed by your
dealer we provide a warranty for 12 month from the date of purchase.
If you install this amplifier yourself, we wish you lots of fun and succes in doing
so. If you follow our guidelines, you’ll get the best result. Our warranty, however,
will be limited to and not exceed 30 days from the date of purchase.
Caliber Accessories
To r ealize the exceptional performance of which this amplifier is capable, it is
necessary that power sources, signal sources, speakers and interconnects are of
the highest quality. Remember that Caliber is not just an amplifier manufacturer.
We also manufacture everything needed for the ‘optimal’ Car Audio System
(except the car). So be sure to ‘Get Connected’ with Caliber and ask your local
Caliber dealer for our accessories.
Contents
Before you start your installation . . . . . . . . . . . . . . . . . . . . . .This page
Features and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mounting and Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Signal input/ -output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Speaker output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Equalizer adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Manuel de propriétaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Bedienungsanleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
BEFORE YOU START
F
D
All Caliber Competition Pro Series Amplifiers have the following specifications.
Variable specifications are listed per model.
Frequency response (+0, -1dB) 20Hz - 30kHz
Total Harmonic Distortion <0,05% with 80kHz LPF
Signal to noise ratio (A-Weighted) >95dB
Input Sensitivity RCA input 15V - 500mV
Input Impedance 20 kOhm
Damping Factor > 180
Output Impedance 2 - 8 Ohm
2-channel Amplifiers
Competition CA 130 Pro Series
Maximum Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 130W
4 Ohm 1kHz Mono Bridged 1x 260W
Continuous Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 65W
4 Ohm 1kHz Mono Bridged 1x 130W
Fuse Rating 20A
Dimensions (WxHxD mm) 200 x 60 x 235
Competition CA 190 Pro Series
Maximum Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 190W
4 Ohm 1kHz Mono Bridged 1x 380W
Continuous Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 95W
4 Ohm 1kHz Mono Bridged 1x 190W
Fuse Rating 25A
Dimensions (WxHxD mm) 250 x 60 x 235
Competition CA 250 Pro Series
Maximum Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 250W
4 Ohm 1kHz Mono Bridged 1x 730W
Continuous Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 125W
4 Ohm 1kHz Mono Bridged 1x 250W
Fuse Rating 2x 20A
Dimensions (WxHxD mm) 320 x 60 x 235
Due to our effort to innovate and improve our amplifiers, this modern generation
of Caliber Competition Pro Series amplifiers offers you the following features:
•Bridgeable outputs.
•’Tri-mode’ output capability, simultaneous stereo & bridged
mono set up is possible.
•Pulse Width Modulated (PWM) MOSFET Power Supply.
•2 Ohm stable (4 Ohm mono-bridged)
•Double sided epoxy board.
•Variable input sensitivity: 15V to 0.5V.
•Thermal-, Overload- and Shortcircuit protection.
•Excellent muting circuitry assures no turn on/off ‘pops’.
•Built-in 7 band equalizer for each channel.
•Built-in phase control for each channel
•Built-in adjustable HighPass/LowPass/FullRange Filter(s).
•Built-in subsonic filter adjustable 10-50Hz
•Differential inputs to shunt any input noise
•Signal output RCA’s for additional amplifier(s) (exept CA 670).
•Large power supply connectors for optimal power distribution.
•Chrome-plated speaker connectors for optimal signal output.
•European design and engineering.
•Superb Sonic Performance for your ‘Dream Machine’ on wheels.
•Years and years of acoustic pleasure.
Mounting your Caliber Amplifier
Before mounting your Caliber Amplifier you must carefully choose the place
where it can be installed.The amplifier has to have at least 5 cm (2”) ventilation
space at all sides, to allow the heat to rise away from the amplifier.
Be sure that the power and signal cables can enter and leave the amplifier in a
straight line, to avoid the risk of malfunction.
The amplifier should be protected from exposure to moisture and direct sun-
light.The best places for it to be mounted are:
• The floor of the trunk.
• Under the driver’s seat
• On your sub-woofer case.
If you’ve decided where to place your Caliber Amplifier, and you’ve convinced
yourself there is enough air circulation and protection from unusual hazards,
Mark the mounting surface using the amplifier as a template (Placing masking tape
on these surfaces first will make your markings more visible).
Drill 2.5 mm (1/8”) diameter holes at the marked locations and mount the
amplifier using the supplied self-tapping screws.
Note: Do not drill any holes while using the amplifier as a template.
You can easily damage the amplifier’s anodized coating in this
manner.
Competition CA 510 Pro Series
Maximum Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 510W
4 Ohm 1kHz Mono Bridged 1x1100W
Continuous Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 2x 255W
4 Ohm 1kHz Mono Bridged 1x 510W
Fuse Rating 4x 20A
Dimensions (WxHxD mm) 440 x 60 x 235
4-Channel Amplifiers
Competition CA 470 Pro Series
Maximum Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 4x 130W
4 Ohm 1kHz Mono Bridged 2x 260W
Continuous Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 4x 65W
4 Ohm 1kHz Mono Bridged 2x 130W
Fuse Rating 40A
Dimensions (WxHxD mm) 330 x 60 x 235
6-Channel Amplifier
Competition CA 670 Pro Series
Maximum Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 4x 90W+ 2x 130W
4 Ohm 1kHz Mono Bridged 2x 180W+ 1x 260W
Continuous Power Output at 14,4V
4 Ohm 20Hz - 30kHz THD 0,5% 4x 45W + 2x 65W
4 Ohm 1kHz Mono Bridged 2x 90W+ 1x 130W
Fuse Rating 25A + 20A
Dimensions (WxHxD mm) 400 x 60 x 235
