Caliber TWS100A Bruksanvisning

Caliber Hörlurar TWS100A

Läs nedan 📖 manual på svenska för Caliber TWS100A (8 sidor) i kategorin Hörlurar. Denna guide var användbar för 8 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/8
USER'S MANUAL
TWS100A True Wireless Earbuds
Thank you for purchasing Caliber product. Hope
you will have fun using it!
Please read this Quick Start Guide thoroughly
before using and keep it properly.
Earphones Overview
How to Use
Charging
indicator
Touch
Sensor
Area
1. Uncover the lid, the earbuds will power on automatically.
2. The LED indicator on Left earbud will flash blue or white
intermittentlyindicating the earbuds are in pairing mode now.
3. Turn on your smartphone's BT and search for "TWS100A" and
confirm to pair/connect.
4. Voice prompt "connected"
Power on
1. Take out the earphone and the
earphone will automatically
re-connect to the smartphone paired.
2. Long Press the touch sensor for 2
seconds to power on manually.
Power off
Put the earphones into the charging
box and the earphones will shut down
automatically.
Charging
Charging the earphones
Earphone light on during charging
100% Full charged, earphone lights go out
Charging the charging box
<25%
25%-50%
50%-75%
75%-100%
100%
Twinkle
Earphones Controls
* If there is no pairing / re-connection for 5 minutes, the
earphones will shut down automatically to save power
Function
Play/Pause
Skip forward
Skip backward
Answer a call
End a call
Reject call
Operation
Press 1 time the touch sensor area (left / right earphone)
Press 2 times the touch sensor area of the right earphone
Press 2 times the touch sensor area of the left earphone
Press 1 time the touch sensor area (left / right earphone)
Press 2 times the touch sensor area (left / right earphone)
Long press the touch sensor area (left / right earphone)
Press 3 times the touch sensor area
(left / right earphone)
Active Siri / Google
Assist
Product Specifications
Noise Reduction Depth
Bluetooth Version
Protocols Supported
Speakers
Transmission Range
Transmission Frequency
Charging Voltage
Earphone Charging Time
Charging Box Charging Time
Music Time
Gift Box Standby Time
Charging Box Battery Capacity
Earphone Battery Capacity
Single Earphone Weight
Product Net Weight
Waterproof Level
-22dB
5.0+EDR
HFP/HSP/A2DP/AVRCP
φ10mm10mm, 32Ω
10M (33 feets)
2.402GHz-2.480GHz
Max e.r.p: <20 mW / 13dBm
DC5V
About 1.5 hours
About 2 hours
About 5 hours
120 hours
450mAH
50mAH
5g
55g
IPX6 (only earphone)
ANC/Ambient/ANC
OFF(Not available
in single earbud
mode)
Long Press the touch senor area for 3 seconds,
(left / right earphone) to toggle between ANC on,
Ambient Sound, and ANC off
Please read the instructions thoroughly before using this product and retain it for future
reference.
Hearing Safety
hearing protection
• Do not wear earbuds with high volume for a long time to avoid damaging your
hearing.
• Set the earbuds to low volume before you put them on, then increase the volume
gradually as per your preference.
• Do not set volume too high to stay aware of your surroundings.
• Please refer to local laws and regulations if you want to answer phone calls via this
device during driving.
• For your safety, avoid distraction from music or phone calls when you are driving or
doing other activities with potential dangers.
Warning: Please set the volume to proper level to avoid hearing damages.
Caution
• Do not expose this product to high temperatures.
• Do not immerse the earbuds into water or expose them to humidity for a long time.
• Do not clean the product with detergent containing alcohol, ammonia, benzene or
abrasives.
• Avoid dropping.
• Place the earbuds back into the charging case when not in use and keep it away
from children and pets to avoid choking hazard.
• Unauthorized disassembly of any parts of this product is forbidden, which may
cause fire hazard, warranty voidance, and/or property loss.
• Close attention is needed when using near children.
• Keep the charging case away from water, rain or any other liquid.
GB Caliber hereby declares that the device TWS100A is in compliance
with the essential requirements and other relevant provisions of Directive
2014/53/EU RED and 2011/65/EU RoHS.
FR Par la présente Caliber déclare que l’appareil TWS100A est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive
2014/53/EU RED et 2011/65/EU RoHS.
DE Hiermit erklärt Caliber, dass sich das Gerät TWS100A in Übereinstimmung
mit den grundlegenden Anforderung und übrigen einschlägigen Bestimmungen der
Richtlinie 2014/53/EU RED und 2011/65/EU RoHS befi ndet.
NL Hierbij verklaart Caliber dat het toestel TWS100A in overeenstemming
is met de essentiële eisen en de andere relevante bepalingen van richtlijn
2014/53/EU RED en 2011/65/EU RoHS.
• Don’t use the product in thunderstorm to avoid malfunction or electric shock.
• Always ask a professional technician or authorized personnel for repair.
This product contains lithium battery. Never expose it to excessive heat such as
direct sunlight or fire to avoid explosion.
Please scan the QR-code for entire manual
Important
HANDLEIDING
TWS100A True Wireless Earbuds
Dank u voor de aankoop van Caliber producten.
Ik hoop dat u er veel plezier aan zult beleven!
Lees deze Snelstartgids voor gebruik aandachtig
door en bewaar hem goed.
Overzicht oortelefoons
Hoe te gebruiken
Opladen
indicator
Aanraking
Sensor
Gebied
1. Open het deksel, de oordopjes gaan automatisch aan.
2. De LED-indicator op de linkeroordop knippert met
tussenpozen blauw of wit om aan te geven dat de oordopjes nu
in de koppelstand staan.
3. Zet de BT van uw smartphone aan en zoek naar "TWS100A"
en bevestig om te koppelen/verbinden.
4. Stemmelding "verbonden"
Inschakelen
1. Neem de oortelefoon uit en de
oortelefoon wordt automatisch
opnieuw verbonden met de
gekoppelde smartphone.
2. Druk de aanraaksensor gedurende
2 seconden lang in om het toestel
manueel in te schakelen.
Uitschakelen
Stop de oortelefoon in het
oplaaddoosje en de oortelefoon zal
automatisch uitschakelen.
Opladen
Opladen van de oortelefoon
Oortelefoonlampje aan tijdens opladen
100% Volledig opgeladen, oortelefoon lichten gaan uit
Opladen van de oplaaddoos
<25%
25%-50%
50%-75%
75%-100%
100%
Twinkle

Produktspecifikationer

Varumärke: Caliber
Kategori: Hörlurar
Modell: TWS100A
