Liebert®

IntelliSlot™ RDU101™ Communications Card

Installer/User Guide

Vertiv™ | IntelliSlot™ RDU101 Installer/User Guide

Technical Support Site

If you encounter any installation or operational issues with your product, check the pertinent

section of this manual to see if the issue can be resolved by following outlined procedures.

Visit https://www.VertivCo.com/en-us/support/ for additional assistance.

The information contained in this document is subject to change

without notice and may not be suitable for all applications. While

every precaution has been taken to ensure the accuracy and

completeness of this document, Vertiv assumes no responsibility

and disclaims all liability for damages resulting from use of this

information or for any errors or omissions. Refer to other local

practices or building codes as applicable for the correct methods,

tools, and materials to be used in performing procedures not

specifically described in this document.

The products covered by this instruction manual are manufactured

and/or sold by Vertiv. This document is the property of Vertiv and

contains confidential and proprietary information owned by Vertiv.

Any copying, use or disclosure of it without the written permission

of Vertiv is strictly prohibited.

Names of companies and products are trademarks or registered

trademarks of the respective companies. Any questions regarding

usage of trademark names should be directed to the original

manufacturer.

TABLE OF CONTENTS

1 Introduction 1

1.1 Support for Liebert® SN Sensors 1

2 Installation 3

2.1 Installing the Card 4

2.1.1 Connecting Directly to Computer for Configuration 4

2.1.2 Determining the DHCP IP Address 5

2.1.3 Assigning a Static IP Address 6

2.2 Change User Names and Passwords Immediately 6

2.3 Configure the Card 6

2.4 Installing Multiple Cards in a System 7

2.5 Security Best Practices 7

3 Enable Communication Protocols 11

3.1 Enable the Protocol 11

3.1.1 Enable SNMP 11

3.2 Download Protocol Mappings 14

4 UNITY Web-page Layout 15

4.1 Web Page Sections 15

4.2 Help Text 16

4.3 Managed-device Tab Menu 17

4.4 Communications Tab Menu 17

4.5 Sensor Tab Menu 18

4.5.1 Sensor-tab Summary Page 19

4.5.2 Sensor-tab Summary Details Pane 19

4.5.3 Changing Sensor Order 20

5 Editing the CardConfiguration 21

5.1 Communications-tab Menu Folders 21

5.2 Active Events Folder 21

5.3 Downloads Folder 21

5.4 Configuration Folder 22

5.4.1 System Folder 22

5.4.2 Local Users Folder 23

5.4.3 Remote Authentication Folder 23

5.4.4 Network Folder 29

5.4.5 Web Server Folder 32

5.4.6 LIFE™ Folder 36

5.4.7 Remote Services Folder 37

5.4.8 Velocity Protocol Folder 40

5.4.9 Messaging Folder 40

5.5 Protocols Folder 44

5.5.1 SNMP Folder 44

Vertiv | IntelliSlot™ RDU101 Installer/User Guide | iii

iii

iiiiii
