KITCHENAIRE
MULTIFUCTION SOLID PLATE STOVE DSS 697
Cooking
Instruction manual
Part number: 073241D
PAGE OF18 2
Dear Customer,
Your new Defy oven was manufactured in a state of the art facility and has passed the strictest
quality control procedures.
Please read this manual carefully before using your oven for the first time and then store it
within easy reach for future reference.
This manual will provide you with information on how to operate and care for your oven to gain
the maximum benefit from it.
We trust you will enjoy years of trouble free use.
EXPLANATION OF SYMBOLS
Important information
Warning—Hazardous situations
Warning—Electric shock
Caution; Warning for fire hazard
Caution; Warning for hot surfaces
Contents
PLEASE REGISTER YOUR PRODUCT AT
www.defy.co.za
DEFY APPLIANCES (PTY) LTD
P.O.BOX 12004
JACOBS
DURBAN
4026
SOUTH AFRICA
1. General Information 3
Introduction 3
Unpacking 3
Installation 3
Anti-tilt Mechanism 4
2. Important Safety Instructions 5
General Safety 5
Technical Specification 6
3. How to use the oven 7
Tips for baking 7
Tips for roasting 7
Tips for grilling 7
The control panel 8
Selector switch 8
How to operate the electric oven 9
Tips for baking pastry 10
How to operate the grill 10
Solid plates 11
Cooking times table 12
Warming drawer 13
4. Maintenance and care 13
General cleaning 13
Cleaning the oven 13
Steam assisted cleaning 13
Oven light 13
Removing the oven door 14
5. Trouble Shooting 15
6. Branches 17
8. Warranty 18
PAGE OF18 3
Connecting the sprague to the oven
1.) Purchase a standard plastic/metal saddle
type bracket, capable of going around the
20 mm diameter sprague and with a hole
pitch of 38 mm (Plastic) 45 mm (Metal),
from your local hardware and 2 off 4.2
mm x 12 mm self tapping screws.
2.) Feed the cables through the Sprague and
connect to the mains terminal block of the
appliance.
3.) Place the plastic/metal saddle around the
sprague and fasten via the 2 self tapping
screws onto the factory pre punched
holes adjacent to the mains terminal block
of the appliance.
1
2
3
WARNING! ELECTRICAL
CONNECTION MUST ONLY BE
DONE BY A QUALIFIED
ELECTRICIAN!
Introduction
Congratulations on the purchase of this
quality product.
We trust that you will enjoy many years of
trouble free use. Please read these
instructions carefully before using the stove.
This manual will provide you with
information on how to operate and care for
your product in order that you gain the
maximum benefit from it.
Unpacking
• Please ensure that packaging material is
disposed of in a responsible manner.
• Plastic bags should be cut up to prevent
children playing with them and
accidentally suffocating.
• Remove all packing from the oven cavity
and position the accessories.
• If the appliance is damaged in any way,
do not use it. Report the damage to your
dealer, who will take the necessary
corrective action.
Installation
• Levelling feet are provided to assist you
in positioning your stove, so that it will
stand firm and level. To adjust the level,
turn the relevant foot to either raise or
lower the stove.
• Surfaces immediately adjacent to the
oven should be able to withstand
temperatures of up to 100°C without
delaminating or discolouring.
Electrical installation
This appliance must be earthed and the
manufacturer and the seller do not accept
responsibility for any damage due to
incorrect installation or electrical connection.
This appliance should not be connected
through an earth leakage system. Refer to
S.A.N.S. 10142
Connection to the power supply
This appliance has a ‘Y’ type supply cord
connection and must be installed by a
licensed electrician, who will ensure that the
stove is correctly connected and safely
earthed. The rated current is printed on the
serial number label attached to the stove
upper back panel. The appliance must be
connected to the mains through an All pole
isolating switch which has a minimum
clearance between the contacts of 3 mm in
All poles. A means for disconnection must
be provided in the fixed wiring.
1. General information
