Sida 1/1
HVented slot covers for better cooling performance
2.5" HDD/SSD drive bays
I
3.5”HDD trays (compatible for 2.5”HDD/SSD)
J
Full arcrylic side panel window
F
E5.25”shield
GRight side cover
LAir filter on bottom cover to prevent dust from entering the power supply
MLED 120mm fan for rear panel (pre-installed)
DFront panel, removable to easily install 5.25”devices
APower button
BReset button
CUSB 3.0 / USB 2.0 / HD audio ports
KLED 120mm fans x 2 for front panel (pre-installed) , effectively cool the HDD
& graphics cards
Assembly Drawing
Features How to install the 5.25”de
1 2
Pull
1 2
4 5 6
5.25” ODD
2.5” HDD/SSD
How to install the 3.
1
3.5” HDD
MX330-F is a elegant looks, functional design, and durable construction don't need to
be pricy.you can get a styling, a full acrylic side panel window for admiring your
components
● PSU & 3.5 BAY COVER
Tucking all cables and less-attractive drives behind a clean, refined PSU cover
● BEST COOLING SOLUTION
Water cooling radiator support up to 240mm on front
● FULL ACRYLIC SIDE PANEL WINDOW
● SUFFICIENT FLEXIBILITY FOR MULTIPLE GRAPHICS SOLUTIONS UP TO 350MM
● CABLE FEEDTHROUGH ON THE MB TRAY FOR EASY ROUTING AND HIDING OF CABLES
● 7 PCI SLOTS PROVIDES FLEXIBILITY FOR MULTIPLE GRAPHICS CARDS SOLUTIONS
Connectors
3
1
2
1
2
3
4
E
D
G
N
O
K
I
J
H
F
L
M
B
A
C
NTop panel fan filter can prevent dust from entering the chassis
OLED 120mm fans x 2 for top cover (pre-installed)
The specification maybe varies depending on the country or region
How to install the 2.5”HDD/SSD
Case Type Middle Tower
Mother board type Mini ITX / Micro ATX / ATX
Dimension ( mm) 195(W)x473(H)x427(D)
5.25" Drive Bay 1
3.5" Drive Bay 2 (Internal)
Front: 240mm
Top: 120mm
Rear: 120mm
2.5" Drive Bay
Water cooling
radiator support
2+2
(converted from 3.5" drive bays)
Expansion slots 7
I/O Panel USB 3.0 p1-x1 / USB 2.0 x1
Mic x 1, Audio x 1
Front:LED 120mm fan x 2
(Pre-installed)
Top:LED 120mm x 2
(Pre-installed)
Rear:LED 120mm x 1
(Pre-installed)
Cooling fan
support
Max. Graphic
cards length
350 mm
Max. CPU
cooler height
155mm
The specification maybe varies depending on the country or region
● Cobertura para Fuente y case 3.5
Escondiendo a todos los cables y drives poco atractivos detrás de una cobertura de fuente
refinada y clean.
● Mejor resolución de enfriamiento
Soporte para radiador de water cooling – hasta 240mm adelante.
● Flexibilidad suficiente para múltiples alternativas para tarjetas gráficas de hasta 350mm
● Panel lateral con ventana totalmente en acrílico
●
Cable de feedthrough en la bandeja de la motherboard para fácilmente enrollar y esconder los cables.
● Diseño altamente limpiante
Filtros de aire que son fácilmente desmontables y limpiantes ubicados en las tapas de arriba,
adelante y debajo que te permiten mantener tu computadora limpia y protegida de la suciedad.
● 7 slots PCI que proveen flexibilidad para múltiples alternativas de tarjetas gráficas.
● Copertura per PSU e bay da 3.5
Nascondi tutti i cavi e le unità dall'aspetto meno gradevole dietro una copertura per PSU
● La miglior soluzione per il raffreddamento
Il radiatore con raffreddamento ad acqua supporta fino a 240 mm davanti
● Sufficiente flessibilità per più soluzioni grafiche fino a 350 mm
● Finestra sul pannello laterale completamente in acrilico
● Passaggio dei cavi sul vassoio MB per instradare e nascondere i cavi semplicemente.
● Design che consente una facile pulizia
I filtri dell'aria superiori e il coperchio superiore e inferiore facilmente pulibili e staccabili
consentono di tenere pulito il computer e proteggerlo dalla polvere.
● 7 slot PCI per fornire flessibilità per più soluzioni per schede grafiche.
● Cobertura para Fonte e case 3.5
Escondendo todos os cabos e drives pouco atraentes atrás de uma cobertura de fonte
refinada e clean
● Melhor resolução de resfriamento
Suporte para radiador de water cooling – até 240mm na frente.
● Flexibilidade suficiente para múltiplas alternativas para placas de video de até 350mm
● Painel lateral com janela totalmente em acrílico
● Cabo de feedthrough na bandeja da placa mãe para facilmente enrolar e esconder os cabos.
● Design altamente limpável
Filtros de ar que são facilmente destacáveis e limpáveis localizados nas tampas de cima,
da frente e debaixo que te permitem manter seu computador limpo e protegido da sujeira.
● 7 slots PCI que fornecem flexibilidade para múltiplas alternativas para placas de vídeo.
PORTUGUÊS
ESPAÑOL
ITALIANO
●
КРЫШКА ДЛЯ БЛОКА ПИТАНИЯ И 3.5 ДЮЙМОВОГО ПРИВОДА
Закрепление всех кабелей и менее привлекательных приводов за крышкой
●
ЛУЧШЕЕ РЕШЕНИЕ ОХЛАЖДЕНИЯ
Радиатор с водяным охлаждением до 240 мм (установка спереди)
●
АКРИЛОВОЕ БОКОВОЕ ОКНО
●
ДОСТАТОЧНАЯ ГИБКОСТЬ ДЛЯ РАЗНООБРАЗНЫХ
ГРАФИЧЕСКИХ КАРТ ДО 350 ММ
●
ПРОХОДЫ ДЛЯ КАБЕЛЕЙ НА ЛОТКЕ МАТЕРИНСКОЙ ПЛАТЫ ДЛЯ УДОБСТВА
ПРОКЛАДКИ И СКРЫТИЯ КАБЕЛЕЙ
●
7 PCI СЛОТОВ ПРЕДОСТАВЛЯЕТ ГИБКОСТЬ ДЛЯ РЕШЕНИЙ С ГРАФИЧЕСКИМИ
КАРТАМИ
РУССКИЙ
Accessory Kit
X 14 X 2
X 3
X 5
X 7
X 4
for Main Board
#6-32 for 3.5" HDD
#6-32 for PSU & Expansion Card
#6-32 for Front Fan
M3 for Main Board, ODD & 2.5" HDD/SSD #6-32 for 3.5" HDD tray and cage
Slot cover
X 1
X6
Cable tie for cable management
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год, последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
1234567890
A
B
For more information, please visit
Compucase Enterprise Co.,Ltd.
All rights reserved.
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan,
R.O.C
Tel:+886-6-356-0606
Service E-Mail:service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR PC Case
Warranty : 1 Year
This warranty gives you specific legal rights.
You may also have other rights
granted under local law.
These rights may vary.
*only for electrical components
● Например,
AG = 17 = 2017 год
Pul
3
6
7
8
2
3
4
2 3
4
How to install a water cooler (front)
How to install a water cooler (top)
