Coby CX-CD114 Bruksanvisning

Coby CD-spelare/brännare CX-CD114

Läs nedan 📖 manual på svenska för Coby CX-CD114 (1 sidor) i kategorin CD-spelare/brännare. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/1
Press PLAY/PAUSE( )button to pause
(5)When CD track data has been read, LCD
screen will display the last track number
with the total play time.
(6)Unit will start play from track No.1
automatically.
The CD mechanism and the sensitive circuitry may cause interference
to a radio tuner nearby. Do not operate this unit while operating other
radio devices.
Danger This product utilizes invisible laser
radiation. Avoid direct exposure to
the beam.
Caution Use of controls, adjustments or procedures not listed in
this manual may result in hazardous radiation exposure.
Only compact discs identified with this mark can
be used with this player.
C O M PA C T
DIGI T A L A UDIO
REPEAT ONE TRACK
(1) Press MODE button once to repeat current track.
(2) Repeat one indicatior appears.
REPEAT ALL TRACKS
(1) Press MODE button twice to repeat all tracks.
(2) Repeat all indicatior appears.
INTRO FUNCTION
The player will play each track for a few seconds.
(1) Press MODE button the third time,
INTRO indicator appears flashing.
(2) Press PLAY/PAUSE button to start INTRO play and
INTRO indicator turns still.
RANDOM FUNCTION
The player will start playback in an random order.
(1) Press RAN button the fourth time,
RAND indicator appears flashing.
(2) Press PLAY/PAUSE button to start RANDOM play .
RAND indicator turns still.
NOTE: To quit REPEAT/INTRO/RAN mode, just keep pressing MODE
button till funnction indicator disappears from the screen.
(4)LCD screen will display "Er" if the unit cannot
read CD track data.
(1)Press PLAY/PAUSE ( )button to turn
the power on.
Press STOP( )button to stop play,
and the last track Number will display.
on/off alternately.
Time display will flash on pause mode.
(3) During pause mode, press FF (or REW )
button to play the next track (or previous track).
The unit will keep in pause mode and time
display will flash.
(1) Press FF (or REW )button to set the
desired track# . Press PLAY/PAUSE
button to play. Press FF (or REW )
button to change the track # during the play
mode.
(2) During play, press REW button to play
previous track.
Press FF button
Press REW button at the head of NO.4
During play, press and hold FF (or
REW ) button to fast forward (or
fast reverse) the current track.
(2) When the voltage is too low, the unit will
automatically turn off.
(1) is displayed when the battery voltage
reaches low.
(2)LCD screen will display "diSC" if CD is not
in the unit.
Maximum Output (Stereo Headphone..15mW+15mW(32ohm)
DC.................................................. 3V with 2 size "AA" Batteries
VOLUME CONTROL
PHONE JACK
DBBS SWITCH
HOLD SWITCH
DC IN JACK
General
CX-CD114
PORTABLE CD PLAYER
Your unit operates on two(2)AA size alkaline batteries. Open the
CD cover and insert the batteries in the battery compartment
following the polarity diagram located inside.
BATTERY OPERATION (BATTERIES NOT INCLUDED)
STOP BUTTON
RAN BUTTON
LCD Display
PLAY/PAUSE BUTTON
REW BUTTON
FF BUTTON
MODE BUTTON
PRG BUTTON
OPEN BUTTON
5.1"x 1.1"x 5.9"(WHD)
PHONE
PHONE
PHONE
PHONEPHONE
PHONE
PHONE
PHONE
PHONE
DBBS
DBBS
DBBS
DBBSDBBS
DBBS
DBBS
DBBS
DBBS
1
ALL
INTRO
RAND
PROGRAM PLAY
1. Press PROG button, the screen is read as:
2. Press FF/REW button to get the desired track.
3. Press PROG to confirm, 01turns to 02.
it is ready to make next selection.
4. Repeat the above steps to edit up to 20 tracks.
Press PROG button to check program list.
5. Press PLAY/PAUSE button to start playback.
6. To stop program playback, press STOP button.
7.To erase memory, open the CD door or cut off power.
NOTE: Repeat/Intro function works also under the program play mode.
2
Hearing experts advise against the constant use of personal stereos played
at high volume. Constant high volume use can lead to hearing loss. If you
experience ringing in the ears or hearing loss, discontinue use and seek
medical advice.
.
To remove the disc from its storage case, press down on the center of
the case and lift the disc out. Hold it carefully by the edges as shown
below.
Insert the disc into the unit with the label of the disc facing UP.
Gently wipe the disc using a soft cloth from the center to the outer
direction to remove dust, fingerprints or any other particles on the
disc surface. Never use chemicals, such as record sprays , anti-static
sprays, benzene or thinners to clean the CD. These chemicals can
damage the disc surface permanently.
To avoid serious scratches on CD, keep them in the cases after each
use. Scratches can cause the laser pick-up skip in the future play.
Do not place stickers or write anything on the disc.
Read the instruction manual before operating this unit.
Do not expose the unit to high temperature or humidity.
Use dampened soft cloth to clean the unit. Do not use strong
detergent or solvent to clean the unit.
Consult your dealer if you are ever in doubt about the
installation, operation or safety of your equipment
DBBS FUNCTION
The Dynamic Bass Boost System(DBBS) enhances the
low frequency(Bass) response of the output.
Set the Volume to low listening level and set DBBS switch to ON .
Note: Some CD'S with DBBS may exceed the bass response
capacity and can cause distortion.
To avoid this , do not play DBBS in high volume.
Playing DBBS in high volume may cause damage to the
headphone and more importantly, to your hearing.
DBBS FUNCTION
114

Produktspecifikationer

Varumärke: Coby
Kategori: CD-spelare/brännare
Modell: CX-CD114
