PRODUCT FEATURES

DWR-WE5413WC/SC/RC

DWR-WE6413WC/SC/RC

Electric and Gas Dryer

A NOTE TO YOU

Thank you for purchasing a DAEWOO Dryer.

Please read this manual carefully, as it provides instructions

on safe installation, use, and maintenance

Record the model and serial numbers,and retain the manual for future reference.

For more information, please visit our website at http://www.e-daewoo.com

"OUTSTANDING PERFORMANCE

Besides the large capacity, you can benefit from faster drying time, quiet

operation, and energy efficiency.

"STAINLESS STEEL DRUM

Stainless steel drum resists rust.

"DIGITAL FABRIC CARE

Multi-Level temperature control takes better care of your clothes.

"EASE OF USE

An entire selection of user-friendly functions make operating the dryer

easier.

"ONE TOUCH SELECTIONS

To choose an option, press its button once. No need to press buttons multiple times to scroll through a list

of options.

Your dryer provides sensor drying and time drying programs.

Sensor Dry

The dryer senses the dampness of the laundry and automatically determines the heat level and operation

time. You might see a sudden increase or decrease in operation time if the sensor determines more or less

drying is required. This is not a malfunction.

Time Dry

Use TIME DRY to select heat level and drying time manually. This can be used if clothes are not as dry as

you like them at the end of the cycle. Use TIME DRY for heavy and bulky items and thick work.

What are Sensor Dry and Time Dry?

CONTACT INFORMATION

Website : http://www.e-daewoo.com

Call : 1-877-393-7823(1-877-DWESVC3)

[SEEKING WARRANTY SERVICE]

The warranty information for your dryer is located at the end of this manual. Warranty Service is available by

contacting the nearest DAEWOO

Service Center. If this product is installed and operated according to the instructions in this manual, DAEWOO will

repair or replace any parts defective in material or workmanship throughout the warranty period, beginning with the

date of purchase.

Warranty Restriction :

If the dryer is subjected to other than single family use, all warranty coverage is effective for only 90 days.

You will need the complete model and serial number when requesting warranty service. A proof of purchase is also

required.

Use the space below to record the model number and serial number of your new DAEWOO dryer.

Model Number

Serial Number

Date of Purchase

❈

Staple your receipt here for convenience when contacting service.

WARNING!

For your safety, the recommendations in this manual must be followed. To reduce the risk of fire or explosion,

electric shock or to prevent property damage, personal injury, or death

when using your appliance follow basic precautions

NOTE : These manual should be retained for future reference.

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

- Do not store or use gasoline or other flammable vapors and llqulds in the vicinlty of this or any other appllance.

- WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a nel ghbor’s phone. Follow the gas supplier’s Instructions.

• If you cannot reach your gas supplier, call the fire department.

- Install ation and service must be performed by a qualified lnnstaller, service agency or the gas supplier.

WARNING : For your safety the information in this manual must be followed to minimize the risk of fire or

explosion or to prevent property damage, personal lnjury or dearth.

IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

■Type : Electric and Gas Dryer

■Rating : Please refer to the rating label regarding detailed

information.

■Size : 27 x 32.4 x 40.1 inches

■Capacity : 7.3 cu.ft. IEC, 10.4kg(22.9lb)

■Weight : 128 Ibs (58.5 kg)

❈Specifications are subject to change by manufacturer.

PART 1. SPECIFICATIONS............................................................................................................................3

PART 2. INITIAL STEPS FOR INSTALLING YOUR DRYER........................................................................7

PART 3. ACCESSORIES INSTALLATION ..................................................................................................17

PART 4. ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYER ........................................................18

PART 5. ELECTRICAL REQUIREMENTS FOR GAS DRYERS ................................................................24

PART 6. GAS REQUIREMENTS AND INSTRUCTIONS............................................................................25

PART 7. USER - MAINTENANCE INSTRUCTIONS ...................................................................................26

PART 8. OPERATING YOUR DRYER.........................................................................................................28

PART 9. TROUBLESHOOTING GUIDE.......................................................................................................35

DAEWOO DRYER LIMITED WARRANTY...................................................................................................39

■

Accessories

TABLE OF CONTENTS

PART 1

SPECIFICATIONS

❈Design of pedestals is

subject to change

without

manufacturers notice.

Dryer Rack (Option) Pedestal (Option)

Skating Kit (Option) Y Connector Inlet hose
