Sida 1/27

Portable Power Bank

DENVER PQC-15005

1、Technical parameters

1.1 Product appearance、

1.2 Specifications、(please refer to actual item)

Battery type: A grade high-energy density Polymer cell

Capacity: 15000mAh/55.5Wh(TYP)

Micro USB Input: DC 5V/2A

Type-C Input: DC 5V/2A, 9V/2A

Type-C Output: DC 5V/3A, 9V/2A, 12V/1.5A

USB QC 3.0 output: DC 5V/3A, 6.5-9V/2A, 9-12V/1.5A

Size: 139*67*24mm

Product weight: 335g

Power bank 1

USB Cable

Manual

1.3 、List of accessories

Specific accessories

refer to actual item

2、Power display light:

Indicator light:

3.1 Charge the power bank 、

3.2 Charge digital equipment、

1. Indicator light: There are 4 lights on the device to show the capacity.

LED flashing LED switch off LED lighting

Charge the power bank

Charge the devices

Display Indicator light

Indicator light

Capacity percentage

0%--25%

25%--50%

50%--75%

75%--100%

100%

0%--25%

25%--50%

50%--75%

75%--100%

100%

Note

The first light flashes

3、Charging instructions

Connect the cable USB port to the charging device and the other end to the Micro input

connector of power bank.

After connecting, the power bank is automatically charged and the current power level

on the battery status indicator flashes. When the battery is fully charged, the status

indicator light will be on.

Check whether the charging voltage of the digital device matches the discharging

voltage of the power bank.

Select one matching charging cable, connect one end to the power bank output

interface, the other end to the digital device, power bank will automatically recognize to

charge digital device.

Displays

The first light flashes

When the power is

close to 5%, the last

light flashes until

power runs out

The power bank is

full charged when

all the light is

lighting

Power bank will check and show the percentage of capacity when

power on.

4 light stand for: 25 50 75 100

OFF/ON

USB QC3.0 Output

Power Light

USB QC3.0 Output

Micro USB Input:

DC 5V/2A

Type-C Input/Output port

High Efficiency

4、Cautions

5、Tips

6、What is QC 3.0?

If you do not use the power bank for a long time, we recommend you to fully charge the

battery then placed it the dry environment with temperature range from 5 - 35°C, please

avoid to directly expose the product in sunlight.

Please fully discharge then perform full recharging if you have not use the power bank

for more than three weeks or the battery life of the product becomes shorter.

Quick Charge 3.0 is engineered to refuel devices up to four times faster than

conventional charging. It is 38% more efficient than Quick Charge 2.0.

Warning: Lithium battery inside! Do not try to open the power bank. Do not drop or expose to

impact shock in any way.

Do not expose to heat, water, moisture or direct sunlight!

Please note the new power bank can only achieve its best performance after two to

three times fully charge and discharge.

Please extend the charging time for 1-2 hours in first three times in order to maximize

the performance of Polymer battery.

Please do not try to disassemble and modify the product by yourself.

Please avoid making physical damages on this product.

Please avoid using this product in the following environments: high temperature, low

pressure, low temperature, humidity, dust, magnetic field strong and long-term exposure

to sunlight. We recommend that you at an altitude of 3000 meters, 0 ° to 35 ° C and

humidity of 5-95% of the environment using the product.

This product must not be exposed to dripping and splashing water, also it should not be

placed in the annex next to items such as cups filled with liquid a class.

Please only use the charger to charge the product which is comply with below

specification, it might have safety issue if user uses the unsuitable charger to charge the

product.

Please follow the relevant local environmental regulations to dispose the product and

accessories.

Please contact with the local dealer or local customer service center if you have any

questions.

Product is subject to change without notification, please prevail in kind.

Please notice - All products are subject to change without any notice. We take reservations

for errors and omissions in the manual.

With a more granular range of voltages(200mV increments from 3.5V to 20V), your

Quick Charge 3.0 compatible device can target one of dozens of suitable power levels.

Electric and electronic equipment and included batteries contains materials, components

and substances that can be hazardous to your health and the environment, if the waste

material (discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can

symbol, seen below. This symbol signifies that electric and electronic equipment and

batteries should not be disposed of with other household waste, but should be disposed of

separately.

As the end user it is important that you submit your used batteries to the appropriate and

designated facility. In this manner you make sure that the batteries are recycled in

accordance with legislature and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and

batteries can either be submitted free of charge at recycling stations and other collection

sites, or be collected from the households. Additional information is available at the technical

department of your city.

DENVER ELECTRONICS A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

www.facebook.com/denverelectronics

Flexible Structure

Universal charging with quick charge 1.0 technology and quick charge 2.0 devices,

quick charge 3.0 supports all USB standards from A to C.

Universal Charging
