Champion WorkHorse 40916 Bruksanvisning

Champion Inte kategoriserad WorkHorse 40916

Läs nedan 📖 manual på svenska för Champion WorkHorse 40916 (24 sidor) i kategorin Inte kategoriserad. Denna guide var användbar för 12 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Sida 1/24
WORKHORSE
AUTO-FEED TRAP
Part No. 40916
Instruction Manual
WARNING: THIS MACHINE CAN CAUSE SERIOUS INJURY OR DEATH!
THOROUGHLY READ INSTRUCTIONS BEFORE INSTALLING OR OPERATING TRAP!
Table of Contents
Section Page
I. Introduction 1
II. Safety 2
III. Required Tools 4
IV. Assembly and Installation 4
1. Unpacking 4
2. Contents 5
3. Assembly 7
A. Assemble Legs 7
B. Install Mainspring 8
C. Attach the Throwing Arm Path Indicator 9
D. Attach the Magazine 10
E. Setup 10
V. Operation 11
VI. Adjustments 12
1. Throwing Arm Limit Switch 12
2. Elevation Adjustment 14
3. Distance Adjustment 15
VII. Transportation and Storage 16
VIII. Troubleshooting 17
IX. Maintenance 18
X. Replacement Parts 18
XI. Warranty Information 19
XII. Contact Information 20
