Sida 1/19
USM SE- - - 2 2023 V0
Envertech Corporation Ltd.
Tel: 6+86 21 858 0086
Web www.envertec.com:
Email: info@envertec.com
Add: No.138, Xinjunhuan road, Minhang District, Shanghai, China
EVT1600SE
EVT1800SE
EVT2000SE
User Manual
USM SE- - - 2 2023 V0
Content
1. Important Safety Information ............................... 1
1.1 Read It First............................................................... 1
1.2 Safety Instructions .................................................... 1
2. Envertech Microinverter System .......................... 1
2.1 ............................................................ How it Works 2
2.2 Monitoring Device EnverBridge ................................ 2
2.3 ..................................................... Optimal Reliability 3
2.4 Simple Design............................................................ 3
3. Product Information ............................................. 3
3.1 Overview ................................................................... 3
3.2 Major Characteristics ................................................ 3
3.3 Datasheet .................................................................. 3
4. P reparation.......................................................... 6
4.1 P acking Checklist....................................................... 6
4.2 Product Description .................................................. 6
4.3 IFurther nformation .................................................. 6
4.4 Symbols on Inverter.................................................. 6
4.5 Accessories................................................................ 7
5. Microinverter System Installation......................... 7
6. Debugging and Operating ..................................... 14
6 .1 Energize the System .................................................. 14
6 .2 Microinverter Operation........................................... 14
7. Troubleshooting and Maintenance ....................... 14
7 .1 LED Status Indications and Error Reporting .............. 14
7 .2 Troubleshoot an Inoperable Microinverter .............. 14
7 .3 Disconnect Microinverters from PV Modules .......... 14
8. System Diagram ................................................... 16
9. Recycling and Disposal ......................................... 16
10. Contact ................................................................ 17
1
1. Important Safety Information
1.1 Read it First
This manual contains important instructions for the installation and maintenance
of the microinverter.
To reduce the risk of electrical shock, and to ensure safe installation and
operation of the microinverter, the following safety symbols appear throughout
this document to indicate dangerous conditions and important safety
instructions.
1.2 Safety Instructions
Do not use Envertech equipment in a manner not specified by the
manufacturer. Doing so may cause death or injury to persons, or damage to
equipment.
Be aware that only qualified personnel should install or replace the Envertech
microinverters and the cables and accessories.
Do not attempt to repair the Envertech microinverter; it contains no user-
serviceable parts. If it fails, contact Envertech customer service to start the
replacement process. Tampering with or opening the Envertech microinverter
will void the warranty.
If the AC cable on the microinverter is damaged or broken, do not install the
unit.
Before installing or using the Envertech microinverter, read all instructions and
cautionary markings in the technical description and on the Envertech
microinverter system and the PV equipment.
Connect the Envertech microinverter to the utility grid only after you have
completed all installation procedures and received approval from the electric
utility company.
Please be kindly note that the Envertech microinverter itself is a heat sink.
Under normal operating conditions, its temperature is 20°C above ambient, but
under extreme conditions, the microinverter can reach a temperature of 90°C.
Do not disconnect the PV module from the Envertech microinverter without
rusty disconnecting AC power.
2. Envertech Microinverter System
The Envertech microinverter system is an on grid microinverter system with -
world- - top class technology. This manual gives details about the safe installation
and operation of the Envertech microinverter.
The three key elements of an Envertech microinverter system include:
EVT1600SE/EVT1800SE/EV2 000SE microinverter: Converting the DC of the PV
module into AC
DANGER
indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
indicates a hazardous situation which, if not
avoided, can result in death or serious injury or
moderate injury.
NOTICE indicates a situation that can result in property
damage, if not avoided.
