Sida 1/18
Page CONTENTS
01 Contents
02 Installation
04 Using the detachable front panel
05 Wiring iagram
06 Operations
06
07 General perations
0 Radio perations
CD/MP3 perations
1 Mixed- CD perations
1 USB perations
13 SD/MMC ard perations
13 AUX in perations
1 Disc otes
1 Trouble hooting
1 Specifications
d
Location and function of controls
o
9 o
10 RDS (Radio Data System) operations
11 /WMA disc o
2 mode o
3 o
c o
put o
4 n
5 s
6
Notes:
- Choose the mounting location where the
unit will not interfere with the normal driving
function of the driver.
- Before finally installing the unit, connect
the wiring temporarily and make sure it is all
connected up properly and the unit and the
system work properly.
- Use only the parts included with the unit to
ensure proper installation. The use of
unauthorized parts can cause malfunctions.
- Consult with your nearest dealer if
installation requires the drilling of holes or
other modifications of the vehicle.
- Install the unit where it does not get in the
driver's way and cannot injure the
passenger if there is a sudden stop, like an
emergency stop.
- If installation ang e exceeds 30°from
horizontal, the unit might not give its
optimum performance
l
- Avoid installing the unit where it would be
subject to high temperature, such as from
direct sunlight, or from hot air, from the
heater, or where it would be subject to dust,
dirt or excessive vibration.
Din Front/Rear-Mount
This unit can be properly installed either
from 'Front' (conventional DIN Front-mount)
or 'Rear' (DIN Rear-mount installation,
utilizing threaded screw Holes at the sides
of the unit chassis). For details, refer to the
following illustrated installation methods.
Installing the unit
Be sure you test all connections first, and
then follow these steps to install the unit.
1. Make sure the ignition is turned off, and
then disconnect the cable from the vehicle
battery's negative (-) terminal.
5. The two supplied keys release tabs
inside the unit's sleeve so you can remove
it. Insert the keys as far as they will go (with
the notches facing up) into the appropriate
slots at the middle left and right sides of the
unit. Then slide the sleeve off the back of
the unit.
2. Disconnect the wire harness and the
antenna.
3. Press the OPEN button ( ) to fold dwon
the and remove
(For details, refer to 'using the detachable
front panel').
4. Lift the top of the outer trim ring then pull
it out to remove it.
front panel it from the unit.
Installation Opening
This unit can be installed in any dashboard
having an opening as shown below:
Installation
1. DIN FRONT-MOUNT (Method A)
53mm
182mm
Take Out Screw Before Installation
Before install the unit, please remove the
two screws.
