Sida 1/1

Service

Only

100 -240 V AC ~ 50/60 Hz

Power AC

Max Power Consum ption: 1 20W

Aux In RL Audi o In Optical In ARC

Optical In R LAudi o In Aux InARC

Vol (2secs)Learn

Learn Vol

Vol on TV remote

Learn Vol

Vol

on TV remote

To talk to us, call +44 (0)203 514 1521 (UK Local) or 1-877-357-8204 (USA)

TV CONNECTIONS

Only one audio connection to your TV is

required, in order of preference:

1. Optical: If available on your TV, use this for

best quality.

2. ARC: If your TV has a socket labelled ARC

use this connection.

3. RCA: Connect both left and right channels

to your TV.

4. AUX In: Connect to the headphone output

of your TV if neither ARC or optical are

available on your TV.

Note: If the 3.5mm socket is used it takes

priority over the RCA input which will be muted.

PLACEMENT! TV5 IS DESIGNED TO BE PLACED UNDER YOUR TV. THE TV MUST HAVE A BASE NO WIDER THAN 725MM

(28.5”) AND NO DEEPER THAN 300MM (12”) AND MUST WEIGH NO MORE THAN 30KG (66LBS). IF THE TV BASE IS TOO

LARGE TO FIT, PLACE TV5 ON A LOWER SHELF OF YOUR TV RACK

AUX Line in Optical in AC power socket ARC

TOP TIPS

TV5 TV speaker base with bluetooth

SOUND MODES

There are 4 dierent modes that can be selected to enhance your sound

experience. You can also Increase or decrease the Subwoofer output.

TV: Greatly improved TV sound.

Music: Enhances stereo music and music videos.

Film: Designed to get the best sound from movies.

Voice: Enhances voices to improve intelligibility.

AUTO POWER DOWN

To save power, TV5 will

automatically turn o after 20

minutes if no sound is playing

from your TV.

AUTO POWER ON

When you turn on your TV,

TV5 will detect the sound and

automatically turn on.

Once paired, music from your device will play

through the unit.

To add another Bluetooth device, repeat from

step 2. TV5 will store up to 8 paired devices

in memory.

LEARNING YOUR TV REMOTE

Remove the fabric grille and locate the

control panel. Follow the instructions

remembering to point your TV remote at the

control panel whilst learning.

BLUETOOTH SET-UP

TV5 is equipped with Bluetooth to allow

wireless playback from any Bluetooth

equipped phone, tablet or computer.

1. Select the Bluetooth input BT on the

remote.

2. To connect a Bluetooth device to TV5,

press and hold the BT button and the

Blue LED will blink.

3. Consult the instructions of the Bluetooth

device to connect to TV5. Successful

pairing will be signalled by a ‘beep’ from

the unit and the Blue LED will stop

ashing.

TV5 is only able to decode LPCM(PCM) 2.0 format signal, Please ensure your source output setting is set to LPCM(PCM).
