Sida 1/2
.3..1.
Index to the Parts and ControlsTable of Contents
Safety Instructions CD Operation
.4.
Cares of Disc
.5.
Trouble shooting
TOP VIEW
Handle
CD Door
Headphone
Jack
Function Selector
REPEAT
PROGRAM
LED Display
Rotary Antenna
Band Selector
PREVIOUS
NEXT
PLAY/PAUSE
STOP
Handle discs by their outer edges and /or the center spindle holes to prevent
fingerprints and scratches.
Do not bend or press the disc. Do not expose the disc to direct sunlight or heating
sources.
To remove stains or fingerprints from the surface of a disc, use a soft, lint-free,
and dry cloth. Wipe in straight movements from the center of the disc to the
outside. Do not use any chemical products, as they can damage the disc.
Do not write on or attach labels to the surface of the disc.
To minimize exposure to dust and dirt. Replace discs in their cases after use.
Store each disc in its case, out of direct sunlight, high temperature and humidity.
Trouble shooting
Should your player develop a problem, please check below before requesting service.
* Check if the power cord has been properly connected to
the power outlet.
* Be sure to select a sound source.
(CD, AM/FM etc.)
* Unplug the main unit, and then
reconnect it. This allows the unit to reset itself after a
power surge or power interruption.
* Increase the volume.
* Disconnect any headphones.
* No disc. Load a disc.
* Disc has been loaded upside down. Place the disc with
the label side up.
* Disc is damaged or dirty. Clean the disc or try another
one.
* Moisture may be condensed inside the player. Remove
the disc and leave the unit power on for one or two
hours.
* Disc is incorrect type for the player.
* You may be in an area of weak signal coverage.
Symptom Check and Action
System does not
function at all
No sound
CD does
not play
Radio does
not work
. The lightning flash with arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to constitute risk of electric
shock to persons.
. The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: SHOCK HAZARD-DO NOT OPEN
AVIS: RISOUE DE CHOC ELECTRIQUE-NE PAS OUVRIR
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B
digital device. Pursuant with the FCC Rules, Part15. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy. And if
not installed and used in accordance with the instruction may cause harmful
interference to radio communication.
IMPORTANT
The CD mechanism and the sensitive circuitry may cause interference to a radio tuner nearby.
Do not operate this unit while operating other radio devices.
DANGER This product utilizes invisible laser radiation.
Avoid direct exposure to the beam.
CAUSION Use of controls, adjustments or procedures not listed in this manual may result in
hazardous radiation exposure.
CONCERNING COMPACT DISCS
Only compact discs identified with this mark can be used with
this player.
IMPORTANT SAFEGUARDS
Always operate the product from a power supply of the same voltage, frequency and rating as
indicated on the product identification plate.
Do not operate product with a damaged cord or plug.
Never install the unit where there are heat sources such as radiators, heat registers, stoves, direct
sunlight, excessive dust or where there is mechanical vibration or shock.
Switch off and unplug from AC outlet when not in use.
Refer all servicing to qualified service personnel.
CX-CD241
Portable CD Player with AM/FM Stereo Tuner
INSTRUCTION MANUAL
Please read this manual before connection and use.
Page
SAFETY INFORMATION
IMPORTANT SAFEGUARDS
TABLE OF CONTENTS
INDEX TO THE PARTS AND CONTROLS.................................................................................1
POWER SUPPLY/CONNECTING TO A HEADPHONE.............................................................2
CD OPERATION/RADIO OPERATION.......................................................................................3
CARES OF DISC/SPECIFICATION........................................................................................... ..4
TROUBLE SHOOTING.................................................................................................................5
RANDOM
Frequency Dial
REAR VIEW
LED Panel
Tuning Control Volume Control
FM ST.
REPEAT
POWER
PLAY
AC Socket
PLAY/PAUSE/STOP
1. Press the PLAY/PAUSE button once to start playing. The current playing track number
appears on the LED panel. The "PLAY" LED indicator is lit during playback.
2. Press the PLAY/PAUSE button twice to stop playing temporarily during playback.
The current track number is flashing while pausing.
3. Press the PLAY/PAUSE button again to resume normal playback.
4. Press the STOP button to stop playing.
NOTE: To remove disc from CD player, always press STOP and wait for complete stop.
REPEAT mode
1. Press the REPEAT button once to repeat playing the current track only, and the
REPEAT LED keeps ON.
2. Press the REPEAT button twice to repeat all tracks, and the REPEAT LED will be
flashing.
3. Press the REPEAT button once more to quit the REPEAT mode.
TRACKING mode
1. To go back to the beginning of current track, press the button once.
2. To go back to the previous tracks, press the button repeatedly.
3. To go to the next track, press the button once or repeatedly to play your desired track.
RANDOM PLAY
1. Press the RANDOM button once to start playing the disc in a random order.
The segments of the " " on the LED window will also be lit in a random order.
2. To cancel the random play, press the RANDOM button again.
PROGRAM PLAY
1. Press the PROGRAM button at stop mode. The "PLAY" LED will be flashing.
2. Press the or button to select the desired track number, and then press PROGRAM
to confirm.
3. Repeat step 2 to set up to 15 tracks. (The programmed # shown on LED is from "1" to
"9" and "A" to "F").
4. Press the PLAY/PAUSE button to start playing the programmed tracks.
5. To cancel the program play, press the STOP button.
1. Slide the Function Selector switch to radio.
2. Select or FM ST by sliding the Band Selector switch to corresponding position.AM, FM
is for FM stereo reception. The " " LED indicator will be lit as receiving a FM ST FM ST
FM radio station.
3. Tune the desired station by turning the Tuning Control.
4. Adjust the volume with Volume Control as desired.
5. Extend Telescopic Antenna and adjust the direction and angle to obtain the optimum
reception.
6. Set the Function Switch to the OFF position to stop radio.
Radio Operation
Specification
Power Supply: 110V~60Hz/220V~50Hz dual voltage
Applicable disc: CD/CD-R
Power Consumption: 4.2W
Output Power: 1W x2
Speaker: 8 OHM
Dimensions: 210(L) x143.5 (H) x220 (W) mm (main unit)
Weight: 1650g (main unit)
RADIO
Frequency Range: AM: 530KHz - 1700KHz
FM: 88MHz - 108MHz
CD Player
Laser Wavelength: 760 ~ 800 nm
Tracking Method: 3-spot error detection/3.86 mm lens
Design and specifications are subject to change without notice.
Slide the Function Selector to the CD position and insert a CD disc.
4. To fast backward/fast forward through the disc, press and hold the button.
/
.2.
Power Supply
1. Using AC power
Before connecting the AC power cord, please make sure to select the proper power
supply between 110V and 220V with the Power Selector on the bottom of the unit.
Insert one end of the AC power cord into the AC socket on the rear of the unit and
the other end into a standard wall socket.
2. Using batteries
Insert 6 x "C" size batteries (not included) in the battery compartment on the bottom
of the unit by matching the polarities.
The unit will not operate on battery power when the AC power cord is plugged into
the AC socket.
Replace batteries when the power indicator dims, the volume decreases or the sound
distorts.
Use batteries of high quality and check them regularly. Alkaline batteries are
recommended.
Do not mix new batteries with old or used batteries.
Use only batteries of the same brand and type.
Batteries should not be left in the unit if they are exhausted or if the unit is not to be
used for a long period of time as they may leak and damage the unit. Battery leakage
is not covered under the warranty.
You can use headphones with 3.5mm diameter stereo plug and an impedance of 32
Ohms. When the headphones are connected, the speakers are disconnected auto-
matically.
Set the VOLUME to a low level before using headphones and gradually adjust the
volume control to the comfortable listening level.
Do not play the VOLUME too loud for extended periods of time to avoid any damage
to your hearing.
Bottom View
Power Selector
(110V/220V)
Battery
Compartment
Connecting to a Headphone
