EMOS ZU310.9 Bruksanvisning

EMOS Värmare ZU310.9

Läs nedan 📖 manual på svenska för EMOS ZU310.9 (23 sidor) i kategorin Värmare. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/23

1546139100_31-ZU310.9_00_01_WEB 148 × 210 mm ZDROJ: 1546139200_31-ZU310.12_00_01

GB LED Highbay

CZ LED Highbay

SK LED Highbay

PL LED High-bay

HU LED High-bay

SI LED Highbay

RS|HR|BA|ME LED High-bay

DE LED Highbay

UA LED Highbay

RO|MD LED Highbay

LT LED Highbay

LV LED Highbay

EE LED Highbay

BG LED Highbay

FR|BE LED Highbay

IT LED Highbay

NL LED Highbay

ES LED Highbay

www.emos.eu

ZU310.12

ZU310.9

ZU310.6

ZU315.12

ZU315.9

ZU315.6

ZU320.12

ZU320.9

ZU320.6

1 2

7 8

Mounting

1 2

Model Voltage Frequency CCT Wattage PF Lumen Beam Angle Dimension Working

temperature Weight

ZU310.12 100–277 V 50/60 Hz 4 000 K 100 W ≥0.9 18 000 lm 120° ø 265 × 163 mm -35~+50°C 2.15 kg

ZU310.9 100–277 V 50/60 Hz 4 000 K 100 W ≥0.9 18 000 lm 90° ø 265 × 163 mm -35~+50°C 2.15 kg

ZU310.6 100–277 V 50/60 Hz 4 000 K 100 W ≥0.9 18 000 lm 60° ø 265 × 163 mm -35~+50°C 2.15 kg

ZU315.12 100–277 V 50/60 Hz 4 000 K 150 W ≥0.9 27 000 lm 120° ø 300 × 173 mm -35~+50°C 2.65 kg

ZU315.9 100–277 V 50/60 Hz 4 000 K 150 W ≥0.9 27 000 lm 90° ø 300 × 173 mm -35~+50°C 2.65 kg

ZU315.6 100–277 V 50/60 Hz 4 000 K 150 W ≥0.9 27 000 lm 60° ø 300 × 173 mm -35~+50°C 2.65 kg

ZU320.12 100–277 V 50/60 Hz 4 000 K 200 W ≥0.9 36 000 lm 120° ø 340 × 178 mm -35~+50°C 3.25 kg

ZU320.9 100–277 V 50/60 Hz 4 000 K 200 W ≥0.9 36 000 lm 90° ø 340 × 178 mm -35~+50°C 3.25 kg

ZU320.6 100–277 V 50/60 Hz 4 000 K 200 W ≥0.9 36 000 lm 60° ø 340 × 178 mm -35~+50°C 3.25 kg

Installation of Converters DALI

GB | LED Highbay

LED Highbay is designed for mounting onto a solid base or

for hanging both indoors and outdoors.

Ingress Protection IP65 – for outdoor use

Mounting

Method A: Loop

Install the loop with gasket to luminaire well in the specied

position.

Hang the luminaire well into the hook.

Wiring 1 to power supply cable: Brown-L; Blue-N; Green-G;

Wire 2 to dimmer: Purple – Dim+, Pink – Dim-.

Method B: Bracket

1. Use a tool to unscrew the auxiliary screws on the

mounting edge.

2. Place the bracket on the mounting connector, take

screws corresponding to the mounting connector from

the bracket kit and screw them into the mounting

connector

3. Use a hex wrench to tighten screws

4. Use tools to tighten auxiliary screws on the mounting

edge

5. Adjust the bracket to a proper installation angle and

tighten mounting screws on the side of the bracket

6. Drill the screw holes on the ceiling according to recom-

mended size and drive expansion screws into the holes

7. Align expansion expansion screw with the mounting

hole of the bracket and pass through the mounting hole

of the bracket

8. Tighten the washer and nut of the expansion screw.

9. Wiring 1 to power supply cable: Brown-L; Blue-N; Gre-

en-G; Wiring 2 for dimming: Purple – Dim+, Pink – Dim-

Installation height 2.5 m.

L – brown – live wire

G – green&yellow – earth wire (ground)

N – blue – neutral wire

Dim +

Dim -

Dim+ – purple – Dimming +

Dim- – pink – Dimming –

Dimming can be realised in two ways via convertors ZU9001

and ZU9002: 0–10 V, DALI.
