Sida 1/2

A Quick Guide to Storage Heating

This guide is designed to help you set up your storage heaters, maximising your comfort whilst minimising your heating bills. This guide covers

‘Automatic’ and ‘Manual’ heaters, and it is important to know which type you have in order to use them properly. Further details are available

in the provided with the product, on our website at or by calling . ’Operation Instructions’ www.credaheating.co.uk 0844 879 3588

• Do not cover the heater.

• Ensure that the supply switch next to the heater is turned on at all times during the heating season.

• Nothing may be within 10” of the top of the heater or 3” of the sides or front of the heater at any time.

• The outer case of the heater will be hot and care should be taken to avoid contact with the heater, especially the grille.

Manual or

Automatic?

First you need to know if your heater is

a manual or an automatic model.

Manual

Manual models must be adjusted each

day with the weather to give a

comfortable room temperature the

following day.

These models are:

TSR12MW, TSR18MW, TSR24MW

Automatic

Automatic models will automatically

adjust for the next day’s requirements

once a comfortable temperature is set.

These models are:

TSR12AW, TSR18AW, TSR24AW

Your Controls

Output

This control should be left at the lowest setting, and

increased when extra heat is required. It should be

returned to the lowest setting at the end of each day.

Input

The position of this control dictates how much heat is

stored in the product ready for use the next day.

Initially this should be set at the mid-point. If it is too

warm the next day then the control should be lowered

slightly, if it is too cold it should be raised slightly.

Staying Comfortable

Manual

If you have a ‘Manual’ heater, you should continue to adjust the ‘Input’ through the heating

season as the weather changes. Turn it up slightly if the room is too cold or down if the room is

too warm. This will make the room slightly cooler or warmer, but not until the next day.

Automatic

Continue to adjust the control up or down for a few days until you have found a comfortable room

temperature. The heater will now automatically adjust the amount of heat stored to give you the

same temperature every day, so the ‘Input’ can be left alone without need for adjustment.

2 1

Creda NOBO, a division of GDC Group, Millbrook House, Hedge End, Southampton, SO30 2DF

For further assistance please contact Creda NOBO Customer Services on 0844 879 3588 or go to www.credaheating.co.uk

Saving Energy with Storage Heating

This part of the guide is designed to help you minimise your electricity bills.

Further advice on reducing your energy bills can be found at:

www.energysavingtrust.org.uk

Which Tariff Do I Have?

To save money with an off-peak tariff you need to know when the ’cheap’ rate electricity is available. Typically if you have storage heaters

you will have an E7 (Economy7) tariff and energy will be cheaper between midnight and 7am each day. Check your electricity bill or call

your utility company to check if you are unsure which tariff you are on.

On this tariff, the best way to minimise your bills is to time as much of your electrical requirements as possible to occur during this seven

hour ‘off-peak’ period. Energy will be around half the price of that used during the day (or ‘peak period’), so it is running electrical items

at these times wherever possible.

How Do I Reduce My Energy Use?

• Where it is safe to do so, use timers to bring on heavy-use appliances during the off-peak period.

• Dishwashers, tumble dryers and washing machines could be set to run at these times, providing substantial savings.

• Avoid tumble drying clothes wherever possible, as this is an expensive electrical appliances to run, and the alternative is free!

• Ensure you heat all of your hot water during the off-peak period, and avoid using any ‘boost’ functions to top up during the day.

• Minimise the use of extra heaters in the evening; turning up your storage heaters to take a slightly larger charge will be cheaper.

• Use the microwave rather than the oven for foods that can be cooked using either appliance, as microwaves are more efficient.

• Insulate your home well, and avoid opening windows and doors unnecessarily.

• Change your light bulbs to low-consumption, energy efficient replacements.

• Only fill the kettle with the amount of water you need.

• Do not leave products in ‘stand-by’ mode.
