Sida 1/96
TO WATCH VIDEOS GO TO:
tinyurl.com/lgh5x3h
Contents
Preparation ......................................2-5
Assembly .......................................6-10
Installation ..................................11-28
Install the Door Control ............21-22
Install the Protector System® ....23-26
Connect power .........................27-28
Adjustments .................................29-31
MyQ® Smartphone Control .................32
Operation .....................................33-39
Using your Garage Door Opener .....34
To Open the Door Manually ...........34
Motion Detecting
Control Panel ...........................35-36
Multi-Function Control Panel .... 37-38
Remote Control .............................38
Homelink® ...................................38
To Erase the Memory .....................39
Maintenance .....................................40
Troubleshooting ...........................41-42
Accessories ........................................43
Warranty ...........................................44
Repair Parts ................................. 45-47
Owner’s Manual
B550C • B750C • B751C
Belt Drive
Garage Door Opener
FOR RESIDENTIAL USE ONLY
PRE-PROGRAMMED REMOTE CONTROL
INCLUDED
www.chamberlain.com
www.mychamberlain.com
Smart Garage Opener
• Please read this manual and the enclosed safety materials carefully!
• Fasten the manual near the garage door after installation.
• The door WILL NOT CLOSE unless the Protector System
® is connected
and properly aligned.
• Periodic checks of the garage door opener are required to ensure
safe operation.
• The model number label is located on the left side panel of your
garage door opener.
• This garage door opener is compatible with MyQ® and
Security+ 2.0® accessories.b
• DO NOT install on a one-piece door if using devices or features
providing unattended close. Unattended devices and features are
to be used ONLY with sectional doors.
2
Safety Symbol and Signal Word Review
This garage door opener hasbeen designed and tested to offer safe service provided it isinstalled,
operated, maintained and tested in strict accordance with the instructions and warningscontained in
this manual.
Mechanical
Electrical
When you see these Safety Symbolsand Signal
Words on the following pages, theywill alert you to
the possibility of serious injury or death if you do
not complywith the warningsthat accompany
them. The hazard may come from something
mechanical or from electric shock. Read the
warnings carefully.
When you see thisSignal Word on the following
pages, it will alert you to the possibilityof damage
to your garage door and/or the garage door
opener if you do not comply with the cautionary
statements that accompany it. Read them carefully.
WARNING: This product can expose you to chemicals including lead, which are known to the
State of California to cause cancer or birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
Unattended Operation
The Timer-to-Close (TTC) feature, the MyQ®Smartphone Control app, and MyQ®Garage Door and
Gate Monitor are examplesof unattended close and are to be used ONLY with sectional doors. Any
device or feature that allows the door to close without being in the line of sight of the door is considered
unattended close. The Timer-to-Close (TTC) feature, the MyQ®Smartphone Control, and any other
MyQ®devices are to be used ONLY with sectional doors.
Check the Door
To prevent possible SERIOUSINJURYor DEATH:
lALWAYS call a trained door systems technician if garage door binds,sticks, or is out of balance.
An unbalanced garage door may NOT reverse when required.
lNEVER try to loosen, move or adjust garage door, door springs, cables, pulleys, brackets or
their hardware, ALLof which are under EXTREME tension.
lDisable ALLlocks and remove ALLropesconnected to garage door BEFORE installation and
operating garage door opener to avoid entanglement.
lDO NOT install on a one-piece door if using devices or features providing unattended close.
Unattended devicesand features are to be used ONLY with sectional doors.
To prevent damage to garage door and opener:
lALWAYS disable locks BEFORE installing and operating the opener.
lONLY operate garage door opener at 120V, 60Hz to avoid malfunction and damage.
Before you begin:
1. Disable locks and remove any ropes connected to the garage door.
2. Lift the door halfway up. Release the door. If balanced, it should stay in
place, supported entirely by itssprings.
3. Raise and lower the door to check for binding or sticking. If your door
binds, sticks, or is out of balance, call a trained door systems
technician.
4. Check the seal on the bottom of the door. Anygap between the floor
and the bottom of the door must not exceed 1/4 inch (6 mm).
Otherwise, the safety reversal system may not work properly.
5. The opener should be installed above the center of the door. Ifthere is
a torsion spring or center bearing plate in the way of the header
bracket, it may be installed within 4feet (1.2 m) to the left or right of the
door center. See page 12.
Torsion
Spring
Extension
Spring
OR
Preparation
3
Test the Wi-Fi®Signal Strength in your garage
You will need a router with Wi-Fi and a smartphone or other mobile device. Make sure your mobile
device is connected to your Wi-Fi network. Hold your mobile device in the place where your garage
door opener will be installed and check the Wi-Fi signal strength.
Wi-Fi signal is weak.
The garage door opener will connect to your Wi-Fi likely
network. If not, try one of the options below.
No Wi-Fi signal. Try one of the following:
• Move your router closer to the garage door opener to
minimize interference from walls and other objects
• Buy a Wi-Fi range extender
• Buy a Chamberlain MyQ ® Internet Gateway (CIGBUC) see page 40
Check Signal Strength. If you see:
Wi-Fi signal is strong. You’re all set!
Install your new garage door opener.
Visit wifihelp.chamberlain.com for more details
See MyQ®Smartphone Control page 32 to connect your garage door opener to your Wi-Fi network.
Additional Items You May Need:
Survey your garage area to see if you will need anyof the following items:
l(2) 2X4 Pieces of wood : May be used to fasten the header bracket to the structural supports.
Also used to position the garage door opener during installation and for testing the safety
reversing sensors.
lSupport bracket and fastening hardware: Must be used if you have a finished ceiling in your
garage.
lExtension brackets (MODEL 041A5281-1) or wood blocks: Depending upon garage
construction, extension brackets or wood blocks may be needed to install the safety reversing
sensor.
lFastening hardware: Alternate floor mounting of the safety reversing sensor will require
hardware not provided.
lDoor reinforcement: Required if you have a lightweight steel, aluminum, fiberglassor glass
panel door.
lRail extension kit: Required ifyour garage door is more than 7 feet (2.13 m) high.
Tools Needed
3/16
7/16
1/2
5/32
5/16
5/8
9/16
1/4
7/16
Preparation
