Sida 1/8

TOLUCA DELUXE

08/53691/0 Issue 3

OCN: 10860

EN : This product is only suitable for well insulated rooms or occasional use. DE : Dieses Produkt ist nur für gut isolierte Bereiche oder gelegentliche

Verwendung geeignet. FR : Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel. IT : Questo prodotto è

adatto solo per spazi ben isolati o per uso occasionale. ES : Este producto sólo es adecuado para espacios bien aislados o un uso ocasional. NL :

Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik. PL : Produkt ten jest odpowiedni wyłącznie do dobrze

odizolowanych miejsc lub do okazjonalnego użytku. NO : Dette produktet egner seg kun for godt isolerte rom eller sporadisk bruk. RO : Acest

produs este adecvat exclusiv spaţiilor bine ventilate sau utilizării ocazionale. CZ : Tento výrobek je vhodný pouze do dobře izolovaných prostor

nebo k příležitostnému použití. DK : Dette produkt er kun egnet til velisolerede rum eller lejlighedsvis brug. PT : Este produto somente é adequado

para espaços bem isolados ou uso ocasional. SE : Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning. FI : Tämä

tuote soveltuu ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK : Tento výrobok je vhodný len pre dobre izolované priestory alebo

na občasné použitie. SI : Ta izdelek je primeren le za dobro izolirane prostore ali za občasno uporabo. HR : Ovaj proizvod je pogodan samo za

dobro izolirane prostore ili povremenu upotrebu. HU : Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas. SV : Denna produkt är

endast lämplig för användning i väl isolerade utrymmen eller enstaka användning.

The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC).

These cover the essential requirements of EEC Directives.

600mm

940mm

820mm

540mm

155mm

Important Safety Advice

When using electrical appliances, basic

precautions should be followed to

reduce the risk of re, electric shock, and

injury to persons, including the following:

If the appliance is damaged, check

immediately with the supplier before

installation and operation.

Do not use this appliance in the

immediate surroundings of a bath,

shower or swimming pool.

Do not use outdoors.

This appliance must not be located

immediately above or below a fixed

socket outlet or connection box.

WARNING: The appliance carries

the Warning Symbol indicating that

it must not be covered or has a Do

not cover label. Do not cover or

obstruct in any way the heat outlet grille

located above the ame window on the

appliance Overheating will result if the

appliance is accidentally covered. Do

not place material or garments on the

appliance, or obstruct the air circulation

around the appliance, for instance by

curtains or furniture, as this could cause

overheating and a re risk.

In the event of a fault unplug the heater.

Unplug the appliance when not required

for long periods.The supply cord must

be placed on the right hand side of

the heater away from the heat outlet

underneath the appliance.

This appliance can be used by children

aged from 8 years and above and persons

with reduced physical, sensory or mental

capabilities or lack of experinence and

knowledge if they have been given

supervision or instruction concerning

use of the appliance in a safe way

and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintaince shall not

be made by Children without supervision.

Children of less than 3 years should

be kept away unless continuously

supervised. Children aged from 3 years

and less than 8 years shall only switch

on/off the appliance provided that it has

been placed or installed in its intended

normal operating position and they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understanding the hazards

involved. Children aged from 3 years

and less than 8 years shall not plug in,

regulate and clean the appliance or

perform user maintaince.

The appliance must be positioned so that

the plug is accessible.

Although this appliance complies with

safety standards, we do not recommend

its use on deep pile carpets or on long

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

hair type of rugs.

If the supply cord is damaged it must be

replaced by the manufacturer or service

agent or similarly qualified person in

order to avoid a hazard.

CAUTION: In order to avoid a hazard due

to inadvertent resetting of the thermal

cut-out, this appliance must not be

supplied through an external switching

device, such as a timer, or connected

to a circuit that is regularly switched on

and off by the utility.

CAUTION - Some parts of this product

can become very hot and cause burns.

Particular attention has to be given

where children and vulnerable people

are present.

Technical Information

Model No: TLC20LX

Heat Output 230V 240V

Nominal Heat Output P Nom 1.7 - 1.9 kW

Minimum Heat Output P min 0.9 - 0.9 kW

Maximum Continous Heat Output P max,c 1.7 - 1.9 kW

Auxiliary Electricity Consumption

In Standby mode el SB 0.48 - 0.49 W

with electronic room temperature control

General

Unpack the heater carefully and retain the packaging for

possible future use, in the event of moving or returning the

re to your supplier.

The re incorporates a ame effect, which can be used

with or without heating, so that the comforting effect may

be enjoyed at any time of the year. Using the ame effect

on its own only requires little electricity.

Before connecting the heater check that the supply

voltage is the same as that stated on the heater.

Please note: Used in an environment where background

noise is very low, it may be possible to hear a sound which

is related to the operation of the ame effect. This is normal

and should not be a cause for concern.

Electrical Connection

WARNING: THIS APPLIANCE MUST BE EARTHED

This heater must be used on an AC ~ supply only and the

voltage marked on the heater must correspond to the

supply voltage.

Before switching on, please read the safety warnings and

operating instructions.
