Pre-Purchase Checklist
Chamberlain® Wall Mount
Garage Opener
1
POWER
An electric outlet must be accessible within a 6-foot (1.83 m) diameter
of the installation area for the opener. The outlet must be 120 VAC/60 Hz ONLY.
Contact a qualified electrician if you need an outlet installed.
SECTIONAL GARAGE DOOR
• Standard sectional door up to 14 feet (4.3 m) high.
• Sectional high-lift door (up to 54 inches [137.2 cm] of high lift).
• Doors up to 18 ft. (5.5 m) wide.
• Doors up to 180 sq. ft. (16.7 sq. m).
• Any gap between the floor and the bottom of the door must not exceed
1/4 inch (6 mm). Otherwise, the safety reversal system may not work properly.
DRUMS AND PREVIOUS OPENER
• Drums have a diameter of 4–6 inches (10–15 cm).
• 3- to 3.9-inch (7.6 cm to 9.9 cm) drums may be used on doors up to 430 lbs.
(195.4 kg).
• Previously installed garage door opener has been removed completely.
TORSION BAR AND TORSION SPRINGS
• Torsion bar is 1 inch (2.5 cm) in diameter.
• Torsion bar must extend at least 1-1/2 inches (3.81 cm) past the bearing plate
and be free of damage.
• Distance between ceiling and center of torsion bar is 3 inches (7.6 cm) or more.
• Distance between garage wall that the torsion bar is mounted on and center of
torsion bar is 2-1/2 inches (6.4 cm) or more.
• A minimum of 8.5 inches (21.6 cm) between the side garage wall (or obstruction)
and the end of the torsion bar.
ALL the requirements listed above MUST be met. If your door does not meet
these criteria, you must install a dierent model of opener. If your torsion bar,
power source and/or drums do not meet the requirements, please contact a
trained door systems technician.
READ FIRST
Before purchasing, please check your garage for the following specic features
to ensure safe installation and operation of the Chamberlain Wall Mount Garage
Opener. The unique space-saving design of the Garage Opener makes it a smart
solution for most garages.
IIMPORTANT! If you DO NOT meet all the requirements, contact a trained door systems technician.
LED Light to brighten
your entire garage
(sold separately).
To reduce the risk of injury to persons, ONLY enable Timer-to-Close and myQ®
remote operation features when operator is installed on a sectional door.
WARNING
Pliers Wire Cutters
Wire Strippers
Claw Hammer
Screwdriver
Level
3/8" Open End Wrench
1/4", 5/16" and 3/8" Sockets
and Wrench with 6" Extension
Drill Tape Measure
Stepladder
Pencil
Needle Nose Pliers
5/32", 3/16", 5/16"
and 3/4" Drill Bits
Chamberlain® Wall Mount
Garage Opener RJO101
Term Denition
Bearing Plate Acts as a support for the torsion bar. The bearing plate is typically located above the garage door.
Door Seal The door seal is located at the bottom of the door and helps to keep outdoor elements from entering the
garage.
Drum Drums are round, grooved spools on the torsion bar that keep door cables orderly.
Extension
Springs
Extension springs are NOT compatible with this opener. Extension springs are typically mounted along
the horizontal section of the track and extend from the front of the door opening to the back hang.
The springs are intended to make a door lighter so you can easily open and close the door by hand.
High-Lift
Sectional Door
A type of garage door constructed with multiple panels that slide along a track inside the garage.
The track runs vertically up the wall beyond the top of the door opening several inches before
encountering the curve in the track. The extended distance above the top of the garage door
determines the amount of a high lift.
Protector
System®
The Protector System is composed of a set of sensors and transmitters that act as a safety measure
to prevent personal injury or property damage caused by a closing garage door.
See also: Safety Reversing Sensor.
Roller Small wheels that allow the door to move up and down the track.
Safety
Reversing
Sensor
The safety reversing sensors are a set of sensor eyes that detect obstructions in the path of the garage
door. If an obstruction is found, the sensors tell the door to reverse direction.
Torsion
Springs
A torsion spring is a type of spring that counterbalances the garage door. The torsion spring is located above
the door on the torsion bar. The springs are intended to make a door lighter so you can easily open and close
the door by hand. Consult a trained door systems technician if you need the springs adjusted or replaced.
Torsion Bar
A torsion bar is a horizontal metal bar mounted above the garage door. The torsion springs are located
on the torsion bar. Most torsion bars are hollow, but some are solid. Some solid torsion bars may have
a groove called a keyway that runs the length of the bar.
GLOSSARY
© 2023 The Chamberlain Group LLC. All Rights Reserved. Chamberlain, the Chamberlain logo, myQ and the myQ logo are registered trademarks of The Chamberlain Group LLC. | RET581862 0323
TOOLS REQUIRED
