AC-1300 Quick Start Guide

ENG-1

1.Appearance

2.Key Functions and Indictors

Key/Indic

ator

Function

Power Power On/Off

Shutter

Video recording mode, Recording/Stop

Capture mode, taking pictures

Replay mode; after connecting to TV, short press

to play the recorded video; long press to enter

shortcut for deletion; short press to confirm file

deletion.

MODE

key

Switchover of video recording and capture mode

in circle and change image size;

In capture mode, long press MODE key to format

TF card;

Replay mode: after connecting to TV, it is used

for next or previous photo, or exit from deletion

mode.

3.Start Operation

Battery

This camera uses the original packaged built-in rechargeable 3.7V

lithium battery.

Battery disassembly is prohibited.

Memory card installation

Following instructions by the card slot, it is plug the TF memory

card into the card slot with metal pins inwards.

To take the memory card out, please press the TF card downward

and take it out.

Power-on

Press and hold power key for 2 seconds and release it for power-on

of the camera.

Mode switchover

After power-on, the camera enters the default mode of video

recording at a default size of Lo. In video recording mode at Lo size,

click MODE key to switch the size to HI; in video recording mode at

HI size, click MODE key to enter capture mode at Lo size, and in

capture mode at Lo size, click MODE key to return to video

recording mode at Lo size.

Video recording

In video recording mode, click Shutter key to start video recording

and click it again to stop recording.

Capture

In capture mode, press Shutter key to take pictures.

TV output

When output of image and audio from the camera to TV is needed,

please plug common end of TV cable into TV port of the camera.

The yellow port is for video input, and the red/white port is for audio.

Replay

After connecting to TV, the camera enters the replay mode. In

replay mode, press MODE key to select photo or recorded video.

After selecting recorded video file, press Shutter key to play the file.

During playing the recorded video, press Shutter key to stop

playing.

In replay mode, long press Shutter key to enter shortcut deletion

prompt, press Shutter key to confirm deletion, and press MODE

key to exit from deletion.

Power-off

In power-on mode, long press Power key to power the camera off.

Connection to computer

Firstly power the camera on, and then connect the camera with

attached USB cable to USB port of the computer. After connecting

to the computer, the camera automatically enters portable disc

mode.

4.Advanced Operation

Video recording, capture mode

( With maximum 29 minutes video recording per sequence)

After power-on, the camera automatically enters video recording

mode. In video recording mode at Lo size, click MODE key to

switch the size to HI; in video recording mode at HI size, click

MODE key to enter capture mode at Lo size, and in capture mode

at Lo size, click MODE key to return to video recording mode at Lo

size.

In video recording mode, press Shutter key to start recording and

press it again to stop recording, press MODE key to switch to Lo

size. In capture mode, press Shutter key to start shooting, and

press MODE key to switch to Lo size.

◆In video recording mode, information are displayed on the

screen as below:

Replay Mode

After power-on and connecting to TV, the camera enters the replay

mode. In replay mode, press MODE key to select photo and

recorded video. After selecting video file, press Shutter key to play

it. During playing, press Shutter key to Stop playing.

In replay mode, long press Shutter key to enter file deletion mode.

In file deletion mode, press Shutter key to confirm deletion, and

press MODE key to exit from deletion.

◆In replay mode, information are displayed on the screen as

below:

No. Icon Description

Video

recording HI

Indicates high resolution in current

video recording mode

Video

recording

icon

Indicates currently in video recording

mode (Flashing icon means in the

process of video recording)

3Battery level Indicates level of battery

4TF card Indicates a memory card available

Recording Lo

Indicates low resolution in current

video recording mode

Time left for

recording

Indicates time left in FT card for video

recording

Capture

mode

Indicates currently in capture mode

8Capture HI

Indicates high resolution in current

capture mode

Photo to be

captured

Indicates quantity of photos to be

captured in current internal memory

10 Capture Lo

Indicates low resolution in current

capture mode

No.

Icon Description

1Replay mode Indicates reply mode

2File quantity

Indicates there are total 31 files, and

the 19th file is being browsed

currently.

3TF card Indicates a memory card available

Icon for video

recording

Indicates the current file is a video

recording file.

1. Black and white digital screen

2. MODE key

3. Shutter

4. Power

5. Microphone

6. Lens

7. Reset

8. USB port

9. TV port

10. TF card slot

AC-1300 Quick Start Guide

ENG-2

File Deletion

After connecting to TV, the camera enters the replay mode. In

replay mode, long press Shutter key to enter file deletion mode,

press Shutter key to confirm deletion, and press MODE key to exit

from deletion.

Warning

• Lithium battery inside!

• Do not try to open the product!

• Do not expose to heat, water, moisture, direct

sunlight!

• Only charge with the original adaptor supplied

with this product!

CAUTION!

DENVER ELECTRONICS A/S

Electric and electronic equipment and included batteries contains

materials, components and substances that can be hazardous to

your health and the environment, if the waste material (discarded

electric and electronic equipment and batteries) is not handled

correctly.

Electric and electronic equipment and batteries is marked with the

crossed out trash can symbol, seen below. This symbol signifies

that electric and electronic equipment and batteries should not be

disposed of with other household waste, but should be disposed of

separately.

As the end user it is important that you submit your used batteries

to the approriate and designated facility. In this manner you make

sure that the batteries are recycled in accordance with legislature

and will not harm the environment.

All cities have established collection points, where electric and

electronic equipment and batteries can either be submitted free of

charge at recycling stations and other collection sites, or be

collected from the households. Additional information is available at

the technical department of your city.

Imported by:

DENVER ELECTRONICS A/S

Stavneagervej 22

DK-8250 Egaa

Denmark

www.facebook.com/denverelectronics
