Sida 1/24

PORTABLE TOILETS

962, 964 965, 966

SANIPOTTIE®

960 SERIES PORTABLE TOILETS

ASEOS PORTÁTILES SERIE 960

TOILETTES PORTABLES, S RIE 960É

INSTRUCTION MANUAL EN 1-8 . . .

MANUAL DE INSTRUCCIONES ES 9-15 . .

MODE D’EMPLOI FR . . 16-22

960 SERIES PORTABLE TOILETS

Dimensions 2

Operation 3

Installation (964, 965, 964MSD, 965MSD) 4-5

Cleaning and Maintenance 6

Winterizing 6

Convenience Products 6

Parts 7

Customer Service 8

Warranty 8

962, 964, 964MSD

All dimensions may vary ± 3/8-inch (10mm).

965, 965MSD, 966

DIMENSIONS

14 1/2-inch

[368mm]

16 1/2-inch

[419mm]

12-inch

[305mm]

14 1/2-inch

[368mm]

16 1/2-inch

[419mm]

15 1/2-inch

[394mm]

MSD Models: Pull ush handle to open ush valve. Pump out holding tank through

boat’s discharge ttings according to boat manufacturer’s instructions.

Prepare toilet for use

1. CAUTION! With seat lid closed, pull

ﬂush handle to open slide valve, then

push to close. This relieves air pressure

that may be created in lower holding

tank due to changes in temperature or

altitude.

2. Remove water cap and ll upper tank.

Replace cap.

3. Pull ush handle to open slide valve.

4. Pour deodorant directly into lower tank,

then close slide valve.

CAUTION! Never pour deodorant into

bowl with slide valve closed.

OPERATION

Use toilet

1. CAUTION! BEFORE EACH USE, with

seat lid closed, pull ﬂush handle to open

slide valve, then push to close. This

relieves air pressure that may be created

in lower holding tank due to changes in

temperature or altitude.

Empty holding tank

CAUTION! MAKE SURE slide valve

handle is all the way in.

1. Unlatch upper unit by disengaging side

latches and lift from holding tank.

2. Carry holding tank to permanent toilet

facility.

2. Use toilet. (If ushing solids, press bellows

pump to add water to bowl before use.)

3. Pull ush handle to release waste into lower

tank.

4. Press bellows pump one or more times to

rinse bowl. Push ush handle to close valve.

3. Remove cap and empty contents into

permanent toilet.

4. Rinse tank thoroughly, replace cap and

reassemble unit and prepare for use.

12 3

1 2 3
