GARDEN SEEDER Assembly / Operation Instructions / Parts
CHAPIN INTERNATIONAL, INC. P.O. BOX 549 700 ELLICOTT ST. BATAVIA, NY 14021-0549 www.chapinmfg.com 800-950-4458
MODEL 84000
Carefully Read These Instructions Before Use
WARNING
Please call 800-950-4458
if you are missing any parts, having trouble assembling, or have any
questions regarding the safe operation of this product.
DO NOT RETURN TO THE STORE.
013518 R0514
1E
WARNING
IMPROPER USE OR FAILURE TO FOLLOW INSTRUCTIONS CAN RESULT IN
PRODUCT FAILURE OR INJURIES. FOR SAFE USE OF THIS PRODUCT YOU MUST
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING.
WARNING: Handling the brass parts of this product will expose you to lead, a chemical known to the State
of California to cause birth defects and other reproductive harm. Wash hands after handling.
Assembly Notes
• This Garden Seeder comes partially assembled. You will be required to assemble the handle and row marker
to the hopper and wheel assembly.
• Before you begin assembly please lower the kickstand
at the front of the garden seeder to keep it steady
during assembly.
ASSEMBLY INSTRUCTIONS
1. Assemble Bottom Handle to Hopper/Wheel Assembly
Remove bottom 2 nuts and
bolts from hopper/wheel
assembly.
1A 1B
Line up handle bottom and replace bottom nuts and bolts, and
add top 2 nuts and bolts (included in bag) and tighten down
with wrench.
Check to see that you have all necessary parts:
2. Assemble Handle Cross Bar
3. Row Marker Assembly
Remove nut from row marker
pole (leave spring and washers
attached to bolt).
3A
2E
2A 2B 2C
Slide handle cross bar through
hole at top of handle bottom.
Center and tighten thumb
screw.
Attach foam grips (included in
bag).
3B 3C
Slide pole through hole in
bracket at the back of the
hopper and secure with the nut.
Attach row marker clip to top of
handle (below cross bar).
Lock row marker into clip.
3D
4. Row Marker Blade Assembly
Remove wing nut from
carriage bolt.
4A 4B 4C
Slide blade onto row marker
pole. Set length to proper row
spacing.
Secure bolt with wing nut.
Clip
Row
Marker
