The Chamberlain Group, Inc.

845 Larch Avenue

Elmhurst, Illinois 60126-1196

www.chamberlain.com

CONTENTS

Preparation .............................. 1-4

Assembly ................................. 5-9

Installation ............................ 10-19

Install the Door Control ............. 20-21

Install the Protector System® ...... 22-25

Power .................................. 26-27

Adjustments .......................... 28-30

Operation.................................. 31

Features ................................... 32

Door Control .......................... 33-34

Remote Control ...................... 34-35

To Erase the Memory .................... 35

To Open the Door Manually ............ 36

Maintenance .............................. 37

Troubleshooting ...................... 38-39

Accessories ............................... 40

Warranty .................................. 41

Repair Parts .......................... 42-43

3/4 hp Chain Drive

Garage Door Opener

Please read this manual and the enclosed safety materials carefully!

Fasten the manual near the garage door after installation.

The door WILL NOT CLOSE unless the Protector System® is connected and

properly aligned.

Periodic checks of the garage door opener are required to ensure safe operation.

The model number label is located on the left side panel of your garage

door opener.

This garage door opener is compatible with MyQ ® and Security 2.0™ accessories.

Only enable the Timer-to-Close or MyQ® remote operation feature when the garage

door opener is installed on a sectional door.

Serial Number:

Date of Purchase:

Model PD752KEV

FOR RESIDENTIAL USE ONLY

Write down the following information

for future reference:

Safety Symbol and Signal Word Review

This garage door opener has been designed and tested to offer safe service provided it is installed,

operated, maintained and tested in strict accordance with the instructions and warnings contained in this

manual.

When you see these Safety Symbols and Signal Words on the following pages, they will alert you to the

possibility of serious injury or death if you do not comply with the warnings that accompany them. The

hazard may come from something mechanical or from electric shock. Read the warnings carefully.

Mechanical

Electrical

When you see this Signal Word on the following pages, it will alert you to the possibility of damage to

your garage door and/or the garage door opener if you do not comply with the cautionary statements that

accompany it. Read them carefully.

Check the Door

To prevent possible SERIOUSINJURYor DEATH:

• ALWAYS call a trained door systems technician if garage door binds, sticks, or is out of balance.

An unbalanced garage door may NOT reverse when required.

• NEVER try to loosen, move or adjust garage door, door springs, cables, pulleys, brackets or their

hardware, ALLof which are under EXTREMEtension.

• Disable ALLlocks and remove ALLropes connected to garage door BEFORE installation and

operating garage door opener to avoid entanglement.

To prevent damage to garage door and opener:

• ALWAYS disable locks BEFORE installing and operating the opener.

• ONLY operate garage door opener at 120 V, 60 Hz to avoid malfunction and damage.

1. Disable locks and remove any ropes connected to the garage door.

2. Lift the door halfway up. Release the door. If balanced, it should

stay in place, supported entirely by its springs.

3. Raise and lower the door to check for binding or sticking. If your

door binds, sticks, or is out of balance, call a trained door systems

technician.

4. Check the seal on the bottom of the door. Any gap between the

floor and the bottom of the door must not exceed 1/4 inch (6 mm).

Otherwise, the safety reversal system may not work properly.

5. The opener should be installed above the center of the door. If

there is a torsion spring or center bearing plate in the way of the

header bracket, it may be installed within 4 feet (1.2 m) to the left or

right of the door center. See page 13.

Torsion

Spring

Extension

Spring

Preparation

Additional Items You May Need:

Survey your garage area to see if you will need any of the following items:

nn (2) 2X4 PIECES OF WOOD

May be used to fasten the header bracket to the structural supports. Also used to position the

garage door opener during installation and for testing the safetyreversing sensors.

nn SUPPORT BRACKET AND FASTENING HARDWARE

Must be used if you have a finished ceiling in your garage.

nn EXTENSION BRACKETS (MODEL 041A5281-1) OR WOOD BLOCKS

Depending upon garage construction, extension bracketsor wood blocks may be needed to

install the safety reversing sensor.

nn FASTENING HARDWARE

Alternate floor mounting of the safety reversing sensor will require hardware not provided.

nn OUTSIDEQUICKRELEASE (MODEL 7702CB)

Required for a garage with NO access door.

nn DOOR REINFORCEMENT

Required if you have a lightweight steel, aluminum, fiberglass or glass panel door.

nn RAIL EXTENSION KIT

Required if your garage door is more than 7 feet (2.13 m) high.

Tools Needed

3/16

7/16

1/2

5/32

5/16

5/8

9/16

1/4

7/16

Preparation
