dBTechnologies’ active line array series

DVA has set new standards in the sound

reinforcement industry since its market launch

in 2006.

Equipped with top-notch features and

engineered for maximum versatility, DVA

T and DVA M series brought the benefits

of line array technology to a much wider

range of users. Now Italian manufacturer

dBTechnologies upgrades the best of

technology that determined the success of

the whole DVA series in the new DVA K series,

composed by the 3-way active line array DVA

K5 and active subs DVA KS10 and double 18”

DVA KS20.

Featuring a Class-D 500

W RMS Digipro® G3

digital amplifier, DVA K5

is capable to reach up

to 129 dB SPL and aims

to inherit the success of the

earliest model of the series DVA T4. The new DVA line array module

comprises 2 x 1,4”compression drivers, a 6.5” neodymium midrange

and a 8” neodymium woofer. Thanks to FIR filters technology, a new

dual rotary encoder DSP user interface allows an extremely precise

system tuning. The module’s electronics and components are

housed in a sturdy polypropylene box, reinforced with an internal

anti-vibration metal structure that allows the cabinet to achieve an

excellent acoustic response. DVA K5 comes with a freshly designed

frontal grille and an integrated raincover.

The semi-horn loaded

subwoofer DVA KS10 is

equipped with a single

18” woofer driven by a

Class-D Digipro® G3 power

amp delivering 1800W Peak

and reaching 134 dB SPL. Maximum versatility is granted by a

stereo input/output balanced pre-amp. Crucially, KS10 can be both

used as a compact PA system (together with K5 on a speaker pole)

or groundstacked, but can also be flown thanks to the optionally

available flyware. A dedicated encoder allows to apply up to 4.5 ms

of delay, with 0.5 ms steps. A switch allows to invert the phase by

180° as well as changing the LPF from 90 Hz to 120 Hz.

Featuring a double 18”

woofer pairing in a bass

reflex housing, the DVA

KS20 is equipped with

2 x DIgipro® G3 power

amplifiers delivering 3600 W

Peak. The system’s internal design brings together the benefits of

bass reflex and horn-loaded system in a compact sturdy housing

covered with robust black laquer. The 56 Bit DSP manages limiters

and delays, for flawless system processing.

DVA KS20 is the perfect low-end complement for larger DVA

K5 systems and can also be used vertically for groundstacked

configurations thanks to the DRK-20/10 pick points on top.

dBTechnologies

dbtechnologies.com

DVA K5 groundstacked

with DVA KS20

DVA K5 flown

with DVA KS10

dBTechnologies

Frequency Response [-3 dB] 70 Hz - 19.000 Hz

Max SPL 129 dB

LF 1 x 8” Neodymium woofer - 2.5” v.c.

MF 1 x 6.5” Neodymium midrange - 2” v.c.

HF 2 x 1” Compression driver - 1.4” v.c.

Directivity [H x V] 100° x 15°, single unit

Frequency Response [-3 dB] 39 Hz - 120 Hz

Max SPL 134 dB

LF 18” Woofer - 4” v.c.

Directivity Omnidirectional

Frequency Response [-3 dB] 34 Hz - 120 Hz

Max SPL 138 dB

LF 2 x 18” Woofer - 4” v.c.

Directivity Omnidirectional

Speaker Type 3-Way Active Line Array Module

Speaker Type Active Semi-Horn loaded Flyable Subwoofer Speaker Type Active Bassreflex - horn Subwoofer

Input Section 1x XLR balanced

Output Section 1x XLR balanced

Power Socket 1x Powercon In + 1 x Powercon Out

Input Section 2x XLR balanced

Output Section 2x XLR balanced

Power Socket 1x Powercon In + 1 x Powercon Out

Input Section 2x XLR balanced

Output Section 2x XLR balanced

Power Socket 1x Powercon In + 1 x Powercon Out

Amplifier technology Digipro® G3 Class-D

RMS Power 500 W

Peak Power 1000 W

Cooling Convection

Amplifier technology Digipro® G3 Class-D

RMS Power 900 W

Peak Power 1800 W

Cooling Convection

Amplifier technology Digipro® G3 Class-D

RMS Power 1800 W

Peak Power 3600 W

Cooling Convection

Controller DSP 56 Bit

AD/DA converter 24 bit/48 kHz

Limiter Dual Active Limiter Multiband RMS, Peak,

Thermal

Processing (filters) FIR Linear phase

X-over frequency MF-HF

Slope MF-HF

1800 Hz

24 dB/Octave

X-over frequency LF-MF

Slope LF-MF

340 Hz

24 dB/Octave

Controller DSP 56 Bit

AD/DA converter 24 bit/48 kHz

Limiter Dual Active Limiter Multiband RMS, Peak,

Thermal

X-over frequency LF-HF

Slope LF-HF

90 - 120 Hz (selectable)

24 dB/Octave

Controller DSP 56 Bit

AD/DA converter 24 bit/48 kHz

Limiter Dual Active Limiter Multiband RMS, Peak,

Thermal

X-over frequency LF-HF

Slope LF-HF

90 - 120 Hz (selectable)

24 dB/Octave

Enclosure Polypropylene PP Metal reinforced

Rigging Points Integrated rigging hardware (1.5° splay res.)

Dimensions (W x H x D) 580 x 240 x 327 mm

(23.2 x 9.6 x 13.08 in)

Weight 14.2 kg (31.3 lbs.)

Enclosure Multiplex birch plywood

Pole Mount 1 x M20 on top

Rigging Points Integrated for SRK10 Flykit (optional)

2 x Pick points on top to fix DRK10/20 Flybars

Dimensions (W x H x D) 515 x 640 x 720 mm

(20.6 x 25.6 x 28.8 in)

Weight 48 kg (105.82 lbs.)

Enclosure Multiplex birch plywood

Pole Mount 1 x M20 on top

Rigging Points 2 x Pick points on side to fix DRK10/20 rigging

frames

Dimensions (W x H x D) 1100 x 580 x 720 mm

(44 x 23.2 x 28.8 in)

Weight 84 kg (185.19 lbs.)

Acoustical Data

Acoustical Data Acoustical Data

Technical Data

Technical Data Technical Data

Inputs

Inputs Inputs

Processor Processor Processor

Mechanics

Mechanics Mechanics

Amplifier Amplifier Amplifier

Series

Power Supply 500 W SMPS with Auto-range PSU

Controls 1 x Input Sensitivity Rotary Switch

1 x DSP Setup Rotary Encoder (LF Correction)

1 x DSP Setup Rotary Encoder (MF-HF Correct.)

Power Supply 1000 W SMPS with Auto-range PSU

Controls 1 x Input Sensitivity Rotary Switch

1 x DSP Setup Rotary Encoder (Delay 4.5 ms)

1 x Phase Inversion Switch (0° - 180°)

1 x X-Over Frequency Switch (90 Hz - 120 Hz)

1 x Outputs Mode Switch (Link - X-Over)

Power Supply 2000 W SMPS with Auto-range PSU

Controls 1 x Input Sensitivity Rotary Switch

1 x DSP Setup Rotary Encoder (Delay 4.5 ms)

1 x Phase Inversion Switch (0° - 180°)

1 x X-Over Frequency Switch (90 Hz - 120 Hz)

1 x Outputs Mode Switch (Link - X-Over)
