Sida 1/12
1
PAGE / CONTENTS
2 IMPORTANT INFORMATION
2 COMPLIANCE WITH LOCAL
REQUIREMENTS
3 SERVICE INSTALLER DETAILS
3 INSTALLATION BEFORE USE
4 GAS CONNECTION
6 RELOCATING BURNER CAPS
6 KNOW YOUR STOVE
7 LIGHTING THE BURNERS
7 LIGHTING THE OVEN
8 OVEN CONTROL
8 TEMPERATURE GUIDE
8 THE OVEN SHELF
9 CLEANING AND MAINTENANCE
10 SAFETY PRECAUTIONS
10 TROUBLE SHOOTING
11 SERVICE CENTRES
11 NOTES
12 WARRANTY
www.defy.co.za
GAS STOVE
OGS148
OWNER’S
MANUAL
LP Gas Safety Association
Safe Appliance
PERMIT NUMBER
1037-40/1-RSA-12-A
2
Important: Read these instructions for use carefully so as to familiarize yourself with
the appliance before connecting it to its gas container. Keep these instructions for
future reference.
Do not use the stove if it is damaged. Report the damage to your dealer, who will take the
necessary corrective action.
Please keep your sales invoice in a safe place. You may need it at a future date as proof of
purchase for warranty purposes.
IMPORTANT INFORMATION
COMPLIANCE WITH LOCAL REQUIREMENTS
2
FLEXIBLE HOSE - Not supplied.
Any hose that is used to connect the stove to the gas system shall comply with SANS 1156
-2 or BS 3212.
TEMPORARY INSTALLATION.
Flexible hose connection from the gas appliance to the cylinder can be made .
Ensure that pipe clamps are tightened correctly and are of good quality.
GAS CYLINDER - Not supplied.
For best results we recommend that gas cylinders with a minimum capacity of 19kg be
used.
REGULATOR - Not supplied.
A 2,8 kPa LPG gas regulator which complies with SANS 1237 must be used.
PERMANENT INSTALLATION.
The appliance may only be installed by a Qualified Gas Fitter who is registered with the
LPGSASA.
All registered Gas Fitters are issued with an identity card which carries their registration
number.
Make a note of this in the box provided on page 3
The Gas Fitter should also provide you with a written certificate after completion of the
work.
Failure to comply with the above will render the Warranty invalid.
1
The manufacturer of this product constantly strives for further improvement.
For this reason the specifications and design of the stove are subject to change
without notice.
3
Unbox the stove and remove all packaging and protective wrapping.
Adhesive residue may be cleaned off using benzine or alcohol and then rinsed with water.
Please ensure that you dispose of the packaging in a responsible manner. Plastic bags
should be cut up to prevent children playing with them and accidentally suffocating.
Stand the stove on a solid flat and level floor capable of supporting it's weight without
flexing.
The stove should be located away from draught, direct
sunlight, cooling appliances and any
combustible materials such as curtains and plastic
containers.
The stove should have an air gap of at least 50mm.
around the back and sides for ventilation purposes and
a space of at least 850mm. above the cooking surface.
The gas pressure regulator should be accessible and
located near the stove.
Before the installer hands over the appliance be sure that you fully understand:
a) The position of the isolation or shut-off valve in the gas supply line to the appliance.
b) The requirements for safe operation of the appliance.
NOTE
This appliance is supplied ex-factory with jets and air settings for use with
Liquid Petroleum Gas ( LPG ) only.
Note: A stove without a flame failure device may only be used with a free standing
cylinder placed adjacent to but not closer than 300 mm to the stove.
RECORD INSTALLERS DETAILS HERE
INSTALLATION BEFORE USE
3
850mm
50mm 50mm
50mm
