Sida 1/4

Enter a 4-digit personal identiﬁcation

number (PIN) of your choice:

Then press the # button.

? ? ? ?

The garage door

opener will activate.

7To test, enter your

PIN, then press

the ENTER button.

Press and hold

the and #

buttons until the

lights on the

keypad stop

blinking.

3Press and release the Enter button on the keypad a number of

times that corresponds with the garage door opener type:

# of Presses Garage Door Opener Type

Security+ 2.0® (Yellow Learn Button)

Security+® (Purple Learn Button)

Security+® (Red/Orange Learn Button)

Billion Code (Green Learn Button)

Learn

Button

5Press and release the Learn

button on the garage door

opener.

Within 30 seconds...

The Learn LED will light.

Enter your 4-digit PIN, then press and

release the ENTER button until the garage

door opener lights ﬂash or two clicks are

heard.

Click

Locate the Learn button on the garage door

opener.

NOTE: Your garage door opener may

look different.

Learn

LED

Learn

LED

OR OR

Learn

LED

Green or

Red/Orange Purple Yellow

PROGRAM INITIAL PIN

CHANGE AN EXISTING PIN*

? ? ? ?

Press the programmed PIN

that you want to change.

...the light bulb blinks twice.

2Press and hold the

# button until...

? ? ? ?

new PIN

Enter the new 4-digit PIN of your choice,

then press the ENTER button.

4To test, press the new PIN,

then the ENTER button.

The garage door opener

will activate.

The light bulb will blink once.

PREPARE

Once the garage door

opener type is selected,

press the 0 button.

REFER TO GARAGE DOOR OPENER MANUAL FOR DETAILED INSTALLATION, ADJUSTMENTS, AND SAFETY INFORMATION.

To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door:

• Install keypad within sight of the garage door, out of reach of children at a minimum height of 5 feet (1.5 m), and away from ALL moving parts of door.

• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate, or play with remote controls.

• Activate gate or door ONLY when it can be seen clearly, is properly adjusted, and there are no obstructions to door travel.

• ALWAYS keep gate or garage door in sight until completely closed. NEVER permit anyone to cross path of moving gate or door.

* For garage door openers that have a green Learn button or an external receiver repeat "Program Initial PIN" to change the existing PIN.

To program the keypad to more than one garage door opener, repeat the steps above using a new PIN for each additional garage door opener.

WIRELESS KEYPAD MODEL CMXZDCG440•

Compatible with garage door openers manufactured after January 1, 1993.

Make sure the garage door opener has a working light bulb because it is a

programming indicator.

Install the battery and program the keypad prior to installation.

WARNING: This product can expose you to chemicals including

lead, which are known to the State of California to cause cancer or

birth defects or other reproductive harm. For more information go

to .www.P65Warnings.ca.gov

...the light bulb blinks 3 times.

1Press any programmed PIN, then press and hold

the * button until...

? ? ? ?

Temporary PIN

Enter the temporary 4-digit PIN of your

choice, then press the ENTER button.

The light bulb will blink

4 times.

Then press

the button.

Press the number

of hours the

temporary PIN

will work (up to 255).

OR Then press

the # button.

Press the number

of openings the

temporary PIN

will work (up to 255).

1 blink 1 blink

To test, press the temporary

PIN, then press the ENTER

button. The garage door opener

will activate. If the temporary

PIN was set for a number of

openings, the test will use up

one opening.

To clear the temporary PIN, repeat steps 1-3 above, setting the number of hours or openings to 0 in step 3.

Replace the battery when the keypad

becomes dim or does not light after a button

is pressed.

Dispose of old battery properly.

SAVE THESE INSTRUCTIONS FOR

FUTURE REFERENCE

To prevent possible SERIOUS INJURY or DEATH:

• NEVER allow small children near batteries.

• If battery is swallowed, immediately notify doctor.

PROGRAM A TEMPORARY PIN

OPERATION

The garage door opener activates when the PIN and ENTER button are

pressed. The keypad will blink for 15 seconds, during that time the

ENTER button can be used to stop, start or reverse the door.

If the wrong number is accidentally pressed, press the correct PIN then

the ENTER button. The keypad will transmit only the last four digits that

were pressed before the ENTER button.

ONE BUTTON CLOSE: The keypad has a feature that allows the door to be

closed using the ENTER button instead of a PIN.

NOTE: This feature is not available on garage door openers manufactured

prior to 2006 or an external receiver.

To deactivate the one button close feature:

1 Press and hold the 1 and 9 buttons for 10 seconds.

2 The keypad will blink four times when the one button close feature is

deactivated.

To activate the one button close feature:

1 Press and hold the 1 and 9 buttons for 10 seconds.

2 The keypad will blink twice when the one button close feature is

activated.

REPLACEMENT PARTS

9V Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10A25

Keypad cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 41D621

Battery cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 41D541

NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or modifications of

this receiver and/or transmitter are prohibited, except for changing the code setting or

replacing the battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.

This device complies with Part 15 of the FCC rules and IC RSS-210. Operation is subject to

the following two conditions: (1) this device may not cause harmful interference, and (2)this

device must accept any interference received, including interference that may cause

undesired operation.

NOTE: This feature is not available on garage door openers that have a

green Learn button or an external receiver.

A temporary 4-digit PIN can be programmed to allow access to

visitors. Each programmed PIN can program one temporary PIN. The

temporary PIN can be set for a number of hours or a number of door

openings. The temporary PIN cannot be the same as any previously

programmed PIN.

BATTERYINSTALLATION

1 Select a location to mount the keypad at a minimum height of 5

feet (1.5 m) out of the reach of children.

2 Remove battery cover and battery.

3 Mark the top mounting hole and drill 1/8 inch (3.2 mm) pilot hole.

4 Install the top screw, allowing 1/8 inch (3.2 mm) to protrude

above the surface. Position the keypad over the top screw.

5 Mark the bottom hole and drill 1/8 inch (3.2 mm) pilot hole. Install

the bottom screw. Do not overtighten to avoid cracking the plastic

housing.

6 Reinstall battery and replace cover.

9V Battery

Call: 888-331-4569

www.craftsman.com

NUMBER OF HOURS NUMBER OF OPENINGS

PROGRAMACIÓN INICIAL DE LA CLAVE PERSONAL (PIN)

CAMBIO DE UNA CLAVE PERSONAL (PIN) *

? ? ? ?

Oprima el PIN programado

que desee cambiar.

... la lámpara parpadee dos veces.

2Mantenga oprimido el

botón # hasta que...

? ? ? ?

nuevo PIN

Introduzca el nuevo PIN de 4 dígitos elegido por usted,

entonces oprima el botón "ENTER".

4Oprima el nuevo PIN para

probarlo y, luego, oprima el

botón "ENTER". El abre-puertas

de garaje se activará.

La lámpara parpadeará una vez.

PREPARACIÓN

O O

"Learn"

LED

"Learn"

LED

"Learn"

LED

Verde

Rojo/Naranja Morado Amarillo

No. de veces Tipo de abridor

Security+ 2.0® (Botón “Learn” amarillo)

Security+® (Botón “Learn” Púrpura)

Security+® (Botón “Learn” rojo o anaranjado)

Billion Code (Botón “Learn” verde)

Botón

“LEARN”

Mantener oprimidas

las teclas * y # hasta

que las luces del

teclado dejen de

parpadear.

53 4

El abre-puertas

de garaje se activará.

Pulsar y soltar el botón Enter la cantidad de veces que

corresponda al tipo de abridor:

Introduzca un número de identiﬁcación

personal (PIN) de 4 dígitos elegido

por usted:

Luego pulsar el botón #.

? ? ? ?

Introduzca el PIN

para probar; luego,

oprima el

botón "ENTER".

Oprima y suelte el botón

"LEARN".

Espere 30 segundos...

El LED se encenderá.

Indicar el número de 4 dígitos de

identiﬁcación personal (PIN) programado en

el paso 2 y luego pulsar y soltar el botón

Enter hasta que las luces del abre-puerta

parpadeen o se escuchen dos sonidos.

Clic

Localice el botón "LEARN" en el abridor

de puerta de cochera.

NOTA: Su abridor de puerta de cochera puede

ser diferente.

Una vez que haya

seleccionado el tipo de

abre-puertas de garaje,

presione el botón “0”.

CONSULTE EL MANUAL DEL ABRE-PUERTAS DE GARAJE PARA OBTENER INFORMACIÓN DETALLADA SOBRE LA INSTALACIÓN, LOS AJUSTES Y LA SEGURIDAD.

Para evitar la posibilidad de LESIONES GRAVES o INCLUSO LA MUERTE debido al movimiento de un portón o puerta de garaje:

• Instale el Control de entrada sin llave a la vista de la puerta del garaje, fuera del alcance de los niños, a una altura mínima de 5 pies (1.5 m) y lejos de TODAS las

partes móviles de la puerta.

• Mantenga SIEMPRE los controles remotos fuera del alcance de los niños. NUNCA permita que los niños utilicen o jueguen con los controles remotos.

• Active el portón o la puerta SÓLO cuando se pueda ver claramente, cuando esté ajustada adecuadamente y cuando no haya obstrucciones en su recorrido.

• Mantenga SIEMPRE a la vista el portón o la puerta del garaje hasta que cierre completamente. NUNCA permita que alguien cruce el camino de un portón o puerta

en movimiento.

* En abre-puertas que tengan un botón verde de aprendizaje (Learn) o un receptor externo, repita los pasos de “Programación inicial de la clave personal” para cambiar la clave existente.

Para programar la Entrada sin llave para más de un abre-puertas de garaje, repita los pasos anteriores usando un nuevo PIN para cada abre-puertas de garaje adicional.

ENTRADA INALÁMBRICA SIN LLAVE • MODELO CMXZDCG440

Compatible con abre-puertas de garaje de fabricados después del 1° de enero de

1993. Verifique que la luz del abre-puertas esté funcionando p3-ya que es un

indicador de programación.

Instale la batería y programe la Entrada sin llave antes de la instalación.

ADVERTENCIA: Este producto puede exponerle a productos químicos

(incluido el plomo), que a consideración del estado de California causan

cáncer, defectos congénitos u otros daños reproductivos. Para más

información, visite www.P65Warnings.ca.gov.
