INSTRUCTION MANUAL
MICRO COMPONENT SYSTEM
RM-421
B
G
h
s
i
l
g
n
E
HELPLINE NUMBER: 0870 100 2525
1
LOCATION OF CONTROLS
1.) VOLUME CONTROL
2.) REPEAT BUTTON
3.) SKIP DOWN BUTTON
4.) SKIP UP BUTTON
5.) POWER INDICATOR
6.) FM STEREO INDICATOR
7.) LED INDICATOR
8.) REMOTE SENSOR
9.) CD PLAY/PAUSE BUTTON
10.) CD STOP BUTTON
11.) PROGRAM BUTTON
12.) DIAL POINTER
13.) TUNING KNOB
14.) FM/AM MODE SELECTOR
15.) POWER OFF & FUNCTION SELECTOR
16.) CASSETTE DOOR
17.) RECORD KEY
18.) PLAY KEY
19.) REWIND KEY
20.) FAST FORWARD KEY
21.) STOP/EJECT KEY
22.) PAUSE KEY
23.) SPEAKER JACKS (L/R)
24.) FM ANTENNA LEAD
25.) BEAT CUT
26.) A/C CORD
CAUTION:
USAGE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THIS UNIT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE
PERSONNEL.
IMPORTANT:
SINCE MOVEMENT OF THE CD MECHANISM AND THE SENSITIVE CIRCUITY MAY CAUSE INTERFERENCE
TO THE RADIO TURNER NEARBY, SWITCH THIS UNIT OFF WHILE OPERATING OTHER RADIO DEVICES.
1
2
3
4
5 6 7 8
9
10
11
12
13
14
15
16
17 18 19 20 21 22
23
25
24
26
LISTENING TO RADIO
OPERATION
1. SET THE FUNCTION SELECTOR TO "RADIO" POSITION.
2. SELECT THE DESIRED RADIO FREQUENCY BAND WITH BAND SELECTOR.
3. TURN THE TUNING CONTROL TO SET THE DIAL POINTER AGAINST THE STATION
FREQUENCY AS DESIRED.
4. ADJUST VOLUME CONTROLS FOR THE DESIRED VOLUME LEVEL.
FM & FM-STEREO RECEPTION
• SET THE FM MODE SELECTOR AT "MONO" POSITION. PROGRAMS ARE RECEIVED IN MONO
MODE. IN PARTICULAR WHEN STEREO SIGNALS ARE WEAK. IT IS PREFERABLE TO RECEIVE
THE PROGRAM IN MONO.
• SET THE FM MODE SELECTOR AT "FM ST" POSITION FOR RECEIVING STEREO
PROGRAMS. THE STEREO INDICATOR LIGHTS UP TO SHOW FM STEREO PROGRAM.
PLAYING COMPACT DISC
• GETTING STARTED
1. SET THE FUNCTION SELECTOR TO "CD" POSITION. OPEN THE
CD COMPARTMENT BY PRESSING THE OPEN BUTTON. PUT A
CD INTO THE COMPARTMENT AND CLOSE THE CD DOOR.
2. FOCUS SEARCH IS PERFORMED IF DISC IS INSIDE. TOTAL NO.
OF TRACKS IS READ.
PLAY/PAUSE MODE
1. IF PLAY/PAUSE BUTTON IS PRESSED DURING STOP MODE, THE FIRST
TRACK WILL BE PLAYED AND THE PLAY/PAUSE LED WILL BE TURNED ON.
2. IF PLAY/PAUSE BUTTON IS PRESSED DURING PLAY MODE,
GOTO PAUSE MODE AND THE PLAY/PAUSE LED AND THE TRACK NO. WILL BE FLASHING.
• STOP MODE
1. IF STOP BUTTON IS PRESSED DURING PLAY OR PAUSE MODE. GO TO STOP MODE
AND DISPLAY TOTAL NUMBER OF TRACKS ALL INDICATOR LED ARE TURNED OFF.
• SKIP MODE
(SKIP UP / SKIP DOWN )
1. DURING PLAY OR PAUSE MODE. IF SKIP UP BUTTON IS PRESSED IT WILL GO TO NEXT
TRACK AND DISPLAY THE TRACK NO. AND THEN CONTINUOUS THE PLAY OR PAUSE MODE.
2. DURING PLAY OR PAUSE MODE, IF BACK BUTTON IS PRESSED IT WILL GO BACK
TO THE BEGINNING OF THE TRACK, SAME TRACK NO, IS DISPLAY CD AND CONTINUOUS
THE PLAY OR PAUSE MODE.
3. PRESS BACK BUTTON AGAIN IT WILL GO TO THE PREVIOUS TRACK AND
CONTINUOUS THE PLAY OR PAUSE MODE.
• REPEAT MODE
PRESS THE REPEAT BUTTON BEFORE OR DURING PLAY, A SINGLE TRACK OR ALL THE TRACKS CAN
BE REPEATED.
EACH PRESS SWITCH THE REPEAT MODE
(1) REPEAT 1 (2) REPEAT ALL (3) REPEAT OFF
2
Repeat 1/
Repeat all
Indication
Play /
Pause
Indication
REPEAT MODE
REPEAT 1
REPEAT ALL
REPEAT OFF
REPEAT 1/ALL
INDICATION
FLASH
LIGHT ON
LIGHT OFF
