Sida 1/36

Operat Manualor's

Printed Matter No. 8940163475

Date: 2019-01 Issue No. 05

Random Orbital Sander

Valid from Serial No. 00001 - 99999

WARNING

To reduce risk of injury, everyone using, installing, repairing, main-

taining, changing accessories on, or working near this tool MUST

read and understand these instructions before performing any such

task.

DO NOT DISCARD - GIVE TO USER

CP7215 SERIES

CP7225 SERIES

CP7255 SERIES

EN Random orbital Sanders

2© Chicago Pneumatic - 8940163475

CP7215 CP7215E CP7215CV CP7215SV CP7215SVE CP7215CVE

Free speed(rpm) 12000 12000 12000 12000 12000 12000

Power(hp) 0.3 0.3 0.3 0.3 0.3 0.3

Power(W) 210 210 210 210 210 210

Spindle thread 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24

Actual air con-

sumption(l/s)

7.6 7.6 7.6 7.6 7.6 7.6

Actual air con-

sumption(cfm)

16 16 16 16 16 16

Min. hose size(") 3/8 3/8 3/8 3/8 3/8 3/8

Min. hose

size(mm)

10 10 10 10 10 10

Weight(lb) 1.74 1.74 1.83 1.84 1.84 1.83

Weight(kg) 0.79 0.79 0.83 0.82 0.82 0.83

CP7225 CP7225CV

CP7225CVE-

3 CP7225CVE CP7225E CP7225SV CP7225SVE

Free speed(rpm) 12000 12000 12000 12000 12000 12000 12000

Power(hp) 0.3 0.3 0.3 0.3 0.3 0.3 0.3

Power(W) 210 210 210 210 210 210 210

Spindle thread 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24

Actual air con-

sumption(l/s)

7.6 7.6 7.8 7.6 7.6 7.6 7.6

Actual air con-

sumption(cfm)

16 16 16.5 16 16 16 16

Min. hose size(") 3/8 3/8 3/8 3/8 3/8 3/8 3/8

Min. hose

size(mm)

10 10 10 10 10 10 10

Weight(lb) 1.74 1.83 1.45 1.83 1.74 1.84 1.84

Weight(kg) 0.79 0.83 0.66 0.83 0.79 0.82 0.82

CP7255 CP7255E CP7255SV CP7255SVE CP7255CVE-3 CP7255CVE

Free speed(rpm) 12000 12000 12000 12000 12000 12000

Power(W) 210 210 210 210 210 210

Power(hp) 0.3 0.3 0.3 0.3 0.3 0.3

Spindle thread 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24 5/16-24

Min. hose

size(mm)

10 10 10 10 10 10

Min. hose size(") 3/8 3/8 3/8 3/8 3/8 3/8

Actual air con-

sumption(l/s)

7.6 7.6 7.6 7.6 7.8 7.6

Actual air con-

sumption(cfm)

16 16 16 16 16.5 16

Weight(kg) 0.79 0.79 0.82 0.82 0.66 0.83

Weight(lb) 1.74 1.74 1.84 1.84 1.45 1.83

Random orbital Sanders EN

1/2" (12mm)

LUBRICATOR

REGULATOR

1/4"NPT FILTER

1/2" (12mm)

3/8" (10mm)

130
