Sida 1/25
Reversible
Luft/Wasser-
Wärmepumpe für
Außenaufstellung
LA 35TUR+
Reversible
Air-to-Water Heat
Pump for Outdoor
Installation
Pompe à chaleur
air-eau réversible
pour installation
extérieure
Montage- und
Gebrauchsanweisung
DeutschEnglishFrançais
Instructions d’installation
et d’utilisation
Installation and
Operating Instructions
Bestell-Nr. / Order no. / No de commande : 452163.66.06 FD 8902
www.dimplex.de EN-1
English
Table of contents
1 Please Read Immediately .......................................................................................................... EN-2
1.1 Important Information........................................................................................................................... EN-2
1.2 Intended Use ....................................................................................................................................... EN-2
1.3 Legal Regulations and Directives ........................................................................................................ EN-2
1.4 Energy-Efficient Use of the Heat Pump ............................................................................................... EN-2
2 Purpose of the Heat Pump ........................................................................................................ EN-3
2.1 Application ........................................................................................................................................... EN-3
2.2 Operating Principle .............................................................................................................................. EN-3
3 Scope of supply.......................................................................................................................... EN-3
3.1 Basic Device ........................................................................................................................................ EN-3
3.2 Switch box ........................................................................................................................................... EN-4
3.3 Heat pump manager ............................................................................................................................ EN-4
4 Accessories ................................................................................................................................ EN-4
4.1 Electrical connection line ..................................................................................................................... EN-4
4.2 External four-way reversing valve........................................................................................................ EN-4
5 Transport..................................................................................................................................... EN-5
6 Set-up .......................................................................................................................................... EN-5
6.1 General ................................................................................................................................................ EN-5
6.2 Condensed Water Pipe........................................................................................................................ EN-5
7 Installation .................................................................................................................................. EN-6
7.1 General ................................................................................................................................................ EN-6
7.2 Connection on heating side ................................................................................................................. EN-6
7.3 Electrical Connection ........................................................................................................................... EN-6
8 Start-Up ....................................................................................................................................... EN-7
8.1 General ................................................................................................................................................ EN-7
8.2 Preparation .......................................................................................................................................... EN-7
8.3 Procedure ............................................................................................................................................ EN-7
9 Maintenance / Cleaning ............................................................................................................. EN-7
9.1 Maintenance ........................................................................................................................................ EN-7
9.2 Cleaning the Heating System .............................................................................................................. EN-7
9.3 Cleaning the Air System ...................................................................................................................... EN-8
9.4 Maintenance ........................................................................................................................................ EN-8
10 Faults / Trouble-Shooting.......................................................................................................... EN-8
11 Decommissioning / Disposal .................................................................................................... EN-8
12 Device information ..................................................................................................................... EN-9
Anhang / Appendix / Annexes ............................................................................................................ A-I
EN-2
English
1
1 Please Read
Immediately
1.1 Important Information
ATTENTION!
For devices with a refrigerant quantity of 6 kg or more, the refrigerating
circuit must be checked for leaks each year in compliance with regulation
(EC) No. 842/2006.
ATTENTION!
The device is not suitable for operation with a frequency converter.
ATTENTION!
When transporting the heat pump, ensure that it is not tilted more than
45° (in any direction).
ATTENTION!
The transport securing device is to be removed prior to commissioning.
ATTENTION!
Do not restrict or block up the area around the air inlet or outlet.
ATTENTION!
Ensure that there is a clockwise rotating field: With incorrect wiring the
starting of the heat pump is prevented. A corresponding warning is
indicated on the display of the heat pump manager (adjust wiring).
ATTENTION!
Never use cleaning agents containing sand, soda, acid or chloride as
these can damage the surfaces.
ATTENTION!
We recommend the installation of a suitable corrosion protection system
to prevent the formation of deposits (e.g. rust) in the condenser of the
heat pump.
ATTENTION!
Before opening the device, ensure that all circuits are isolated from the
power supply.
ATTENTION!
Any work on the heat pump may only be performed by authorised and
qualified after-sales service technicians.
1.2 Intended Use
This device is only intended for use as specified by the manufac-
turer. Any other use beyond that intended by the manufacturer is
prohibited. This requires the user to abide by the manufacturers
product information. Please refrain from tampering with or alter-
ing the device.
1.3 Legal Regulations and
Directives
The construction and design of the heat pump complies with all
relevant EU directives, DIN/VDE regulations (see CE declaration
of conformity).
When connecting the heat pump to the power supply, the rele-
vant VDE, EN and IEC standards are to be adhered to. Any fur-
ther connection requirements stipulated by the network operator
must also be observed.
When connecting the heating and/or cooling system, all applica-
ble regulations must be adhered to.
Persons, especially children, who are not capable of operating
the device safely due to their physical, sensory or mental abilities
or due to their inexperience or lack of knowledge, must not oper-
ate this device without supervision or instruction by the person in
charge.
Children must be supervised to ensure that they do not play with
the device.
ATTENTION!
For devices with a refrigerant quantity of 6 kg or more, the refrigerating
circuit must be checked for leaks each year in compliance with regulation
(EC) No. 842/2006.
More information can be found in the chapter Maintenance /
Cleaning.
1.4 Energy-Efficient Use of the
Heat Pump
With the purchase of this heat pump you are helping to protect
the environment. A prerequisite for energy-efficient operation is
the correct design of the heat source system and heating system.
It is particularly important for the efficiency of a heat pump to
keep the temperature difference between heating water and heat
source as small as possible. For this reason, it is advisable to de-
sign the heat source and heating system very carefully. A tem-
perature difference of approx. one Kelvin increases the
power consumption by around 2.5%. When designing the he-
ating system, it should be borne in mind that special consumers
such as e.g. domestic hot water preparation should also be taken
into consideration and dimensioned for low temperatures. Un-
derfloor heating systems (panel heating) are optimally suited
for heat pump use on account of the low flow temperatures
(30 °C to 40 °C).
It is important to ensure that the heat exchangers are not conta-
minated during operation because this increases the tempera-
ture difference, in turn reducing the COP.
Correct adjustment of the heat pump manager is also important
for energy-efficient use of the heat pump. Further information can
be found in the operating instructions of the heat pump manager.
