Sida 1/2
Product Registration
To help you get the most out of your
Earthworks purchase, please take a
moment and register your product with us
online at .earthworksaudio.com/register
Service & Repair
If you have any problems with your
Earthworks products, please contact our
Service & Repair Department.
Email: returns@earthworksaudio.com
Telephone: (603) 654-2433, ext. 119
MADE IN USA
Printed in USA
User’s Guide
™
earthworksaudio.com
July 11, 2018
Description
The Earthworks is a directional pre-polarized SR30/HC
condenser microphone with a rst-order hypercardioid
pickup pattern directly coupled to a dedicated wideband,
low output impedance transformerless preamplier. The
SR30/HC requires a standard 24-48V Phantom Power
supply. It features a frequency response from 20Hz to
30kHz, fast impulse response, very low handling noise,
uniform polar pattern, and high SPL handling capabili-
ties. It provides excellent uncolored rejection of sounds
arriving off-axis.
Each microphone is delivered with its own calibration
chart providing the individually measured frequency re-
sponse curve. A mounting clip is included with the mi-
crophone.
Applications
The Earthworks SR30/HC is easy to operate. Connect
the microphone to a microphone preamplier supply-
ing 24-48V phantom power using a standard XLR mi-
crophone cable. Please allow up to one minute for the
microphone to settle. Plugging in the microphone “hot”
(phantom power already present at the input) will not
damage the microphone, and is actually preferred for
faster settling. It is normal for any phantom powered mic
to “pop” when plugged in or powered up. Make sure to
mute the signal to speakers or headphones when phan-
tom power is rst applied.
The excellent performance characteristics of the
SR30/HC make it ideal for a wide range of applications.
In the studio or on the stage the SR30/HC is an ideal
choice for a variety of instruments including sax, ute,
trumpet, guitar, piano, and percussion. It is superior for
choir because it doesn’t spotlight. Rather, it picks up an
entire section with no hot spots. The SR30/HC is popu-
lar among concert tapers because of its open uncolored
sound and among jazz enthusiasts for its ability to cap-
ture explosive performances while retaining the subtle
nuances of artistic expression.
This microphone has no removable parts.
Care of Microphone
The Earthworks SR30/HC microphone is a precision
instrument designed and built to provide years of top
performance. Following these simple rules will help to
protect your investment in the SR30/HC:
Avoid touching the front protective screen.
Never attempt to disassemble the microphone –
it cannot be opened.
Avoid extreme heat and condensing humidity.
Allow the microphone to warm up in the case when
bringing it in from the cold weather.
Rough handling may damage the microphone even
if no visible marks are left.
When not in use keep the SR30/HC in its case.
•
•
•
•
•
XLR Output Connector Assignment of SR30/HC
Specications
Frequency response: 20Hz to 30kHz
Polar Pattern: Hypercardioid
Sensitivity: 20mV/Pa (-34dBV/Pa)
Power Requirements: 24-48V Phantom, 10mA
Peak Acoustic Input: 139dB SPL
Output: XLR-3
Output Impedance: 65Ω, balanced between pins 2 & 3
Minimum Load: 600Ω btw. pins 2 & 3
Noise: 16dB, A equivalent
Dimensions L x D: 229 x 22 mm (9 x .860 in.)
Weight: 225g (.5lb)
Impulse Response of SR30/HC (typical)
Polar Response of SR30/HC (typical)
Frequency Response of SR30/HC (typical)
Specications are subject to change without notice.
