Sida 1/58
777-24-014-W-0 rev 2E5 / 4
Tablet Management Cart
Set-up and Go Guide
Pages 1 - 4
Guide Set-up and Go
du chariot de gestion de tablettes
Page 5 - page 8
Guía para la con guración
y puesta en marcha
del carrito de gestión de tabletas
Páginas 9 - 12
Tablet Managementwagen – Anleitung
zum Aufbau und Gebrauch
Seite 13 - Seite 16
Carrello di gestione tablet – Guida
rapida all’installazione
Paginas 17 - 20
タブレットマネジメントカート
（Tablet Management Cart）のセ
ットアップおよび使用ガイド
21 ページ - 24 ページ
平板电脑管理手推车安装和使
用指南
25 页 - 28 页
Two Module
Management Carts
Chariots de gestion
à deux modules
Carritos de gestión
con dos módulos
Zwei-Modul-
Managementwagen
Carrelli di gestione
a due moduli
モジュール2個付きマネ
ジメントカート
两台模块管理手推车
1
5
9 10 11
6 7 8
2 3 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1 2 3
1 2 3
1 2 3
4
1
1
1
1
8
8
Make sure the cart power cord is disconnected
from wall power supply before proceeding.
Unlock the module and open the doors.
1 Tablet Charging Set-up
Place the drawer up-side-down on the cart top. Line
up a tablet USB cable along numbers 1 to 8 on the
drawer as a way to measure out slack (represented
by dashed line).
Slide the drawer partially into the module. Recon-
nect the USB and DC cables and wrap the straps
around the cables.
Use a Phillips screwdriver to remove the two screws
located on the interior sides of the module; save
screws to reinsert later.
Route the tablet USB cable through the slots to
the back of the drawer maintaining the slack mea-
sured in previous step.
Slide the drawer completely into the module.
Insert the screws removed in step 2 and tighten.
Partially slide out the module drawer. You’ll need
to unplug two cables before sliding the drawer
completely out. Open the strap to access the two
cables.
Turn over the drawer. Wrap the excess USB cable
around the cable organizer.
Insert tablets into module. Connect the tablet
USB charging cables to the tablets. Repeat Steps
1 - 10 for the other modules.
Unplug the USB and DC power cables (push up on
the lever under the DC connector to release). The
drawer can now be removed.
Connect the USB cable to the corresponding USB
port. Repeat USB cabling steps 5 through 8 for the
rest of the tablets going into this module.
Follow Tablet Charging instructions rst, then Sync Set-up Instructions on next page.
Tablet Charging
The power cord is used to turn
the Cart power on and o .
Charging occurs whenever the
cart power cord is connected
UNLESS a Mac or PC notebook
USB cable is connected to the
cart for syncing (see Tablet
Syncing Set-Up on the next page).
Tablet Management Cart
Set-up and Go Guide
The cart power cord acts as the connect/disconnect de-
vice switching power o and on.
1 / 28
