Sida 1/16
MX141M Manual v1.0
MX141M
5CH MIXER/MEDIA PLAYER
CONTRACTOR SERIES
MANUAL
HF
MASTER LEVEL
MEDIA MIXER
MX
141M
LF
HF
LF
UP
[STORE]
FILE
FOLDER
[STATION]
TRANSPORT
GAIN EQ EQ
-10 -6 -3 0 +5
OUTPUT (dB)
FOH
DATA
MODE
POWER
AUX
CH 4
1
MIC 1 ON
3 4
IR
USB
SOURCE SEQ
SOURCE 4
BLUETOOTH
AERIAL
MX141M Manual v1.02
Thank you for choosing Cloud Contractor Series for your sound system. To make sure that this product meets your expectations
and provides long-term, reliable performance, please read and follow this instruction manual carefully.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions and all markings on the product. Keep these instructions.
• Heed all warnings and instructions, both in this manual and on the product.
• Clean only with a dry cloth. Unplug from AC supply before cleaning.
• Do not use this product near water and avoid any exposure to water.
• Before connecting this product to any AC supply, make sure you check whether the AC mains voltage and frequency
match the indication on the product and its packaging.
• 2QO\FRQQHFWWKLVSURGXFWWRDQ$&VXSSO\ZLWKVXIÀFLHQWSRZHUKDQGOLQJSURWHFWLYHHDUWKFRQQHFWLRQJURXQGIDXOW
(earth-fault) protection and overload protection.
• Disconnect the product from the AC supply during thunderstorms. Also disconnect from the mains supply if the product
is not being used for long periods.
• 0DNHVXUHDQ\KHDWVLQNRURWKHUFRROLQJVXUIDFHRUDQ\DLUFRQYHFWLRQVORWLVH[SRVHGVXIÀFLHQWO\WRIUHHDLUFLUFXODWLRQ
and is not blocked.
• Do not operate this product in environmental temperatures exceeding 35 degrees Celsius and/or 85% relative humidity.
• Position the product in a safe and stable place for operation, out of reach of unauthorized persons.
• Make sure any cable connections to and from the product are neither subject to potentially destructive mechanical
impact nor present any risk of stumbling or other accident risk to people.
• $XGLRHTXLSPHQWPD\JHQHUDWHVRXQGSUHVVXUHOHYHOVVXIÀFLHQWWRFDXVHSHUPDQHQWKHDULQJGDPDJHWRSHUVRQV$OZD\V
start up at low volume settings and avoid prolonged exposure to sound pressure levels exceeding 90 dB.
• Do not open this product for service purposes. There are no user-serviceable parts inside.
• Warranty will be void in any case of unauthorized service by the user or other unauthorized persons.
• Take any precaution required by local law, applicable regulations or good business practice to avoid injury to people or
material damage by use of this product.
Explanation of symbols used in this manual and on the product:
ATTENTION!
Read manual
before installation
and operation.
DANGER!
Safety hazard.
Risk of injury or death.
WARNING!
Hazardous voltage.
Risk of severe or fatal
electric shock.
WARNING!
Fire hazard.
MX141M Manual v1.0 3
Overview
General
The MX141M combines a 5-channel audio mixer for stereo music sources and a microphone with a on-board media player,
Bluetooth® wireless technology, an FM tuner and an IR remote control. It is perfect for applications where foreground or
EDFNJURXQGPXVLFLVPL[HGZLWKYRFDODQQRXQFHPHQWVDVIUHTXHQWO\RFFXUVLQÀWQHVVDQGKRVSLWDOLW\DSSOLFDWLRQV
Health advice
This unit produces and absorbs electromagnetic radiation. The strength of radiation and the sensitivity for disturbing interference
PDWFKHVWKH&(DQG)&&UHTXLUHPHQWV$FRUUHVSRQGLQJVLJQLVSULQWHGRQWKHEDFNVLGHRIWKHXQLW$Q\FKDQJHRUPRGLÀFDWLRQ
may affect the behaviour of the unit concerning electromagnetic radiation and it may not then meet CE requirements. The
manufacturer takes no responsibility in this case.
Functional advice
This unit is immune to the presence of electromagnetic disturbances – both conducted and radiated - up to a certain level.
8QGHUSHDNFRQGLWLRQVWKHXQLWLVFODVVLÀHGWRVKRZD´FODVV&µSHUIRUPDQFHFULWHULDDQGPD\HQFRXQWHUWHPSRUDU\GHJUDGDWLRQ
or loss of function which may need manual help to recover. In such case, disconnect the AC power from the unit and reconnect
it again to recover.
Environmental advice
This unit is built to conform to the ROHS standards and the WEEE directive 2002/96/EC of the European Parliament and of the
Council of the European Union. Under these regulations, the product shall not be discarded into regular garbage at the end of
its life, but shall be returned to authorized recycling stations.
Unpacking
Please check that the box contains the following items:
Main parts: 1 pc. MX141M main unit
1 pc. Mains cable
1 pc. Bluetooth antenna
1 pc. IR remote control
1 pc. Operation manual
If any part is missing, please contact your dealer immediately for replacement.
AC mains voltage setting
If the AC mains voltage of your power outlet
and the setting of the AC supply voltage on
your unit do not match, contact your dealer,
FRQWUDFWRURUDTXDOLÀHGVHUYLFHZRUNVKRSWR
change the setting of the AC voltage selector.
The AC voltage selector switch is located on
the side panel of the unit, close to the AC inlet.
WARNING After unpacking, and
before plugging the AC cord in the
wall outlet, check whether the AC mains voltage and frequency is compatible with this product (see rear panel of
SURGXFW:KHQHYHUWKHVSHFLÀHGYROWDJHRU\RXU$&SOXJVKRXOGQRWPDWFKWKHORFDOFRQGLWLRQVGR127SOXJWKH
AC cord into the wall outlet and contact your dealer immediately.
AC Voltage
Selector Switch
