CVM-V03(SIG.LAV)
FOR DSLR/
CAMCORDER
FOR
SMARTPHONE
FOR GOPRO
USER MANUAL
Foreword
Thanks for purchasing the Comica CVM-V03(SIG.LAV) lavalier
omini-directional microphone, the product is mainly designed for GoPro
sporting camera, Cellphone as well as DSLR Camera/Camcorders. It’s a
professional power-drived(which can efficiently assist to decrease the
background noise) wired and lavalier microphone.
1
Notice
Please carefully read this user manual before using;
The LED Indicator light will keep on with green color to help you check the
item or power normally work;
The product is belong to the super accurate instrument, please pay attention
to avoid any dropping, collision or thump;
Please do not put the device beside the heat or interference source, like
radiator、Roaster or air-condition, etc;
Please keep this product in the dry environment;
Do not expose this device in rain or moist environment,
2
What’s in the box
3
Microphone
Control Body
Function Switch
Indicator Light
3.5MM Audio Plug Windscreen
Mic Collar BarCR2032 Battery Tray
WindscreenMicrophone Control body’s Clamp
Cellphone Recording Cable Converter
GoPro Recording Cable Converter
Portable Case
Cable Coiling Board CR2032 Lithium Battery Microphone
Windscreen
Microphone
Wind Muff
Warranty Card
User Manual
Components
4
1. dB Adjustment 2. Put into Battery
Operation Instruction
5
As followed illustration: Pull the ‘Battery Door’
out , put into CR2032 battery(Note: Follow the
sign of ‘Battery Tray’ to differ ‘+’ and ‘_’
pole), then push the ‘Battery Door’ into the
Microphone body again , till so far the battery
installation is finished!
As followed illustration, move
the ‘Function Switch’ to
‘+10dB’, the dB of
microphone will be increased
from -38 to -28.
Operation Instruction
6
1. Frequency Response
（Normal dB）
（+10dB After）
Specification
8
2. Polar Pattern
Specification
9
3. Technology Parameters
Specification
10
As followed illustration: slip the WindScreen or Wind Muff over the mic by
following the arrow; The WindScreen or Wind Muff can efficiently decrease
the wind noise outdoors;
4. The usage of WindScreen and Wind Muff 3. Connection with Camera / GoPro / Cellphone / Voice Recorder
Operation Instruction
7
0
30
60
90
120
150
180
210
240
270
300
330
-45
-35
-25
-15
dB rel.1V/Pa
Polar Pattern
Maximum SPL
Frequency Range
THD
Output Impedance
Dynamic Range
Sensitivity
Battery
Input Voltage
Signal/Noise
Dimension
Battery Life
Omni-directional
≥134dB SPL (@ 1kHz, 1% THD into 1KΩ load)
20～20KHz
≤0.3%
200Ω
114dB
-28dB or- 38dB±3dB@ 1kHz
CR2032
3.0V
≥74dB SPL
36(Diameter)*12mm
≥200H
As followed illustration: you can connect the cable with Camera and
Voice Recorder directly ;
For working with Cellphone, please use the ‘Cellphone Recording
Cable’ as converter adapter;
For working with GoPro Sporting Camera, please use‘GoPro Recording
Cable’ as converter adapter;
100 1k 10k 20k
10
0.0
-10
-20
-30
-40
-50
20
dB re 1 v./Pa
100 1k 10k 20k
10
0.0
-10
-20
-30
-40
-50
20
dB re 1 v./Pa
LAVALIER MICROPHONE
Shenzhen Comica Technology Co.,LTD
Tel: +86-(0)755-28226496 Fax: +86-(0)755-28435621
www.comica-audio.com
Email: support@comica-audio.com
