II. Product Parameters
Name of the product
Model of product
Supporting platform
Bluetooth
Battery type
Input
Packaging size
Product size
Bluetooth controller T1d
T1d
Android, iOS
Bluetooth 4.0
600mAh, polymer lithium battery
5V-1A
185*180*80mm
162*101*67mm
Bluetooth controller T1d, support Bluetooth 4.0 wireless connection. It is
suitable for Android devices (version 4.3 or above) and Apple devices
(system version iOS8.0 or above). This product fully intelligent and
automatically identifies various models of equipment, no need to
manually set Android or iOS mode, connect and play.
Bluetooth controller
Operating Manual
I. Product Introduction
MENU
C2C1
III. Concept of Controller
Pair
Power display
Charging port
Power button
Photo button Video button
Note: The factory default setting of the controller is the "America hand". The left
joystick control the height and the direction, the right joystick control the forward,
backward, and left direction of the flight.
Lifting
Turn left Turn right
Back
Left Right
Falling
Custom key
Custom
key
Custom
key
Custom
key
Custom
key
Right joystick
Right joystick
Left joystick
Left joystick
Custom
key
Custom key
IV. Function Description
1. Turn on and connect the controller
1) Short press the button to turn on, if it starts successfully, the ABXY
button of the controller will be always on.
2) Power display LED flickers slowly; Enter the Bluetooth mode directly
to wait for the APP connection;
3) Enter the flight control APP to connect the controller;
4) After connecting, the power display LED is always on and show the
quantity of electricity.
5) If the controller has been connected to other phones, press the "Pair"
button of the controller to force the controller to enter the state of waiting
match.
2. Turn-off
1) Long press the power button for 3-5 seconds, shut down the
controller, turn off all the LED lights;
3. Automatic turn-off
1) The controller is in connecting state, if it is idle for more than 5
minutes, the controller will turn off automatically.
2) The controller is in disconnecting state (waiting for connection), if no
connection for 2 minutes, the controller will turn off automatically.
4. Check the power
After the controller connected successfully, the LED lamp will show
current power information.
The LED lamp group shows the proportion: Fully bright is about 75% to
100%; 3 lights are about 50% to 75%; 2 lights are about 25% to 50%; 1
light is about 1% to 25%
5. Low battery alarm
1. When the available power is lower than the low power alarm voltage,
the LED light group lasts double flash;
2. When the available power is lower than the battery protection voltage,
the controller will turn off automatically.
6. Battery charging
1) LED lights 1-4 flicker slowly during charging;
2) When the charge is over (full), the LED light group is always on;
Disconnect the charging cable after charging.
