Sida 1/12
501 / 521
COMPACT STOVE
Cooking
Instruction manual
Part number: 069184
PAGE OF 122
Introduction
Congratulations on the purchase of this
quality product. We trust that you will
enjoy many years of trouble free use.
Please read these instructions carefully
before using the stove.
This manual will provide you with
information on how to operate and care
for your product in order that you gain
the maximum benefit from it.
Unpacking
Please ensure that packaging material is
disposed of in a responsible manner.
Plastic bags should be cut up to
prevent children playing with them and
accidentally suffocating.
Remove all packing from the oven
cavity and position the accessories.
If the appliance is damaged in any way,
do not use it. Report the damage to your
dealer, who will take the necessary
corrective action.
A polystyrene strip has been placed
between the control panel and the hob.
(See diagram with arrows below)
Please ensure the strip is completely
removed prior to use. Failure to do so is
a safety hazard. Check that there are no
broken pieces of polystyrene left
between the control panel and the hob.
Installation
Surfaces immediately adjacent to the
oven should be able to withstand
temperatures of up to 100 without °C
delaminating or discolouring.
Cupboard design
Your Defy oven is designed to give you
years of trouble free service, however it
is important that it be correctly
installed.
Cooking appliances generate
considerable heat. The layout and
materials of the mounting cabinet
should take account of the
characteristics of the oven.
Surfaces immediately adjacent to the
oven should be able to withstand
temperatures of up to 100°C without
delaminating or discolouring.
Overhanging doors above the oven may
be subjected to heat as well as
condensation if very moist foods are
being cooked.
Accessories supplied may
vary depending on the model.
Not all accessories in the user
manual may be included with
your appliance. Accessories
may be purchased from Defy
spares.
PAGE OF 123
Electrical installation
(Model 521 only)
This appliance must be earthed and the
manufacturer and the seller do not
accept responsibility for any damage
due to incorrect installation or
electrical connection.
This appliance should not be connected
through an earth leakage system.
Refer to S.A.N.S. 10142
Connection to the power supply
This appliance has a Y type supply cord ‘ ’
connection and must be installed by a
licensed electrician, who will ensure that
the stove is correctly connected and safely
earthed. The rated current is printed on the
serial number label attached to the stove
upper back panel. The appliance must be
connected to the mains through an All
pole isolating switch which has a
minimum clearance between the contacts
of 3 mm. in All poles. A means for
disconnection must be provided in the
fixed wiring.
Bake and 2 small plates
Grill and 2 small plates
3 Plates
Electrical installation (Model
501 only)
Push the electric plug into a 230V. 15A.
Earthed wall socket The stove is a plug
in model with a 15A. power supply.
It is therefore not possible to use all the
elements at the same time. Set the selector
to the required position.
Do not set the knob to the unmarked
position.
Connecting the sprague to the oven
1.) Purchase a standard plastic/metal saddle
type bracket, capable of going around the
20 mm diameter sprague and with a hole
pitch of 38 mm (Plastic) 45 mm (Metal),
from your local hardware and 2 off 4.2
mm x 12 mm self tapping screws.
2.) Feed the cables through the Sprague and
connect to the mains terminal block of the
appliance.
3.) Place the plastic/metal saddle around the
sprague and fasten via the 2 self tapping
screws onto the factory pre punched holes
adjacent to the mains terminal block of the
appliance.
1 2 3
WARNING!
ELECTRICAL
CONNECTION
MUST ONLY BE
DONE BY A
QUALIFIED
ELECTRICIAN!
Danger of fire: Do not store items on the cooking surface. CAUTION: The cooking
process has to be supervised. A short term cooking process has to be supervised
continuously. WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in a fire.
