CSM-SERIES
MIXING CONSOLES
Item ref: 170.871 , 170.8 , 170.873UK UK 72UK
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warran ty
CSM-series User Manual
Introduction
Thank you for oosing a M compact mixing console as part of your professional sound system. This product has been ch CS
developed to provide a wide range of facilities for professional and reliable sound reinforcement. Please read and keep
this manual to achieve the best results from your purchase and avoid damage through misuse.
Package Contents
• CSM compact mixing console
• Mains power adaptor
• User manual
If you find any accessory is missing or the product has arrived with any problems, please contact your retailer at once.
This product contains no user-serviceable parts, so make no attempt to try to fix or modify this item yourself as this will
invalidate the warranty. We recommend you keep the original package and proof of purchase for any possible
replacement or retur issues. n
Warning
To prevent the risk of fire or electric shock, do not expose any of the components to rain or moisture.
Avoid impact or heavy vibration to any of the components.
No user serviceable parts inside - fer servicing to qualified service personnel. re
Safe ty
• Please observe the following warning conventions
CAUTION: RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit
This symbol indicates that there are important operating and maintenance instructions in the literature
accompanying this unit.
• Ensure that the correct mains lead is used with adequate current rating and mains voltage is as stated on the unit
• Avoid ingress of water or particles into any part of the housing If liquids are spilled on the console, stop using .
immediately, allow the unit to dry out and have checked by qualified personnel before further use
• Do not cover or obstruct cooling vents
Warning: this unit must be earthed
Placement
• Keep the console out of direct sunlight and away from heat sources.
• Do not place heavy objects on top of the control surface
• Allow adequate space for air-flow and keep the console away from damp or dusty environments.
Cleaning
• Use a soft dry or slightly damp cloth top clean surfaces of the console
• A soft brush can be used to clear debris from between controls without damaging them
• To avoid damage, do not use solvents to clean the components
CSM-series User Manual
Console layout
Each M compact mixing nsole s a bank of CS co ha
mono input channels which can accept a balanced
microphone input or switchable line/instrument
input. There is also a stereo input for playback
devices or line level instruments.
All preamps have studio grade, low noise
architecture for the cleanest possible path
throughout the signal chain. Console layout is set
out in distinct sections to simplify operation.
The following pages of this manual are divided up
into these stages to explain the details and function
of each control.
Channel inputs
Channel inputs are provided as XLR or 6.3mm jack on combo sockets.
If an XLR is plugged in, this will be connected as low impedance (microphone) level.
If a 6.3mm plug is used, this will be connected as either line or instrument level (swit ble) cha
The connections for these inputs are assigned as follows.
Mic / Line / Instrument input
1. Combo input Connect balanced microphone via XLR connection a
or a e level or instrument input via 6.3mm plug.lin
An unbalanced XLR can be connected provided
that 8V phantom power not used. Wired as follows. +4 is
2. IMPED switch Press this button in to set the input impedance to instr level or leave the button ument
in the up position fo line level inpu (instrument level is usually for pickups, such r a t.
as those on a guitar. Electronic keyboards usually produce a line level output)
3. +48V phantom Press this button in to enable +48V phantom power to the XLR the LED indicato and r
will light. This provides power to me condenser microphones and DI boxes. so
Do not use with unbalanced XLR connectors. This does not affect jack inputs. any
Balanced
Pin 1 = Ground
Pin 2 = Signal +
Pin 3 = Signal –
Unbalanced
Pin 1 = Ground
Pin 2 = Signal +
Pin 3 = Ground
