A I A N O C L A S S I C T U B U L A R H E A T E R G U A R D S F O R D I M P L E X
WIREWORKERS OF EXCELLENCE SINCE 1860
C. AIANO & SONS
AI AN O C LA SS IC T UB UL A R HE AT ER GU AR DS
AIANO has been making tubular heater guards for almost as long
as there have been tubular heaters.
In coopera!on with GDC Group, AIANO has redesigned its classic
tubular heater guards for the new Dimplex range of tubular
heaters with thermostats.
Unlike other guards on the market, the AIANO guard is designed
specifically with the new Dimplex tubular heaters in mind and
each guard is the correct size for each Dimplex heater model.
This classic AIANO guard has a streamlined and op!mised design
which is the result of many decades of experience in manufac-
turing heater guards for health & safety in the UK.
The guard is made from steel weld mesh on a steel frame, which
means that the guard is strong, compact and allows op!mum
heat circula!on. The AIANO tubular heater guard ensures you
get the full benefit of the heater while the surface temperature
of the guard stays safe to touch. It also extends the life!me of
the guard.
AIANO wire guards are manufactured in the UK from Bri!sh and
European Union steel.
The complete family of AIANO guards and Dimplex tubular heaters
AIANO STG11 installed on a Dimplex ECOT1FT tubular heater
C. A IA NO & S ON S, L TD . 64 70 CHRISP STREET, LONDON E14 6LR TEL. 020 7987 1184 FAX 020 7538 2786 WWW.AIANOS.CO.UK -
AIANO STG41 tubular heater guard for the new Dimplex ECOT4FT tubular heater with thermostat
Core advantages of AIANO tubular heater guards
× Opmum heat circulaon—the open wire mesh construc!on
of the AIANO tubular guard allows the heat from the Dimplex
tubular heater to circulate freely while the guard itself stays at
a safe temperature to the touch.
× Modular installaon—the AIANO tubular guard can be in-
stalled end to end in a modular linear configura!on without
compromising heat circula!on.
× A perfect fit—the AIANO guard follows the contours of the
heater and matches the exact length of each tubular Dimplex
heater to provide an a#rac!ve and safe solu!on.
× Compactness of design—the ‘minimal’ look and light feel of
the guard belies its strength and durability. The AIANO guard
takes up minimum necessary wall space and does not demand -
a#en!on.
× Flexible installaon—the AIANO tubular heater guards are
supplied with separate moveable p clips. The clips can be -
placed anywhere on the frame for ease of installa!on in con-
fined or awkward spaces. The clips can be fixed outside the
frame (for ease and quickness), or, as in the photo above,
inside the frame for an ‘invisible’ more a#rac!ve look.
C . A I A N O & S O N S 1 5 0 y e a r s o f e x c e l l e n c e —
C. Aiano & Sons, Ltd. has been making wire guards for health & safety and security for more than 150 years.
From our London workshop, AIANO makes a wide range of products for tubular heaters, storage, panel and con-
vector heaters, fluorescent light fittings, floodlights, bulkheads, sensors and many more.
Our products help to provide health and safety protection in a variety of industrial and public environments from
warehouses to the factory floor, in schools and hospitals.
As well as our standard products, we offer a bespoke service whereby we can both manufacture to customer re-
quirements or design and manufacture a custom solution.
Specifica"on
Materials—AIANO tubular heater guards are manufac-
tured in the UK from 1” x ½” x 16 gauge (25mm x 13mm x
1.63mm) weld mesh on a 5 gauge (5.38mm) rod frame.
Our steel is sourced from Europe and the UK.
Fixings—the guards are supplied with movable p clips -
which can be a#ached to any part of the frame. They can
be fi#ed outside the frame for an easier installa!on, or
inside the frame for an ‘invisible’ fixing.
Finish—AIANO tubular heater guards are coated in white
epoxy polyester coa!ng. Other colours are available on -
request for an addi!onal charge. Hybrid epoxy polyester
powder coa!ng is recommended for use in interior situa-
!ons where toughness, chemical resistance and good
mechanical resistance proper!es are essen!al. Epoxy
polyester powder coa!ng also provides good colour
preserva!on, heat stability and a#rac!ve appearance.
Product code Description
Dimensions (in)
(L x W x D)
Dimensions (mm)
(L x W x D) Suits Dimplex model
STG 11 Aiano 1ft single guard 16" x 5⅜" x 4½ 408 x 137 x 114 ECOT1FT
STG 12 Aiano 1ft double guard 16" x 8¾" x 4½ 408 x 222 x 114
STG 13 Aiano 1ft treble guard 16" x 12" x 4½ 408 x 305 x 114
STG 21 Aiano 2ft single guard 28" x 5⅜" x 4½ 713 x 137 x 114 ECOT2FT
STG 22 Aiano 2ft double guard 28" x 8¾" x 4½ 713 x 222 x 114
STG 23 Aiano 2ft treble guard 28" x 12" x 4½ 713 x 305 x 114
STG 24 Aiano 2ft 4 bank guard 28" x 20" x 4½ - 713 x 508 x 114
STG 31 Aiano 3ft single guard 40" x 5⅜" x 4½ 1018 x 137 x 114 ECOT3FT
STG 32 Aiano 3ft double guard 40" x 8¾" x 4½ 1018 x 222 x 114
STG 33 Aiano 3ft treble guard 40" x 12" x 4½ 1018 x 305 x 114
STG 34 Aiano 3ft 4 bank guard 40" x 20" x 4½ 1018 x 508 x 114
STG 41 Aiano 4ft single guard 52" x 5⅜" x 4½ 1323 x 137 x 114 ECOT4FT
STG 42 Aiano 4ft double guard 52" x 8¾" x 4½ 1323 x 222 x 114
STG 43 Aiano 4ft treble guard 52" x 12" x 4½ 1323 x 305 x 114
STG 44 Aiano 4ft 4 bank guard 52" x 20" x 4½ 1323 x 508 x 114
STG 51 Aiano 5ft single guard 64" x 5⅜" x 4½ 1630 x 137 x 114 ECOT5FT
STG 52 Aiano 5ft double guard 64" x 8¾" x 4½ 1630 x 222 x 114
STG 53 Aiano 5ft treble guard 64" x 12" x 4½ 1630 x 305 x 114
STG 54 Aiano 5ft 4 bank guard 64" x 20" x 4½ 1630 x 508 x 114
STG 61 Aiano 6ft single guard 76" x 5⅜" x 4½ 1933 x 137 x 114 ECOT6FT
STG 62 Aiano 6ft double guard 76" x 8¾" x 4½ 1933 x 222 x 114
STG 63 Aiano 6ft treble guard 76" x 12" x 4½ 1933 x 305 x 114
STG 64 Aiano 6ft 4 bank guard 76" x 20" x 4½ 1933 x 508 x 114
AI A N O T UBU L AR H E A T E R GU AR D M O DE L S
AIANO tubular heater guard family rang-
es from 1# to 6#
C. A I A N O & S ONS , L T D . 64 70 CHRISP STREET, LONDON E14 6LR TEL. 020 7987 1184 FAX 020 7538 2786 WWW.AIANOS.CO.UK -
AIANO tubular heater guards come in singles, doubles, trebles and quads to
suit banks of up to 4 tubular heaters
