Installation Manual
Chain Drive Garage Door Opener
Models C2405C • D2405C • C2102C •
C2202C • D2101C
FOR RESIDENTIAL USE ONLY
PRE PROGRAMMED REMOTE
CONTROL INCLUDED
To register your garage door opener to receive updates and oers
from Chamberlain, visit chamberlain.registria.com or use the icon
below:
1. Take a photo of the camera icon including
the points ( ).
2. Send it in by texting the photo to 71403 (US).
• Please read this manual and the enclosed safety materials carefully!
• Fasten the manual near the garage door after installation.
• The door WILL NOT CLOSE unless the Protector System® is connected and properly aligned.
• Periodic checks of the garage door opener are required to ensure safe operation.
• The model number label is located on the back panel of your garage door opener.
• This garage door opener is compatible with myQ® and Security+ 2.0® accessories.
• DO NOT install on a one-piece door if using devices or features providing unattended close. Unattended devices
and features are to be used ONLY with sectional doors.
Unattended Operation
The Timer-to-Close (TTC) feature, the myQ® App, and myQ® Garage Door and Gate Monitor
are examples of unattended close and are to be used ONLY with sectional doors. Any device or
feature that allows the door to close without being in the line of sight of the door is considered
unattended close. TheTimer-to-Close (TTC) feature, the myQ®App, and any other myQ®
devices are to be used ONLY with sectional doors.
The images throughout this manual are for reference only and your product may
look different.
Contents
Preparation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Install the Door Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Install the Protector System® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Connect Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Adjustments � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 31
myQ® App Control � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 34
Connect With Your Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Operation� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 38
Using your Garage Door Opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using your Door Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Remote Control and Keyless Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Home Link® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Erase the Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
To Open the Door Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 39
Troubleshooting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 40
Warranty � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 42
Automatic Garage Door Opener Safety & Maintenance Guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 43
Repair Parts � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 45
Rail Assembly Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Installation Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Model C2102C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Model C2405C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Model D2405C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Model C2202C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Model D2101C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Safety Symbol and Signal Word Review
This garage door opener has been designed and tested tooffer safe service provided it is
installed, operated, maintained and tested in strict accordance with the instructions and
warnings contained in this manual.
Mechanical
Electrical
When you see these Safety Symbols and Signal Words on the following pages, they will
alert you to the possibilityof
serious injuryor death
if you do not comply with the warnings that
accompany them. The hazardmay come from something mechanical or from electric shock.
Read the warnings carefully.
When you see this Signal Word on the following pages, it will alert you to the possibility
of damage to your garage door and/or the garage door opener if you do not comply with
the cautionary statements that accompany it. Read them carefully.
WARNING:
This product can expose you to chemicals including lead, which are known to
the State of California to cause cancer or birth defects or other reproductive harm. For
more information goto
www.P65Warnings.ca.gov
2
Preparation
Preparation
Check the Door Before You Connect with Your Smartphone
Monitor and control your garage door from anywhere using the myQ® App. You will need
a router with Wi-Fi® and a smartphone or other mobile device. Make sure your mobile
device is connected to your Wi-Fi® network. Hold your mobile device in the place where
your garage door opener will be installed and check the Wi-Fi®
signal strength.
Check Signal Strength. If you see:
Visit support.chamberlaingroup.com for more details.
See myQ® App Control page 37 to connect your garage door
opener to your Wi-Fi® network.
Wi-Fi signal is strong. You’re all set!
Install your new garage door opener.
Wi-Fi signal is weak.
The garage door opener will likely connect to your Wi-Fi
network. If not, try one of the options below.
No Wi-Fi signal. Try one of the following:
• Move your router closer to the garage door opener
to minimize interference from walls and other objects
• Buy a Wi-Fi range extender
Before you begin:
1. Disable locks and remove any ropes connected to the garage door.
2. Lift the door half way up. Release the door. If balanced, it should stay in place, supported
entirely by its springs.
3. Raiseand lower the door to checkfor binding or sticking. If your door binds, sticks, or is out
of balance, call atrained door systems technician.
4. Checktheseal on thebottomof thedoor. Any gap between theoor and the bottom of
thedoor must not exceed 1/4” (6 mm). Otherwise, the safety reversal system may not
workproperly.
5. Theopener should be installed above the center of thedoor. If thereis atorsion spring
or center bearing platein theway of the header bracket, it may beinstalled within 4 feet
(1.2m) totheleft or right of thedoor center. See page 13.
To prevent possible SERIOUS INJURY or DEATH:
ALWAYS call a trained door systems technician if garage door binds, sticks, or is out of
balance. An unbalanced garage door may NOT reverse when required.
NEVER try to loosen, move or adjust garage door, door springs, cables, pulleys, brackets
or their hardware, ALL of which areunder EXTREME tension.
Disable ALL locks and remove ALL ropes connected to garage door BEFORE installation
and operating garage door opener to avoid entanglement.
DO NOT install on a one-piece door if using devices or features providing unattended close.
Unattended devices and features are to be used ONLY with sectional doors.
To prevent damage to garage door and opener:
ALWAYS disable locks BEFOR Einstalling and operating the opener.
ONLY operate garage door opener at 120V, 60 Hz to avoid malfunction and damage.
3
