Installation / Service Instructions
For the latest documentation, visit www.escea.com
DF / DFS
-Series
630381_20
Gas Fireplace
IMPORTANT: The flueing has been significantly changed for DF700, 960, & 990
(refer to section C2).
IMPORTANT: There are new false cavity framing requirements that must be
adhered to (refer to section B1).
IMPORTANT: The fascia and secondary glass are critical components of the fire and
must be properly fastened prior to running the fire (refer to sections D2 and F1).
Important:
The appliance shall be installed in accordance with;
• This installation instruction booklet
• Local gas fitting regulations
• Municipal building codes
• Electrical wiring regulations
• Any other relevant statutory regulations.
• AS/NZS 5601.1:2013 Gas Installations
WARNING:
This appliance must be installed by a qualified person. Replacement of the appliance mains supply
cord should only be made by the manufacturer, its service agent, or a similarly qualified person.
Do not modify this appliance.
This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the appliance.
Failure to follow these instructions could cause a malfunction of the heater, which could result in
death, serious bodily injury, and/or property damage. Failure to follow these instructions may also
void your fire insurance and/or warranty.
Who can install this product:
Installation must be carried out by a registered installer who, on completion of the installation, must
issue a:
AUS: Certificate of Compliance
NZ: Certificates that comply with the latest legislation in accordance with national and/or local
codes. If these are not issued then the Escea warranty may be void.
Warranty Repair and Annual Servicing:
Please contact Escea if you require warranty work. Warranty repair work must be carried out by a
recognised gas fire technician. It is recommended that recognised Escea Gas Fire Technicians are
also used to carry out annual servicing requirements (particularly during the warranty period). For
contact details of recognised Escea Gas Fire Technicians in your area, or for replacement parts,
please contact the retailer from whom the appliance was purchased our visit our website.
The heater must be installed according to these instructions and in compliance with all relevant
building, gas fitting, electrical and other statutory regulations (eg. AS/NZS 5601). Any shortcomings
in the appliance and flue installation will be the responsibility of the installer, and Escea will not be
accountable for any such failings or their consequences.
Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220.
For contact details of your local Escea distributor or dealer in New Zealand, please
visit: www.escea.com or email: info@escea.com. From Australia, please visit www.escea.com.au,
call AU: 1800 460 832 or WA: 1800 730 140, or email us at info@escea.com
DF700 PRODUCT SPECIFICATION
MODEL NAME DF700
Description of Appliance Powerflued Gas Fire Heater
Star Rating 4-5 Stars
Max. Heat Output 5.9kW
A/NZ Approval No. AS/NZS 5263.1.3
Gas Type Natural Propane ULPG
Gas input High 25 MJ/hr 25 MJ/hr 24 MJ/hr
Low 11 MJ/hr 11 MJ/hr 9.5 MJ/hr
Inlet Pressure Max 5.0 kPa 5.0 kPa 5.0 kPa
Min 1.13 kPa 2.75 kPa 2.75 kPa
Operating Pressure on High 1.0 kPa 2.30 kPa 2.30 kPa
Operating Pressure @ Front Burner Jet on High 0.95 kPa 2.29 kPa 2.29 kPa
Burner Jet Size Front: 1.70mm
Rear:1.40mm
Front: 1.05mm
Rear:0.9mm
Front: 1.05mm
Rear:0.85mm
Aeration Collar Hole Size 1 hole @ Ø3.5mm No Collars No Collars
Pilot injector #42 #27 #27
Appliance Dimensions (mm)
Width 693.0 mm
Height 596.0 mm
Depth 387.0 mm
Weight 45 kgKg
Ignition System Electronic Ignition to pilot system
Escea PCB
Ignition Activation 7 secs (approx)
Flame Safeguard Flame Rectification
Consumption 84W @ 0.35A 230V
Remote controls Yes
Timers Yes
Clock Yes
Function lock / child Yes
Temperature control Yes
Connections
Electric 230V AC
Gas 1/2" BSPP female lower right of fireplace chassis
Flue Type 4” and 3” Flexi Flue
Spigot
Location Rear and centre
Data badge location On Chassis Base
