100 Series Flat Panel Monitor Pivots
Vertical Surface, Direct Mount
User's Guide
A B
1
2
#8-32 x 5/16" #8-32 x 3/8"
a b
4X4X
1/2" 1/2"
2
1
1x #8-32
M4 x 10mm
M4 x 10mm
75-100mm
4x
4x
4x
1x 3/32"
a b
888-47-019-02 rev. N • 03/09
2 of 8
1 Determine Ergonomic Mounting Height
1.062"
(26.97mm)
1.062"
(26.97mm)
2 Determine Mounting Confi guration
WARNING
Because surfaces vary widely and the ultimate mounting method is out of Ergotron’s control, it is
imperative that you consult with appropriate engineering, architectural or construction professional
to ensure that your Ergotron mounting solution is mounted properly to handle applied loads.
!
888-99-014
Rev E. 12/02 1 of 10 888-99-014-02
Ergonomic Mounting Heights
(for Flat P anel Monitors and Keyboards)
ERGONOMICS
Ergotro n USA 1-80 0-38 3-1916
Ergotro n Europe +31 20 312 .29.39
Overview
When mounted properly, Ergotron
ARMS™ will provide ergonomic monitor
viewing and keyboard operation for a
wide range of users - whether sitting,
standing or in sit/stand situations.
The dimensioned drawings and formulas
contained in this guide can be used to
determine the ergonomically correct
mounting height of any of Ergotron's
Flat Panel Monitor/Keyboard solutions
mounted to either a vertical or a
horizontal surface. If mounting above
a worksurface, mounting heights may
change due to various worksurface
heights.
The Anthropometric Table on page
10 shows how mounting heights are
calculated based on the eye and elbow
heights of male and female operators.
To Mount your Flat Panel Moni tor or Keyboard at an ergon omi cally
correct height, start at step 1 and continue as di rected.
2
1
Center
Line of
mounting
holes
T op
of
Sc reen
Front View Back View
X
Side View
X
FIND "x"
1
= Distanc e between Cent er line of Mounti ng Holes and Top of Monit or Sc reen.
2
1
Applications mounted to a
horizontal surface
Applications mounted to a 1.5" pole
FIND YOUR MOUNTING APPLICATION
2
2
66 6
8
9
9
9
USE "x"
to c alculate mounting height f or your appli cation.
HD Laptop
Tray
3
8
2 33
4 5
77
888-47-019-02 rev. N • 03/09
3 of 8
3 Mount Pivot
ab
45
75 mm 100 mm X mm
+
ab
#8-32 x 5/16"
4 4X X
#8-32 x 3/8"
4 Attach Monitor
cd
