Sida 1/2
Fig. 1 Fig. 2
Fig. 4 Fig. 5Fig. 3
INSERT SIM CARD
Fig. 1: Remove battery cover (as shown).
Fig. 2: Slide SIM card in with the gold contact facing down.
INSERT BATTERY AND CHARGING
Fig. 3: Insert battery (gold contacts on right front side).
Fig. 4: : slide cover to closed position with Close battery door
a ‘click’.
Fig.5: Plug charging cable into the socket on the side of the
phone.
Charging: Battery indication bars in upper right corner of the
display are moving
Full battery: Bars in upper right display corner are solid
Please note: The battery should be charged for at least 4 hours
before your first call. Use only batteries and chargers which are
approved for use with this model.
TOOLS
Bluetooth: Switch on: In the menu
Bluetooth
Power
.
Search audio device:
to search for new devices select
device to be connected
Next time you switch on
Bluetooth it will automatically be connected
.
TELME EMERGENCY SYSTEM
You can store up to 4 emergency numbers (family, neighbours,
friends, emergency services).
In case of an emergency press and hold the emergency
button. The emergency key will still work when the key lock
is enabled.
Press the emergency button to make an emergency call.
Up to 4 numbers will be called in a predetermined order
until the emergency call is answered.
This process is repeated 3 times.
Note: The phone does not recognize whether a person,
an answering machine or voice mail takes off and sees this
as a successful emergency!
To abort the emergency call press long
During the emergency call sequence, the mobile telephone
sounds a warning signal to alert the people around you
about the emergency.
If no emergency number is stored, your prepaid-card has
run out or you are outside of the reception area of your
network operator, the international emergency number
112 will be called.
Note: If you want to save numbers from official services, police,
firefighter, etc. as emergency numbers, you have to clarify this
with these institutions. No liability will be assumed for possible
costs incurred if you dial accidentally.
Saving emergency numbers:
Enter Menu Settings SOS-Settings SOS Numbers
Numbers. Highlight number (with up- and down-key) and press
to select number. Now you enter the desired number and
press Save: Im Menü Einstellungen SOS-Einstellungen
Status Ein/Aus
Then confirm with Yes
.
Note: select emergency number: private number (has to
confirm as explained above) or official service number, e.g.:
ambulance, police, etc. (no confirmation call required).
C145
PartNo: C145_Manual-V2_40677-GER_201311
SUPPORT
TELME Service Center
Industriezeile 36 · 4020 Linz · Austria
Phone: +43 (0)732 · 77 77 17 · 0
Web: www.telme.eu
DECLARATION OF CONFORMITY (DOC)
We, Emporia Telecom Produktions- und Vertriebs- GmbH & Co. KG. declare
under our sole responsibility that the following product is in conformity with
the following relevant harmonised standards.
Kind of product: Dual Band Mobile Phone
Article number: C145
Governing EU-regulations: Council Directive R&TTE 1999/5/EC
Radio equipment and telecommunications terminal equipment
Harmonized EN standards:
Health: EN 50360 - 2001; EN 62209-1 - 2006; EN 62209-2 - 2010
Safety: EN 60950-1+ A12 + A11 + A1: 2011; EN 50332-1 2000
EMC:
EN 301 489-1 V1.9.2; EN 301 489-7 V1.3.1; EN 301 489-17 V2.2.1;
EN 55013+A2: 2006; EN 55020+A11: 2011
Radio spectrum: EN 301 511 V9.0.2; EN 300 328 V1.7.1
0678
Eveline Pupeter, CEO 01.06.2013, Linz/Austria
PACK AGE CONTENT
WARRANT Y
This warranty is valid only if original TELME batteries were used.
TECHNICAL PRODUCT DESCRIPTION
Dualband GSM 900/1800MHz
Dimensions: 109.7 x 55.6 x 13.7 mm
weight: 70 g
Akku: Li-Ion 3,7V / 800mAh, interchangeable
Standby-time: 300h
Talk time: 240min
Internal antenna: SAR 1,190 W/kg
Subject to print errors, mistakes and technical changes.
Mobile phone
Battery: Li-Ion 3.7V / 800mAh
Desktop charger
Mobile phone: 12 month
Battery: 6 month
SAFETY INSTRUCTIONS
Switch off the mobile phone in hospitals or in the vicinity of medical
equipment, as the mobile phone may cause them to malfunction.
Keep your mobile phone a minimum distance of 20cm away from
pacemakers, if it is turned on.
Never drive a car while holding the mobile phone in your hand.
Observe national law and traffic regulations governing the use
of mobile phones in traff ic.
Always turn off your mobile phone inside an airplane.
You must switch off the mobile phone in the vicinity of petrol stations
and other places with explosive materials.
Don’t shine the light directly into the eyes of people or animals.
If the speaker or headset is set to a high volume this can cause hearing
damage. Never hold the phone to your ear when the speakerphone
mode is activated or the emergency button is pressed.
The device and its accessories may contain small parts.
Keep this product out of reach of small children.
As a precaution, we recommend disconnecting the charger
from the phone during a thunderstorm.
CORRECT USAGE
This mobile phone is robust and designed for mobile operation.
However, it must be protected from moisture (rain, bath…) and impact.
Do not expose it to direct sunlight.
Any utilization other than described above will cause damage
to the device, and may be hazardous (electric shock, fire, etc.).
The entire product must not be altered or rebuilt,
and the housing must not be opened.
The power plug is suitable only for use with residential-type outlets of the
public mains with 230 Volt/ 50 Hz (10/16A) alternating current.
The power supply is the power off mechanism of the device. The desktop
charger must be close to the device and be easily accessible.
DISPOSAL
Disposal of packaging: Packaging and packaging materials are
recyclable and should always be returned.
Disposal of batteries: Batteries must not be disposed of with
domestic rubbish! As a consumer you are required by law to recycle
used batteries. You may return them to your local collection point or
to the dealer.
Disposal of the device: Do not throw your mobile phone into the
garbage, once it has outlived its usefulness. For the benefit of the
environment, take it to a recycling location for used phones so it can
be processed in an environmentally responsible way.
ALARM CLOCK:
on/off:
Press 7x
Edit:
to set the alarm time and repetition (once, daily, individually).
Turn off the alarm clock: press
Mute: press
(the alarm clock will go on again after the preset
time).
OTHER FUNCTIONS IN SETTINGS
Enter menu with ins Menü continue to Settings
Sound & Alert:
To choose a phone profile (e.g. silent) and configure your
personal settings.
Call waiting:
You can activate/deactivate and check status to get a
notification about an incoming call while having a phone talk.
Network settings:
Choose automatic (automatic boot in a network) or manual
selection (select a network manually).
Auto power on/Auto power off
Voicemail number: Change the voicemail number
Security settings: Activate, deactivate or change PIN and
phonecode (default phone code: 0000).
Restore Factory: Reset the phone to factory settings.
FREQUENTLY ASKED QUESTIONS
Screen shows “Insert SIM card! Only emergency call 112“:
Check the direction of the SIM card.
A call failed:
Check the selected telephone number and area code again
for accuracy (area code entered?).
The mobile telephone display is blank/black:
Telephone is in energy saving mode (press keylock).
Or it is switched off _ press for 2 seconds to turn it on.
The mobile phone is not responding:
Remove battery, re-insert and switch on the device again.
If still no response, please contact the Service Center.
The charging process will not start:
It may take a few minutes. If there`s no response after
30 minutes, please contact the Service Center.
TEXT MESSAGE (SMS)
SMS (Short Message Service) is a short text message,
up to 160 characters in length.
Writing text: Enter menu with enter New SMS oder New
multimedia message (MMS), if you want to send pictures
with .
Choose Write message with . Entering text with the
keypad. Every key represents several signs, depending on
how often you press the key.
(e.g. 2x , 2x , 3x , 3x , 3x for ) hello
. , ! ? ‘ “ @ : 1
a b c 2 ä æ å à
d e f 3 è è ê
g h i 4 ì í î ï
j k l 5 £
m n o 6 ö ø ó
p q r s 7 ß $
t u v 8 ü ù ú
w x y z 9 ý þ
Space; 0
special character: , . ? ; : ! “ ’
@ _ ~ & + - ( ) < > { } [ ] ...
Use the key, to Choose from 4 Writing Styles:
abc lower case
ABC upper case
Abc Upper and lower
123 numbers
Sending SMS: After typing the text, press 2x
. Send
Enter the number or choose from phonebook
, scroll to
the contact and select with
auswählen). Press
again
to send the message.
TELEPHONE BOOK
Save names and numbers (always with international
dialling code, e.g. +49 for Germany, +43 for Austria, +41 for
Switzerland).
Switzerland).
In standby , press 1x
drücken (standby screen) Menu
points: Search for name, new entry, copy, change entry,
delete, TB settings.
Storing phone book entries (Name & Number):
Enter phone book with
select Add new contact, press Options-Key
select if you want to add your contact to the SIM or to the
phone. Edit name and number by pressing Edit
. Refer to
chapter for writing instructions. Press Back
to save your
entry. A pop-up appears. Press Yes
.
Searching phone book entries:
open the phone book with:
Scroll through the entries with
and or
Search names: enter the initial letters of the searched name
via the keypad (scroll through with
. When the requested
name is shown, press
to start a call.
SYMBO LE AM D ISPLAY Signal strength
Roaming
Battery indicator
Bluetooth
Missed call
Call forwarding
New text
alarm on
Profile: Silent (mute)
Profile: Meeting
Profile: Maximum
Dial: Enter the telephone number via the keypad (including area
code with 0) start call with .
Redial list: - key, scroll through call list with or press (all
dialled, missed and received calls), select a number and start
call with .
Handsfree Speaking: To talk without holding the phone to your
ear, switch on/off the handsfree function during a call : press
Handsfree.
FIRST STEPS
Switch on:
the phone: press power on/off-key for 2 sec.
Switch off:
by pressing power on/off for 2 seconds again.
When using a new SIM card, enter the 4 digit PIN Code (Personal
Identification Number) and confirm with .
Note: The PIN-Code is a 4-digit number combination
preventing others from switching on your mobile phone.
Switch off your PIN-Code: In menu: Settings Security
Settings PIN PIN off.
Tip: The first time you switch it on, you will be asked to enter
the time and date using the number keypad, and confirm with
Furthermore your own telephone number and the device
name will be shown: with . to „save“ and press
Navigation im Menü: Press button.
Flick through the menu points with . and
Confirm with
to get to the marked chapter.
The device will switch off the illumination after a while in the
case of inactivity. To switch the illumination on again, press
any button once.
Incoming call:
Pick up: press the -key
Reject: press the -key
End a call: press the -key
Arrow Keys
On standby: Enter main menu
Enter phone book conact list
In menu and phone book: scrolling
End/On/Off-Ke
In menu: brings you back to home screen
Writing a SMS: brings you back to home
screen and saves SMS to drafts
During a call: Terminate
On/ Off: Press for 2 sec
-Key
Press twiche to switch between capital
letters, small letters and numbers
Press and hold to enable / disable Silent Mode
-Key
When writing (SMS, phone book):
insert a space
M1/M2 Quick dial keys
M1:
In Idle screen: press and hold for calling
contact
In menu: Option/Select/OK
M2:
In idle screen: press and hold for calling
contact
In menu: End/Back/Delete
Writing numbers or text: Delete
During a call: Handsfre
Pick-up/OK/Call list-Key
Calling: Enter the number, then press
Answering an incoming call: press
In menu: Confirm selection
On standby: Enter call list (dialled, received,
missed
-Key
in standby: long press: enable key lock /
disable key lock
press twice: + (for international prefix, e.g.
+44 for UK)
for SMS: Special characters: ( , . „ ´ ? ; ! @ ~ < >
& % [ ] / \ # * § $ ...)
Flashlight
To push on/off the flashlight
Emergency button
Press to start
emergency call
process
Produktspecifikationer
| Varumärke: | Emporia |
| Kategori: | Mobiltelefon |
| Modell: | Telme C145 |
Behöver du hjälp?
Om du behöver hjälp med Emporia Telme C145 ställ en fråga nedan och andra användare kommer att svara dig
Mobiltelefon Emporia Manualer
11 Oktober 2024
5 Oktober 2024
16 September 2024
16 September 2024
13 September 2024
10 Augusti 2024
3 Augusti 2024
28 Juli 2024
Mobiltelefon Manualer
- Mobiltelefon Samsung
- Mobiltelefon Xiaomi
- Mobiltelefon Casio
- Mobiltelefon LG
- Mobiltelefon AEG
- Mobiltelefon Huawei
- Mobiltelefon Philips
- Mobiltelefon Panasonic
- Mobiltelefon Fysic
- Mobiltelefon Motorola
- Mobiltelefon Medion
- Mobiltelefon Nokia
- Mobiltelefon Siemens
- Mobiltelefon Acer
- Mobiltelefon Aiwa
- Mobiltelefon Alcatel
- Mobiltelefon Allview
- Mobiltelefon Apple
- Mobiltelefon Amplicom
- Mobiltelefon Archos
- Mobiltelefon Sharp
- Mobiltelefon Asus
- Mobiltelefon Sony Ericsson
- Mobiltelefon Micromax
- Mobiltelefon Sonim
- Mobiltelefon Sencor
- Mobiltelefon Blaupunkt
- Mobiltelefon Lenovo
- Mobiltelefon Polaroid
- Mobiltelefon Doro
- Mobiltelefon Sagem
- Mobiltelefon Lava
- Mobiltelefon Blu
- Mobiltelefon Denver
- Mobiltelefon ZTE
- Mobiltelefon Sanyo
- Mobiltelefon Sunstech
- Mobiltelefon Gigabyte
- Mobiltelefon Mitsubishi
- Mobiltelefon Nec
- Mobiltelefon Binatone
- Mobiltelefon Blackberry
- Mobiltelefon Olympia
- Mobiltelefon NGM
- Mobiltelefon Profoon
- Mobiltelefon Bixolon
- Mobiltelefon Dell
- Mobiltelefon Switel
- Mobiltelefon InFocus
- Mobiltelefon Pantech
- Mobiltelefon Honor
- Mobiltelefon Logicom
- Mobiltelefon Palm
- Mobiltelefon Kyocera
- Mobiltelefon Plum
- Mobiltelefon Infinix
- Mobiltelefon OnePlus
- Mobiltelefon Lupilu
- Mobiltelefon MyPhone
- Mobiltelefon Tiptel
- Mobiltelefon Beafon
- Mobiltelefon SPC
- Mobiltelefon Teleline
- Mobiltelefon Realme
- Mobiltelefon Maxcom
- Mobiltelefon I.safe Mobile
- Mobiltelefon Cyrus
- Mobiltelefon Oukitel
- Mobiltelefon Orange
- Mobiltelefon Hummer
- Mobiltelefon Tiny Love
- Mobiltelefon GSmart
- Mobiltelefon Bea-fon
- Mobiltelefon Modu
Nyaste Mobiltelefon Manualer
20 Oktober 2024
16 Oktober 2024
15 Oktober 2024
10 Oktober 2024
8 Oktober 2024
7 Oktober 2024
6 Oktober 2024
5 Oktober 2024
30 September 2024
29 September 2024
