5117583/02
CERAMIC PEBBLE FUEL EFFECT
INSTALLER AND OWNER GUIDE
THIS GUIDE IS FOR FITTING THE
6 PE EBBL CERAMIC FUEL EFFECT TO
C AL SS 2 MODELS ONLY.
(Ceramic set number 5115433)
IMPORTANT
THIS GUIDE MUST BE PLACED INSIDE OR ATTACHED
TO THE INSTALLER AND OWNER GUIDE SUPPLIED
WITH THE GAS FIRE. IT MUST BE LEFT WITH THE
OWNER.
THIS GUIDE MUST BE READ IN CONJUNCTION WITH
THE INSTALLER AND OWNER GUIDE SUPPLIED WITH
THE GAS FIRE.
© Baxi Heating U.K. Limited 2007.
© Baxi Heating U.K. Limited 2007.
All rights reserved. No part of this publication may be reproduced in any material form
(including photocopying), stored in any medium by electronic means (including in any
retrieval system or database) or transmitted, in any form or by any means, whether
electronic, mechanical, recording or otherwise, without the prior written permission of
the copyright owner.
Applications for the copyright owner's permission to reproduce any part of this
publication should be made, giving details of the proposed use, to the following
address: The Company Secretary, Baxi Heating UK Limited, The Wyvern Business
Park, Stanier Way, Derby, DE21
Warning: Any person who does any unauthorised act in relation to a copyright work
may be liable to criminal prosecution and civil claims for damages.
Because our policy is one of constant development and improvement, details may vary slightly from
those given in this publication
SAFETY
This product uses fuel effect pieces and a burner compartment rear wall
containing Refractory Ceramic Fibres (RCF), which are man-made vitreous
silicate fibres. Excessive exposure to these materials may cause irritation to
eyes, skin and respiratory tract. Consequently, it is important to take care when
handling these articles to ensure that the release of dust is kept to a minimum.
To ensure that the release of fibres from these RCF articles is kept to a
minimum, during installation and servicing we recommend that you use a HEPA
filtered vacuum to remove any dust and soot accumulated in and around the
fire before and after working on the fire. When replacing these articles we
recommend that the replaced items are not broken up, but are sealed within a
heavy duty polythene bag, clearly labelled as RCF waste. RCF waste is classed
as a stable, non-reactive hazardous waste and may be disposed at a landfill
licenced to accept such waste. Protective clothing is not required when
handling these articles, but we recommend you follow the normal hygiene rules
of not smoking, eating or drinking in the work area and always wash your
hands before eating or drinking.
This appliance does not contain any component manufactured from asbestos
or asbestos related products.
Page 2
INSTALLER AND OWNER GUIDE
© Baxi Heating U.K. Limited 2007.
FITTING THE CERAMIC PEBBLE FUEL EFFECT
The ceramic fuel effect may cause staining / discolouration to decorative surfaces. It
is therefore advisable to protect decorative surfaces.
Note: Depending upon model the detail around the ceramic fuel effect may be
different to that shown.
1. Place the base pebble in the firebox. It should
rest on the ledges at the rear sides of the burner
unit (See figure 1).
Install the 6 loose pebbles as follows. The underside of each pebble is marked with a
letter ‘A’ to ‘F’ and an arrow.
2. The pebbles should be
positioned so that the arrows
always point towards the back of
the fireplace opening. When
located into position the stem of
each arrow should be at 90° to the
rear of the fireplace opening (See
figure 2).
3. Hold pebble ‘A’ upright with the
arrow pointing to the top. Place
pebble “A” on top of the base
pebble (See figure 2).
INSTALLER AND OWNER GUIDE
Page
3
Figure 1 Rear base pebble
position
Figure 2.
© Baxi Heating U.K. Limited 2007.
