OPERATING INSTRUCTIONS FOR PERSONAL TRIMMER
READ THESE INSTUCTIONS BEFORE USING YOUR TRIMMER!
Safety
All trimmers are individually checked for correct operation before distribution.
When using this trimmer, please adhere to regulations governing the
operation of trimmers and ensure that all safety features are working
correctly.
This machine has a rotating circular blade, which is pulled longitudinally through
the material to be cut. The blade is housed in a plastic cutting head guard for
safety.
THIS TRIMMER MUST NOT BE OPERATED IF THE CUTTING HEAD IS NOT
IN PLACE.
It is an offence under the Offices, Shops and Railway Premises Act to use, or allow to be
used a trimmer without the cutting head guard in place.
Provided that the guard supplied with this machine is in place during operation, the
machine conforms with BS5498: 1977.
DO NOT TOUCH THE EDGE OF THE CIRCULAR BLADE WITH YOUR HAND
UNDER ANY CIRCUMSTANCE!
Features
The two horizontal and one vertical scale bars marked on the trimmer table area are
calibrated in centimetres (1). The photographic size markings and the degrees on the
table area are meant as a guide only (2). The machines are provided with a ground steel
circular cutting blade enclosed in a cutting head (3) and an automatic clamp (4).
Operating the trimmer
The machine is able to cut up to 5 sheets of 70 gsm paper in one pass. It can also cut
light card, acetates and other thin materials. Any attempt to exceed the stated single pass
capacities could result in damage to the machine.
The rotating circular blade is pulled longitudinally through the material to be cut. The
blade housing is fitted to a support bar along which it runs. The machine will cut in both
directions along the support bar axis.
With the blade housing parked at one end of the support bar insert the material to be cut
underneath the clear plastic clamp. Push the material through until the place that you
wish to cut is aligned with the table area cutting edge. Use the plastic moulding at the top
or the bottom of the trimmer (5) as a guide to ensure that the material is set square to the
blade before cutting. For a good quality cut, even with the thinnest material, it is advisable
to pull the blade housing along the cutting support bar gently and evenly. Moving the
blade housing along the support bar automatically engages the plastic clamp to ensure
that the material is held securely in position. Pull the blade housing along the entire length
of the cutting support bar and park it at the opposite end from which you started before
attempting to remove the material you are cutting. The scale bars and table markings can
be used to help achieve an accurate cut.
Changing the blade
The rotating circular blade on Trimmers is designed to be self sharpening. However,
depending on usage, it is likely that the blade will eventually become blunt. This can be
detected by reduced cutting capacity and greater effort required to run the blade housing
along the support bar. Trimmers have been designed to ensure that replacement of the
blade is a simple operation.
The blade housing support bar (6) is clipped into the trimmer’s moulded plastic end caps
(7). Simply unclip the support bar at one end from the plastic moulded end cap and slide
off the entire old blade housing. Slide the new blade housing onto the support bar
ensuring that it is the same way round as the old one (the rubber wheel inside the blade
housing should sit on top of the automatic plastic clamp and the circular rotary blade
should run alongside the metal table area of the trimmer). Gently clip the free end of the
support bar back into the plastic moulded end cap.
Dahle orth merica, nc. N A I
49 Vose Farm Road
Peterborough, H 3458 N 0
Tel. (800) 995-1379
info@dahle.com
www.dahle.com
