Sida 1/24
Key System Tuner CD/MP3/WMA BluetoothBT Audio
Short press long press Short press long press Short press long press Short press long press Short press long press
1Power Power off
2 Rotary Volume
3Menu (audio / system) OK
4 Panel release
5 Disc slot
6 Eject
7 LCD display
8 USB port
9Mode Mode Mode
10 Display
11 Mute Reject incoming
call/end call
12 AMS
13 Band Answer incom-
ming call
Transfer conver-
sation to mobile
phone
14 Seek down Manual down Track down fast backward Track down
15 Seek up Manual up Track up fast forward Track up
16 3,5mm AUX In Jack
17 M1 Store M1 Play/Pause Play/Pause
18 M2 Store M2 Intro
19 M3 Store M3 Repeat
20 M4 Store M4 Shufe
21 M5 Store M5 File down
22 M6 Store M6 File up
Description of the functions
Panel Release Push this button to release the frontpanel.
Eject (behind panel) Push this button to eject the CD out of the unit.
Power Power function to activate or deactivate the unit.
Band Band selection allows you to select different reception bands, f.i. FM1, FM2 and FM3
AF AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse.
TA TA stands for Trafc announcement which means that it will give you information about the trafc (if broadcasted) no matter what mode you are in (CD,USB, etc.) it will automatically interrupt the cd
and give the information, after that it automatically switches back to the selected mode
Manual up/down Hold rotary button to switch to manual radio frequency search (up/down step by step)
Menu (system) Press the VOL/SEL button for several seconds to activate the cyclical mode to choose from the following user instructions: DSP ON/OFF > ESP 12/45
(CD mode) > BEEP ON/OFF > AREA > VOL LAST/ADJ > SEEK. (rotate to adjust)
In DSP mode you can choose from preset EQ settings: FLAT, CLASSIC, POP, ROCK
Audio Menu The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader. These options can be used to ne tune your sound.
Mode The mode button allows you to go from one source (f.i. CD) to another source (f.i. Tuner) by pushing the button as many times as needed.
AMS AMS stands for Automatic store; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost.
Rotary volume This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears.
M1-M6 These are the preset stations where you can store your favorite radio stations if in tuner mode.
Pause/Play This button allows you in CD, USB or SD mode to play or to pause the music.
Repeat Repeat will play a selected song or album continuously. Available in CD, USB and SD mode.
Shufe Shufe will play all the songs random. Available in CD, USB and SD mode.
File down/up In MP3 mode press this button to go up or down one folder.
Track down/up In MP3 mode press this button to go up or down one track
fast forward/backward Long press to fast forward to the CD, USB or SD.
3,5mm AV jack in To connect an external audio system.
USB poort When inserting a USB stick the unit will switch to USB mode.
SD card input (behind panel) Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 16GB card)
Reset (behind panel) Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.
Bluetooth Open Bluetooth menu by pressing and holding “MENU” button
Pairing Activate BlueTooth on your mobile phone, and search for available devices. Select “Car Audio”, password “8888”. If succesfull “BT ON” is displayed.
Reconnect The unit will normally auto-reconnect.
Reject incomming call Press (MU) button if you not wish to answer the call, and return to normal playing mode.
Transfer To audio transfer from headunit back to the mobile phone. Long press the Transfer (BND) button to transfer the audio back to your mobile.
Inserting discs.
Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc.
Make sure the label side is facing up when you insert the disc. “Disc error” will be displayed on your
player if you insert a disc incorrectly. If “Disc error” continues to be displayed even though the disc
has been inserted correctly, push the RESET switch with a pointed object such as a ballpoint pen.
Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc
or damage the player.
Irregular shaped discs.
Be sure to use round shaped discs only for this unit and never use any special shaped discs. Use of
special shaped discs may cause damage to the mechanism.
new discs.
To prevent the disc from jamming, “Disc error” is displayed if discs with irregular surfaces are inserted
or if discs are inserted incorrectly. When a new disc is ejected immediately after initial loading, use
your nger to feel around the inside of the centre hole and outside edge of the disc. If you feel any
small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub
the inside edge of the hole and outside edge of the disc with a ballpoint pen or other such instrument,
then insert the disc again.
Installation location.
Make sure that the system will not be installed in a location subjected to:
• Direct sun and heat
• High humidity and water
• Excessive dust
• Excessive vibrations
Correct handling.
Do not drop the disc while handling. Hold the disc so you will not leave ngerprints on the surface. Do
not afx tape, paper, or gummed labels to the disc. Do not write on the disc.
Disc cleaning.
Fingerprints, dust, or soil on the surface of the disc could cause the DVD player to skip. For routine
cleaning, wipe the playing surface with a clean, soft cloth from the centre of the disc to the outer
edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent
before cleaning the disc.
Disc-accessoires
There are various accessories available on the market for protecting the disc surface and improving
sound quality. However, most of them will inuence the thickness and/or diametre of the disc. Using
such accessories can cause operational problems.
Playable discs
Mark Recorded content Disc-size
Music - CD Audio 12 cm
