Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions
mentioned herein.
MC3-LITE
4-Channel Ultra-compact Audio Mixer
User Manual
Caring For Your SYNCO Product Product Introduction
Package List
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the
product to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids
warranty.
Please have the product checked or repaired by authorized
technicians if any malfunctions happened.
Failure to follow all the instructions may result in mechanics
damage.
Warranty does not apply to human errors.
MC3-LITE Audio Mixer x1
3.5mm TRS to TRRS cable x2
Charging Cable x1
① Power Button & Power Indicator
Press to turn on/o󽗈 the system.
When the system is on, the indicator stays on yellow.
② Wireless Connection Button & Wireless Control Indicator
Press the button, turn to Bluetooth interface on your phone and 󽗉nd
“MC3-LITE” for connection.
The indicator stays on blue when the function is on.
③ Low Battery Indicator
When the battery is running low, the indicator would stay on red.
④ Charging Indicator
The indicator stays on green during charging procedure and is o󽗈
once charging is ful󽗉lled.
⑤ Stepless Gain Control Dial
Separate gain control dial is provided for each output port.
⑥ Monitoring/Output Switch
Switch the 3.5mm jack to Monitoring or Output as needed.
⑦ 3.5mm Output Jack
To connect with mobile devices.
⑧ 3.5mm Output/Monitoring Jack
Depending on the Monitoring/Output Switch, this jack can be
switched between output or monitoring. Headphones can be
plugged into this interface for monitoring.
Block 15th, No.200 Fangcun Avenue East, Liwan District,
Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
Input Jack
Output Jack
Audio Distortion
Frequency Response
SNR
3.5mm Line-In
3.5mm Mic-In
Wireless Connection Input
3.5mm Stereo Output
＜0.1%
20Hz-20KHz
＞95dB
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without
following its operation speci󽗉cation
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase,
please contact a local agent for assistance, or you can always
contact SYNCO’s customer service through email at support@
syncoaudio.com.
Please retain your sales receipt and warranty certi󽗉cate as proof
of purchase. If any of these documents is missing, only sales
return or chargeable service will be provided.
If the SYNCO product is out of the warranty coverage, the service
and the parts cost will be charged.
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in
case of quality defect(s) found in the product under normal use
within 30 days upon receipt of the product.
2. Original SYNCO products are entitled to limited 12-month
warranty service. The warranty period begins on the date of
purchase of brand new, unused products by the 󽗉rst end-user.
Within the warranty period, if product defect or failure is attributable
to material defection or technological problem, the defective
product or defective part will be repaired or replaced without charge
(service and materials fee).
Speci󽗉cations
Warranty
Arti󽗉cial damage, e.g. crash, squeeze, scratch, or soaking
Modi󽗉cations to a product by its user or a third party without
prior written consent of SYNCO, e.g. replacement of element or
circuit, label alteration
The code on product is inconsistent with that of warranty
certi󽗉cate, or the code on the product or warranty certi󽗉cate is
altered or torn o󽗈
All consumable accessory attached to a product, like cable, wind
mu󽗈, battery
Faults as a result of force majeure, such as 󽗉re, 󽗊ood, lightning,
etc.
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to
contact us via Email：support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
⑨ Type-C Charging Port
For charging the MC3-LITE via the included charging cable; charging
while recording is available.
⑩ 3.5mm Line-in Jack
To connect with a media player or other audio device.
⑪ 3.5mm Mic-in Jack
To connect with microphone; Stereo input supported.
Gain Control
Input Voltage / Currency
Monitoring Output Power
Monitoring Output Impedance
Material
Weight
Dimensions
Battery Life
Battery Capacity
-15~15dB
5V/500mA
76mW
32Ω
Metal
156g
87*65*34mm
4H
500mAh
