FULL RANGE
CRUNCH GTS SERIES
CAR AUDIO SPEAKERS
Congratulations on your purchase of the new Crunch GTS Series
speaker system.
The GTS speaker series offer superior sonic accuracy, intense high
power sound quality with exotic build materials and outstanding
good looks.
As with all high quality car audio products, we recommend
professional installation by an authorised Crunch dealer.
Your dealers knowledge and experience can ensure a problem free
and cosmetically integrated installation.
If you choose to install the speakers yourself, please read the entire
manual very carefully.
1
Impact Resistant Tweeter Elements
Neo Mylar Soft Dome Tweeter
Installation hardware Included
External 12dB Passive In-Line Crossover
Raised T-Yoke
Silver Alpha-Cellulose Cones
Tight-Fit Insert Speaker Terminals
Moisture Resistant Rubber Surround
High Mid-Bass Impact
Anti-Resonant Stamped Steel Basket
Wide Nominal Power Range
2
SPEAKER LOCATION AND MOUNTING TIPS
THE FIRST STEP IS THOROUGH PLANNING BEFORE THE
INSTALLATION BEGINS.
THE SPEAKER SCREW HOLE CONFIGURATION WILL WORK WITH
MOST DOMESTIC AND FOREIGN VEHICLES.
FOLLOW THESE INSTRUCTIONS CAREFULLY TO ENSURE PROPER
IMAGING AND MAXXIMUM PERFORMANCE.
Factory Speaker Replacement Location and Installation
1. Before you alter the vehicles interior materials, be sure there is
adequate room and clearance for the speaker depth to clear the
windows and other moving parts. (See speaker measurement page).
2. If you are using the speaker wires provided in this kit, be sure
to route wires through the factory door grommet as shown in the
speaker mounting diagram.
3. After securing the speaker and checking clearances, connect
the red/black speaker audio wires to the correct speaker + and -
push-pin terminals.
Custom Speaker Location and Installation
1. Follow steps 1-5 above.
2. Use the speaker mounting diagrams and speaker hole cut-out
dimensions on the following pages.
3. Always mount the left and right side speakers on the same plane.
This means that each speaker should be the same height from
the floor and same distance from the firewall. Do not mount one
speaker higher, lower, further forward or further behind the other.
3. It is always best to keep the tweeter (component speakers) as close
to the mid range driver as possible. Typically with-in 12”.
The tweeters sound best when swivelled up, towards the rear center of
the vehicle.
