Sida 1/10

17.6-55lbs 42”-65”
8-25 kg
600 x 500
100 x 100
-
VESA
COMPLIANT
For installation assistance or questions, please contact us
at support@mount-it.com or (855) 925 5668.
MI-384
INSTALLATION INSTRUCTIONS
Height Adjustable Fireplace TV Mount

2
The maximum temperature at the front of the fireplace mantle should never be more
than 100°F (37.8°C).
The fireplace mantle should not extend more than 12”(304mm) from the mounting
surface.
This mount can support displays weighing between 17.6~55lbs(8~25kg).
The mounting surface should be a wood stud frame wall with studs spaced no more
than 24”(609mm) apart ; The wall must notexceed 5/8”(16mm) thick.
Ensure that the mounting surface is capable of supporting the combined weight of
the mount and any mounted display.
This mount should only be installed by persons with a basic knowledge of building
construction and installations.
This bracket should only be installed by two people. Do not attempt to install it by
yourself.
If mounting to a wall of wood stud construction, ensure that mounting bolts are
anchored in the center of the studs. When installing the TV mount on a concrete
wall, the wall must be at least 8.0" (203mm) hick with a minimum compressive t
strength from 2500 to 3000 psi (17.2 to 20.7 Mpa) and must meet the ASTM C39
specification. When installing the T mount on a cinder block wall, the cinder blocks V
must meet the ASTM C216 specifications and have a minimum nominal width of 8.0"
(203mm). Be sure to mount it in a solid part of the block, generally 1" (25mm)
minimum from the side of the block. Do not drill into mortar joints! If plaster/dry
wall is thicker than 5/8" (16mm), custom fasteners must be supplied by the installer.
Note that hardware and instructions are provided for installation to wood stud
walls only.

3
PACKAGE CONTENTS
Mount your television conveniently above your fireplace using this Above Fireplace Mount.
It is capable of supporting televisions with VESA patterns from 100x100 and x500600
and weighing between 17.5~55lbs
(8~25
kg). The mount allows you to keep the
TV safely up and out of the way when not in use, then you can pull it down to eye level
for comfortable viewing.
INTRODUCTION
FEATURES
Designed for flat screen televisions from " ~65" 42
Supports televisions weighing between 17.6~55 lbs
(8~25
kg)
Supports VESA mounting patterns between 100x100 and 600x500
Designed to mount to wood stud frame wall above the fireplace mantle
Television can be pulled down to eye level for comfortable viewing
Full motion mount allows for ±30° swivel, ±5° rotation, and +10°/-5°tilt
Safety Brackets
Wall Plate VESA Bracket
Spring Arm VESA Arms
Crossbar Pull Handle
Pull Handle Template
AA-1
AA.
X 2
X 1
X 1
X 1
X 1
X 1
X 2
X 1
X4
CC.
EE. HH.
GG. II.
FF.
BB.
DD.
X 2
