User’s Guide
Warranty
All Earthworks microphones carry a limited
warranty (parts and labor).
Product Registration
To help you get the most out of your
Earthworks purchase, please take a moment
and register your product with us online at
earthworksaudio.com/register.
Service & Repair
If you have any problems with your
Earthworks products, please contact our
Service & Repair Department.
Email: returns@earthworksaudio.com
Telephone: (603) 654-2433, ext. 119
MADE IN USA
™
Printed in USA
earthworksaudio.com
July 11, 2018
Frequency Response of QTC30 (typical)
Description
The Earthworks QTC30 is an omnidirectional (pressure)
pre-polarized condenser microphone directly coupled to a
dedicated wideband, low output impedance preamplier.
The QTC30 requires a standard 24-48V phantom power
supply. It features an extended linear free-eld frequency
response from 3Hz to 30kHz, extremely fast impulse re-
sponse, low self-noise, very low handling noise, uniform
polar pattern, and high SPL handling capabilities. It exhibits
no proximity effect.
Each microphone is delivered with its own calibration chart
providing the individually measured frequency response
curve. A mounting clip is included with the microphone.
Applications
The Earthworks QTC30 is easy to operate. Connect the mi-
crophone to a microphone preamplier supplying 24-48V
phantom power using a standard XLR microphone cable.
Please allow up to one minute for the microphone to settle.
Plugging in the microphone “hot” (phantom power already
present at the input) will not damage the microphone, and
is actually preferred for faster settling. It is normal for any
phantom powered mic to “pop” when plugged in or pow-
ered up. Make sure to mute the signal to speakers or head-
phones when phantom power is rst applied.
The QTC30 is designed for recording quieter sources such
as vocals, strings, woodwinds, and distant-miked orches-
tras or choirs. The QTC30 will faithfully reproduce sound
with impeccable detail and does not exhibit the typical
problems and limitation exhibited with conventional mi-
crophones. Its fast impulse response and diaphragm set-
tling time results in very natural and uncolored sound. The
QTC30 is also an excellent room mic for ambiance in the
studio and for recording rehearsals and performances. This
microphone has no removable parts.
Care of Microphone
Earthworks QTC30 microphone is a precision instrument
designed and built to provide years of top performance.
Following these simple rules will help to protect your invest-
ment in the QTC30:
Avoid touching the front protective screen.
Never attempt to disassemble the microphone –
it cannot be opened.
Avoid extreme heat and condensing humidity. Allow the
microphone to warm up in the case when bringing it in
from the cold weather.
Rough handling may damage the microphone even if no
visible marks are left.
When not in use keep the QTC30 in its case.
•
•
•
•
•
XLR Output Connector Assignment of QTC30
Specications
Frequency response: 3Hz to 30kHz +1/-3dB
Polar Pattern: Omnidirectional
Sensitivity: 34mV/Pa (Typical)
Power Requirements: 24-48V Phantom, 10mA
Peak Acoustic Input: 140dB SPL
Output: XLR-3
Output Impedance: 65Ω, balanced between pins 2 & 3
Minimum Load: 600Ω between pins 2 & 3
Noise: 20dB, A equivalent
Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)
Weight: 160g (.3lb)
Impulse Response of QTC30 (typical)
Polar Response of QTC30 (typical)
Specications are subject to change without notice.
